- Page 1 JS14P Series Time Relay User Manual □ Please carefully read this User Manual before installing and operating the product. and keep this manual properly for future reference...
- Page 2 1.1 Scope of Application JS14P series time relay is suitable for AC 50/60Hz automatic control circuit with the voltage 380V and below and with the DC volage 240 and below. and is used to connect or disconnect the circuit at a predetermined time.
-
Page 3: Technical Features
1.3 Normal Working Conditions and Installation Conditions 1.3.1 Working environment: the altitude does not exceed 2000 meters; the ambient temperature is not higher than +40° C and not below -5° C; the voltage variation range of the rated control power supply is 85%-110% of the rated voltage;... - Page 4 3.10 Mechanical life: ≥1 million times 3.11 Electrical life: ≥100,000 times 3.12 Cooperation with the short circuit protective device (SCPD): The RT16-00, 6A fuse with “1” type basic protection is recommended as SCPD; that is, the relay shall not cause danger to the persons or equipment in case of short circuit, and it is not allowed to work continuously before the repair or replacement of parts.
- Page 5 Time relay Multiple Panel type mounting hole sizes drawing JS14P-01~07/M Panel type outline dimensions drawing 8-φ4 holes are for back-panel wiring Time relay Multiple JS14-01~07 Device type outline dimensions drawing Device type installation dimensions drawing (or a 35mm standard mounting rail used) V.
- Page 6 5.4 Power-on delay type: Please present all required delay time before use. and then turn on the power; at this time the relay delay starts; when the preset time expires. the delay contact is converted to realize timing control. 5.5 Power-off delay type: preset the required delay time. and then turn on the power; at this time. the relay delay contact will pull in.
-
Page 7: Common Faults And Troubleshooting
VI. Common Faults and Troubleshooting 6.1 Not work after startup The power terminal is not wired and the wiring is improperly connected or disconnected. and the power supply is not connected. 6.2 The relay works abnormally after power-on Check the relay wiring connection and digital setting are correct; check the product for broken line or short circuit. - Page 8 Certificate Inspector: Check 01 Production date: See label on inner box DELIXI GROUP CO., LTD. Manufacturer: Zhejiang Delixi Electrical Co., Ltd. Address: No. 155. Zhandong Road. Liushi Town. Yueqing City. Zhejiang P/C: 325604 Tel: (86-577) 61778888 Fax: (86-577) 61778000 Customer Service Hotline: 400-826-8008 www.delixi-electric.com...
