5.3.4. Insert the battery cartridge into the tool. Pull the switch trigger to flow built-up dust or particles off the oil discharge hole by discharging
chain oil.
5.3.5. Remove the battery cartridge from the tool. Reinstall the sprocket cover and saw chain on the tool.
fig. 15
5.4. REPLACING THE SPROCKET (fig.18)
NOTE: A worn sprocket will damage a new saw chain. Replace the sprocket if damaged.
5.4.1. Remove the sprocket cover, saw chain and guide bar. See section 4.3, 4.4 for removal.
5.4.2. Refer to fig.18 for indication of areas of most wear on sprocket.
5.5. Ensure that the circlip is replaced to securely hold the new sprocket safely in place (fig.19).
fig. 18
6. STORAGE
6.1.
Clean the tool before storing. Remove any chips and sawdust from the tool after removing the sprocket cover.
6.2. After cleaning the tool, run it under no load to lubricate the saw chain and guide bar.
6.3.
Cover the guide bar with the guide bar cover.
6.4. Empty the oil tank.

7. MAINTENANCE SCHEDULE

7.1. To ensure long life, prevent damage and ensure the full functioning of the safety features, the following maintenance must be
performed regularly.
7.2. Warranty claims can be recognized only if this work is performed regularly and properly. Failure to perform the prescribed maintenance
work can lead to accidents!
7.3.
The user of the chain saw must not perform maintenance work which is not described in the instruction manual. All such work must be
carried out by suitably qualified individuals.
© Jack Sealey Limited
fig. 16
Original Language Version
fig. 17
fig. 19
CP40VCS Issue 2 11/01/2024
