- Page 1 JS14□Series Time Relay User Manual Standard: GB/Т 14048.5 □ Please carefully read this User Manual before installing and operating the product, and keep this manual properly for future reference...
- Page 2 1. Overview 1.1 Scope of Application JS14□series time relay adopts SCM system chip circuit, LED digital display, and digital key switch preset; the product is suitable for the AC 50/60Hz automatic control with the voltage of AC380V and below or with the DC voltage of 240V and below as a delay element.
- Page 3 1.3.2 Vertical or horizontal installation is available 2 Structural Features and Working Principle This series of time relays are composed of shell, main line board, panel, and plug; All adopt medium-scale integrated circuit, LED nixie tube display, digital toggle switch preset; it has advantages of convenient setting, stable and reliable operation, high delay accuracy, small size, and universal A100V ~ 240V C and DC voltages for new power voltages of JS14S-H and JS14S-D, and JS14S.
- Page 4 3.4 The rated operating voltage Ue / rated operating current under the usage category Ie: AC-15Ue; AC220V, Ie： 0.47A; DC-13 Ue:DC220V, Ie:0.14A 3.5 Resistive current Ith: 3A 3.6 Contact capacity: AC250V 5A; (resistive); 3.7 Pollution level: 3 3.8 Delay time: See table 3.9 Setting error: ≤1%;...
- Page 5 8-φ4 are wiring holes for back-panel wiring Outline dimensions of JS14PS device type Installation dimensions of JS14PS device type (or a 35mm standard rail used for installation) Reset Reset Pause Pause JS14SG, JS14S, JS14S-D wiring diagram JS14S-H wiring diagram JS14PS wiring diagram JS14C wiring diagram 5 Installation and Operation Instructions 5.1 Follow the specifications and power voltage during operation, and properly connect the wires according to the...
- Page 6 5.3 The time interval between the power outage and the next power-on must be greater than 1 second during operation. 5.4 The operating voltage of the relay should be within the rated working voltage range. 5.5 The equipment that may cause major economic losses or personal safety is designed to make the technical characteristics and performance values have sufficient allowance, and safety measures such as double circuit protection should be adopted.
- Page 7 10. Company Commitment Under the condition that users follow the use and storage conditions and the product are well sealed. within 24 months from the production date. our company will provide repair and replacement service free of charge for any damage or abnormal operation due to poor manufacture quality.
- Page 8 Inspector: Check 01 DELIXI GROUP CO., LTD. Production date: See label on inner box Sold by Delixi Electric Ltd Manufactured by Delixi Group Co., Ltd. 3# Unit, Electrical Apparatus City, Liushi Town, Yueqing City, Zhejiang 325604 Tel: (86-577) 61778888 Fax: (86-577) 61778000 Customer Service Hotline: 400-826-8008 www.delixi-electric.com...
