ASROCK A770DE Specifications

A770DE+
AMD 770 + SB710 Chipsets
Product Brief
- Supports for AM3 / socket AM2+ / AM2
processors
- Supports CPU up to 140W
- Supports AMD OverDrive
(Advanced Clock Calibration)
- Supports ATI TM CrossFireX
- PCIE Gigabit LAN
- Supports ASRock Instant Boot, Smart BIOS,
OC Tuner, Intelligent Energy Saver
The specification is subject to change without notice. The brand and product names are trademarks of their
respective companies. Any configuration other than original product specification is not guaranteed.
TM with ACC feature
TM
ww w.asrock.com
Detail Specification
- ATX Form Factor: 12.0-in x 8.2-in, 30.5 cm x 20.8 cm
Platform
CPU - Support for Socket AM2+ / AM2 processors: AMD
Phenom TM FX / Phenom / Athlon 64 FX / Athlon 64 X2
Dual-Core / Athlon X2 Dual-Core / Athlon 64 / Sempron
processor
- Support for AM3 processors: AMD Phenom
and Athlon II X4 / X3 / X2 processors
- Supports CPU up to 140W
- Supports AMD OverDrive™ with ACC feature (Advanced
Clock Calibration)
- AMD LIVE! TM
- Supports AMD's Cool 'n' Quiet Technology
- FSB 2600 MHz (5.2 GT/s)
- Supports Untied Overclocking Technology
- Supports Hyper-Transport 3.0 (HT 3.0) Technology
Chipset - Northbridge: AMD 770
- Southbridge: AMD SB710
- Dual Channel DDR2 memory technology
Memory
- 4 x DDR2 DIMM slots
- Supports DDR2 1066/800/667/533 non-ECC, un-buffered
memory
- Max. capacity of system memory: 16GB
- 2 x PCI Express 2.0 x16 slots (green @ x16 mode,
Expansion Slot
orange @ x4 mode)
- 1 x PCI Express 2.0 x1 slot
- 3 x PCI slots
- Supports ATI
Audio - 7.1 CH Windows
(VIA ® VT1708S Audio Codec)
LAN - PCIE x1 Gigabit LAN 10/100/1000 Mb/s
- Realtek RTL8111DL
- Supports Wake-On-LAN
I/O Panel
Rear Panel I/O
- 1 x PS/2 Mouse Port
- 1 x PS/2 Keyboard Port
- 1 x Coaxial SPDIF Out Port
- 1 x Optical SPDIF Out Port
- 6 x Ready-to-Use USB 2.0 Ports
- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED
LED)
- HD Audio Jack: Side Speaker / Rear Speaker / Central /
Bass / Line in / Front Speaker / Microphone
Connector - 6 x Serial ATAII 3.0 Gb/s connectors, support RAID (RAID
0, RAID 1, RAID 10 and JBOD), NCQ, AHCI and "Hot
Plug" functions
- 1 x ATA133 IDE connector (supports 2 x IDE devices)
- 1 x Floppy connector
- 1 x IR header
- 1 x COM port header
- 1 x HDMI_SPDIF header
- CPU/Chassis/Power FAN connector
- 24 pin ATX power connector
- 8 pin 12V power connector
- CD in header
- Front panel audio connector
- 3 x USB 2.0 headers (support 6 USB 2.0 ports)
BIOS Feature
- 8Mb AMI BIOS
- AMI Legal BIOS
- Supports "Plug and Play"
- ACPI 1.1 Compliance Wake Up Events
- Supports jumperfree
- SMBIOS 2.3.1 Support
- CPU, NB, SB, VCCM Voltage Multi-adjustment
- Supports Smart BIOS
Support CD - Drivers, Utilities, AntiVirus Software (Trial Version),
AMD OverDrive
- ASRock OC Tuner
Unique Feature
- Intelligent Energy Saver
- Instant Boot
- Hybrid Booster:
- CPU Frequency Stepless Control
- ASRock U-COP
- Boot Failure Guard (B.F.G.)
- ASRock AM2 Boost: ASRock Patented Technology
to boost memory performance up to 12.5%
- CPU Temperature Sensing
Hardware Monitor
- Chassis Temperature Sensing
- CPU/Chassis/Power Fan Tachometer
- CPU Quiet Fan
- Voltage Monitoring: +12V, +5V, +3.3V, Vcore
OS ®
- Microsoft Windows
TM
Vista / Vista
Certifications - FCC, CE, WHQL
- Quick Installation Guide, Support CD, I/O Shield
Accessories
- ATA 133 cable
- 2 x SATA data cables (optional)
- 1 x SATA 1 to 1 power cable (optional)
TM II X4 / X3
Ready
TM TM
CrossFireX
®
Vista™ Premium Level HD Audio
TM
Utility
®
XP / XP Media Center / XP 64-bit /
TM
64-bit compliant
