Summary of Contents for Halo AIR RF
- Page 1 For use with...
- Page 2 HALO AIR RF & WI-FI UIN: 234819 (RF), 234790 (Wi-Fi) Comprising of 234821 ( Halo Air Thermostat ) & 234825 ( Halo Air interface ) and 235327 (Halo Air bracket). Internet connected* wireless single zone Programmable Room Thermostat (PRT). Compatible with the following heat pumps: Logic Air.
-
Page 3: Getting Started
The Ideal Halo Air is a wireless PRT that These instructions are written is paired with the Halo Smart Interface specifically for installation of this installed alongside the Heat Pump. The product with an Ideal Heating Logic Air Smart Interface is fitted into the Smart Heat pump. -
Page 4: Kit Contents
A. KIT CONTENTS 1. Halo PRT display unit 3. Trim plate 2. PRT rear housing HP Comms 4. Desk stand 5. Smart Interface 6. Smart Interface bracket 8. 4 AA Batteries 9. Screws & Rawlplugs 7. Install and user guides... -
Page 5: Location Guidelines
B. LOCATION GUIDELINES The Halo Air uses wireless Zigbee communication 1.2-1.5m between the control PRT and the Interface, up to a maximum range of 30 metres. Occasionally house construction and 1. Mounted 1.2-1.5m above the 2. Not above a radiator/heat... - Page 6 C. INSTALLING THE HALO PRT The Halo can be either wall mounted or desk mounted. WALL MOUNTING THE HALO If there are any concerns regarding signal strength and location of the wall mounted PRT it is advisable to pair the control and check the signal strength before fixing to the wall.
- Page 7 C. INSTALLING THE HALO PRT (CON’T) DESK MOUNTING THE HALO 1. The Halo has an integrated rear housing and 2. Insert the 4 AA batteries provided into the desk stand. front housing of the Halo. Pay close attention that the orientation of the batteries is as indicated in the housing.
- Page 8 D. INSTALLATION OF THE SMART INTERFACE To install the Smart Interface into a new heat pump follow the steps below. The Smart Interface Bracket can be mounted straight to the wall or onto an existing single gang wall box. 1. Locate the bracket in a suitable location close 2a.
- Page 9 D. INSTALLATION OF THE SMART INTERFACE (CONT.) Remove rear knock out Remove bottom knock out 4a. Rear cable mounting; From the fuse spur 4b. Surface cable mounting; From the fuse spur wire the Live, Neutral and Earth connections wire the Live, Neutral and Earth into the left into the left hand side connections in the hand side connections in the Smart Interface Smart Interface Bracket marked L, N, (E).
- Page 10 HALO AIR INTERFACE FLOW THERMISTOR 8. Wire the BSB connection from the bracket 9. Install the cover and screws. into the Halo Air Interface terminals making sure the polarity is correct, and cable retention is in place...
- Page 11 90 seconds. HP Comms is not illuminated check the BSB wiring and polarity. HP Comms 4. Continue the pairing sequence on the Halo 3. Press and hold the Pair button on the Smart PRT. Interface until the Zigbee LED starts flashing to begin the pairing process with the Halo.
- Page 12 The Zigbee communication icon will also be visible on the display. 8. Once the Halo PRT is paired to the Smart Interface press and hold the pair Zigbee icon button on the Smart Interface until the...
-
Page 13: Establishing Communication
Heat Pump and Smart Interface press the Override button. The HP Comms LED the Halo PRT will show the home screen. GREEN will flash for up to 1 minute during which time the Halo PRT will display a CF05 information screen. - Page 14 Ideal Halo app onto the householders phone. (Available on Google Play or the Apple App Store.) 4. Open the Ideal Halo app, tap on create an account and follow the in-app instructions. 5. Once an account has been set up the app will automatically guide the user through connection of the Halo.
- Page 15 I. HALO FEATURES AND CONFIGURATION To enter the settings menu press the menu button. Menu options Action Holiday mode allows the device to be switched off for a predefined period of Holiday time then automatically returns to the pre-programmed heating schedule.
- Page 16 Green (flashing) - Failsafe active* No illumination - Override OFF* † Only applicable for Halo Air Wi-Fi not Halo Air RF. *Override and Failsafe only active when communication is lost between the Halo PRT and Smart Interface. See Halo User Guide for more information.
- Page 17 L. ADVANCED SETTINGS HOT WATER Description Factory setting New setting Timed hot water setting Disabled Emergency immersion heater M. CENTRAL HEATING TEMPERATURE SETTINGS Description Factory setting New setting Comfort 21° C Setback 18° C Frost 8° C...
-
Page 18: Commissioning Checklist
Halo home screen flashes to Pair button again to exit “Identify” function. indicate successful pairing Halo is positioned in the homeowners chosen location if desk mounted. Check RSSI (Received Signal Strength Target RSSI between 0 and -65 Indication) of the Zigbee wireless connection and text green (accessed on the PRT via Menu, Support). -
Page 19: Troubleshooting
PRT does not show the welcome screen follow “Deleting Halo from the Zigbee Network” instrictions below. On the Halo PRT press the dial and the right hand key together until Deleting Halo from the welcome screen is displayed. This will delete the Halo PRT from the the Zigbee Network Zigbee network and factory reset the PRT. - Page 20 Hereby, Ideal Boilers Ltd declares that this device Ideal Boilers Ltd (model 234819 (RF) & 234790 (Wi-Fi)) is in compliance National Avenue with: Directive 2014/53/EU. Hull, HU5 4JB T: 01482 498660 The full text of the EU declaration of conformity is E: enquiries@idealheating.com available at the following internet address idealheating.com...
