Halo Air RF User Manual

2-zone
Hide thumbs Also See for Air RF:

Advertisement

Quick Links

Download this manual
For use with

Advertisement

loading
Need help?

Need help?

Do you have a question about the Air RF and is the answer not in the manual?

Questions and answers

Related Manuals for Halo Air RF

Summary of Contents for Halo Air RF

  • Page 1 For use with...
  • Page 2 If you have purchased or are upgrading a Halo Air RF (non-connected control) you can upgrade this to an internet connected heating control by downloading the Halo app and following the steps in the app to connect your Halo control. You will be required to pay a connection fee to upgrade to app-controlled heating.
  • Page 3 ZONE 1 & ZONE 2 MODE SELECTION The current mode is You can choose to run displayed bottom right your Halo in Auto, Manual or Off mode. Press the right hand Auto: runs your heating to button to change the...
  • Page 4 MAIN FEATURES HEATING ZONE 1 & ZONE 2 PLUS HOURS If you are running a Press and hold the schedule with pre-set times dial to extend the (Auto mode) and you want current heating to maintain the current setting temperature of your heating instead of moving to the next setting simply press the dial.
  • Page 5 MAIN FEATURES HEATING ZONE 1 & ZONE 2 OVERRIDE If you are running a schedule with pre-set times (Auto mode) and you want to adjust the temperature of your heating temporarily, simply turn the dial to your desired temperature. The new temperature will be active until the next scheduled change shown under the target temperature.
  • Page 6 06:00 comfort 21.0ºC 08:00 setback 18.0ºC days and view the 16:00 comfort 21.0ºC Your Halo will come with a pre- setback 18.0ºC 22:00 schedule that is set. Press edit or the dial to modify the set schedule: selected day To edit a day, push...
  • Page 7 Comfort Temperature 21.0ºC Setback Temperature 18.0ºC scrolling and then Your Halo will come with Frost Temperature 08.0ºC pre-set Comfort, Setback pushing the dial to Rotate dial to change or push to select and save when complete edit.
  • Page 8 MAIN FEATURES HOT WATER ZONE 1 ONLY To access the hot water Hot water on functions, when on the until 10:00pm heating home screen, simply press the dial. hot water auto menu mode Push dial to alternate between Central Alternatively press the menu Heating (CH) and button, scroll to Hot Water Domestic Hot Water...
  • Page 9 MAIN FEATURES HOT WATER ZONE 1 ONLY MODE SELECTION Hot water on The current mode is You can choose to run your until 10:00pm displayed bottom right Hot Water in On, Off or Auto hot water auto mode. menu mode Press the right hand button to change the ON: Tops up your hot water...
  • Page 10 MAIN FEATURES HOT WATER ZONE 1 ONLY TIMED HOT WATER Hot water o until 12:00am You can choose to activate the timed hot water (Auto) hot water auto menu mode function in the Advanced Settings menu accessed through the hot water menu.
  • Page 11 MAIN FEATURES HOT WATER ZONE 1 ONLY BOOST Hot water on until 10:00pm If you are running a schedule with pre-set hot water auto menu mode times (Auto mode) and you want to boost your hot Turn the dial water rather than wait for the next scheduled event simply turn the dial.
  • Page 12 MAIN FEATURES HOT WATER ZONE 1 ONLY Turn the dial to move HW Schedule between the different 00:00 Hot Water On SCHEDULES 06:00 Hot Water O days and view the 12:00 Hot Water On Hot Water O 16:00 schedule that is set. If the timed hot water To modify the hot water schedule for a selected day press edit or the dial...
  • Page 13 Override feature which can be used to It will wirelessly communicate with switch your heat pump on if wireless your Halo control and, in the case of an communication between the Halo and internet connected Halo, your home Smart Interface is lost.

  • Page 14: Additional Features

    If there is a fault then the fault symbol will show on the home Fault screen of your Halo. Press the left hand button to access further Notification information about the fault. Energy data is a feature which can be used to check the amount...
  • Page 15 Indicates your heating is on. Indicates there is a fault with the control or heat Fault pump. Child lock Childlock is set so the Halo cannot be altered. Override Override or plus hours function is active. Optimised start Optimised start is active.
  • Page 16 Battery status indication. Indicates that the Halo is communicating Zigbee with the Smart Interface. Indicates that the Halo is communicating with internet and can be controlled with the Halo app via Cloud* your smart phone. *Halo Wi-Fi only Domestic Hot...
  • Page 17 There are also two finger grabs top and bottom as shown below. Use the finger grabs to gently pull the Halo away from the rear housing. Do not use a screwdriver to separate.

  • Page 18: Troubleshooting

    Please note even without a signal between the you will see the following screen. Halo and the smart interface the heating will To re-pair go to section F in the Halo Air continue to operate in failsafe mode. In failsafe installation instructions. You can also find a mode the schedule will still operate.

  • Page 19: Warranty

    WARRANTY Your Ideal Halo comes complete with a 2 year c. To any other costs or expenses caused by or Ideal Guarantee, subject to the following arising as a result of the breakdown of the terms and conditions. controls. d. To any defect resulting from the incorrect During the period of the guarantee we will installation of the controls.
  • Page 20 Hereby, Ideal Boilers Ltd declares that devices Ideal Boilers Ltd (model 234791 (RF) & 234792 (Wi-Fi)) are in compliance National Avenue with: Directive 2014/53/EU. Hull, HU5 4JB T: 01482 498660 The full text of the EU declaration of conformity is available E: enquiries@idealheating.com at the following internet address idealheating.com 235469 A02...
