INOX RA Installation Instructions

RA/SE/GT/GS Rose with Tubular Latch Parts List:
Items No. Parts Description
1 Rose Inside w/Lever (Section A)
2 Rose Outside w/Lever (Section B)
3 Outside Rose Cover
4 Inside Rose Cover
M4 x 1-3/8" (35mm) Machine
5
Screw
Leverset
6 8x1-3/4" (45mm) Spring Spindle
Parts
- Dummy Spinle for RA/SE
- #6x1" Wood Screws for RA/SE
7 Privacy Pin
8 Set Screw
9 M4x40mm Bolt Sleeves
- #8x1" Wood Screws
10 Tubular Latch
11 Tubular Latch Faceplate
12 Tubular Latch Striking Plate
8# Screws for Tubular Latch
Locks
13
Faceplate
8# Screws for Tubular Latch
14
Striking Plate
15 Tubular Latch Dust Box
- Door Prep Template
Others
- Installation Instruction
Section A
RA GT
Section B
RA GT
Function
Full Half Half
Privacy Passage
Dummy Dummy Passage
1 EA 1 EA 1 EA 1 EA 1 EA
1 EA 1 EA 1 EA - -
1 EA 1 EA 1 EA - -
1 EA 1 EA 1 EA 1 EA 1 EA
2 EA 2 EA - - 2 EA
2 EA 2 EA - - 1 EA
- - 2 EA 1 EA -
- - 6 EA 3 EA -
1 EA - - - -
2 EA 2 EA 2 EA 2 EA 1 EA
2 EA 2 EA - - 2 EA
- - 8 EA 4 EA -
1 EA 1 EA - - 1 EA
1 EA 1 EA - - 1 EA
1 EA 1 EA - - 1 EA
2 EA 2 EA - - 2 EA
2 EA 2 EA - - 2 EA
1 EA 1 EA - - 1 EA
1 EA 1 EA - - 1 EA
1 EA 1 EA 1 EA 1 EA 1 EA
RA/SE/GT/GS Rose with Tubular Latch Installation Instructions:
1. For RA/SE, mount dummy spindle
with 3 x #6 wood screws. GT/GS does
not need mount dummy spindle.
3.
1
3
2
