- Page 1 NAVIGATOR JRS1Dsp Series Thermal Overload Relay Series User Manual □ Please carefully read this User Manual before installing and operating the product, and keep this manual properly for future reference Internal...
- Page 2 Safety Notice Please carefully read this instruction before the installation, operation, run, maintenance, and inspection, and follow the contents of the instruction to properly install and operate this product. Danger: ⚫ Do not operate the travel switch with wet hands; ⚫...
- Page 3 About JRS1Dsp Legends: 6- Product model 1- Frame current 7- Certification mark 2- Stop button 8- Rated insulation voltage 3- Reset setting button 9- Normally closed contact A is auto reset 10- Normally open contact H is manual reset 11- Resistive current of auxiliary circuit 4- Setting current set button 12- Trip level 5- Trip indication, testing, and reset...
- Page 4 Normal Operation, Installation and Transport Conditions ●Normal operation and installation conditions (1) The ambient air temperature is not higher than +55℃, and is not below -10℃; the average value within 24 hours does not exceed +35℃; (2) The altitude of the installation site does not exceed 2000m; (3) The relative humidity of the atmosphere does not exceed 50% at the maximum ambient temperature of +55℃, and a higher relative humidity is allowed at lower temperatures, such as 90% at 20℃.
- Page 5 Outline and Installation Dimensions (mm) ●JRS1Dsp-185 Matched with contactor CJX2s-120/160/185/225 ●JRS1Dsp-630/F independent installation b: 75mm standard clamp rail Internal...
- Page 6 Installation Method ●JRS1Dsp-185 35mm clamp rail 1) Combination installation: Connection via screws 2) Independent installation: Fixed via a clamp rail or screw ● JRS1Dsp-630/F: With the independent installation available only, fixed via a 75mm clamp rail or screw Internal...
- Page 7 Wring Diagram ●Combination installation FU-Fuse KM-Contactor FR-Thermal relay SB1-Stop button SB2-Start button Internal...
- Page 8 ●Independent installation The sectional area of the connecting wire of auxiliary circuit is 1mm Table of sectional area of connecting wire of main circuit JRS1Dsp-630 current is calculated according to 100%Ie, and JRS1Dsp-185 current is calculated according to 125%Ie. Sectional area of Sectional area of Setting current Setting current...
- Page 9 Sectional area of Setting current range A Size of copper sign mm connecting wire mm Main circuit 400<Ie≤500 150x2 (30x5)x2 500<Ie≤630 185x2 (40x5)x2 Maintenance and Service ● Regular maintenance is conducted, and dust deposited on the thermal overload relay shall be removed timely. ●...
- Page 10 Models of contactor and fuse corresponding to the rated operating current Setting Fuse matched with the Frame rated relay current Matched contactor Order No. current (A) range (A) Internal...
- Page 11 Company Commitment Under the condition that users follow the use and storage conditions and the product are well sealed, within 24 months from the production date, our company will provide repair and replacement service free of charge for any damage or abnormal operation due to poor manufacture quality. A paid repair will be provided if the warranty period expires.
- Page 12 Inspector: Check 05 DELIXI ELECTRIC LTD Production date: See label on inner box Manufacturer: Zhejiang Delixi Electrical Co., Ltd. Address: Delixi High-Tech Industrial Park, Liushi Town, Yueqing City, Zhejiang 325604 Tel: (86-577) 61778888 Fax: (86-577) 61778000 Customer Service Hotline: 400-826-8008 www.delixi-electric.com...
