Electric Scooter 4 Pro (2nd Gen) User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Electric Scooter 4 Pro 2nd Gen and is the answer not in the manual?

Questions and answers

Summary of Contents for Xiaomi Electric Scooter 4 Pro 2nd Gen

  • Page 1 Electric Scooter 4 Pro (2nd Gen) User Manual...
  • Page 2: Safety Reminder

    Read this manual carefully before use, and retain it for future reference. Watch out for Safety Risk Safety Reminder Avoid hitting your head on door frames, elevators, Do not press the accelerator when you are walking and other overhead obstacles. alongside the scooter.
  • Page 3 Do not Try Dangerous Actions Do not ride in the rain. Do not ride through puddles Do not ride with anyone else, including children. Do not hang bags or other heavy stuff on the Do not ride on one foot. handlebar.
  • Page 4 Do not try riding up or down stairs, nor try jumping Do not touch the mechanical brake. over obstacles.
  • Page 5: Product Overview

    Product Overview Right Winglight Handlebar Headlight Brake Lever Quick Release Lever Lock Stem Quick Release Lever Front Fork Front Reflector Charging Port Mechanical Brake Accelerator Control Panel & Power Button Left Winglight Scooter Bell Buckle & Bell Lever Winglinght Buttons Deck Hook Taillight &...
  • Page 6 D is for standard mode. S is for sport mode, and it has high speed in this mode; it is recommended to use this mode after on/off in the Mi Home/Xiaomi Home app, and the headlight and taillight will automatically turn on or off according to the ambient mastering the riding skills.
  • Page 7: Package Contents

    Package Contents User Manual Important Information Specifications Allen Key Electric Scooter Battery Charger Screw × 5 (1 is spare)
  • Page 8: Assembly And Setup

    Assembly and Set-up Follow the number order as illustrated to pre-tighten the four screws with the included Allen key. Make sure the handlebar is correctly installed and then tighten the screws thoroughly. Put down the kickstand, and hold up the stem until it is completely in an upright position. Then push the quick release lever inward to the end.
  • Page 9: Charge Your Scooter

    Charge Your Scooter ≤30% ≈ 30 When the scooter is turned off for about a month with the battery level of the scooter being lower than 30%, the scooter will enter sleep mode. In this case, the scooter cannot be turned on. To exit the sleep mode, charge the scooter for about three seconds to activate the battery.
  • Page 10 Before being activated, the scooter will keep beeping when turned on and is limited to 10 km/h. When the scooter is used for the first time, it must be activated via the Mi Home/Xiaomi Home app. Tap "+" on the top right corner and open "Scan" to scan the QR code on the label attached to the control panel, on the right side of the deck, or on the back cover of the user manual again.
  • Page 11 Notes: The app is referred to as Xiaomi Home app in Europe (except for Russia). The name of the app displayed on your device should · Watch the riding guide video. Do not exit the video before finishing it. be taken as the default.
  • Page 12: Restore Factory Settings

    Reset Bluetooth Make sure the scooter is turned on. Press the accelerator and simultaneously press the power button 5 times to reset. When the Starting & Accelerating scooter beeps, it has been reset successfully. Step on the deck with one foot, and slowly kicks off the other on the ground. Restore Factory Settings Make sure the scooter is turned on.
  • Page 13 Steering When the scooter slows down or stops, put one foot on the ground to get Tilt your body to the steering direction as you turn, and slowly turn the off the scooter. Put down the kickstand when parking the scooter. handlebar.
  • Page 14 24 hours, and the motor will remain locked when the scooter is turned on again. You need to unlock the motor in the app to use the scooter. Locking the motor will consume the scooter's power, please use this function properly. Note: The phone will vibrate only if the page of the scooter in the Mi Home/Xiaomi Home app is open.
  • Page 15 Adjust the Mechanical Brake Hook Buckle Align the buckle with the hook and secure them Fold the stem. together. Tool: 14 mm T-handle socket wrench (the tool needs to be prepared by the user). Before adjustment, make sure the scooter is powered off and not charging. When the brake is too tight, use the tool to turn the nut on the screw rod counterclockwise, so as to slightly shorten the brake cable's exposed bottom part.
  • Page 16 Inflate the Tire Illustrations of product, accessories, and user interface in the user manual are for reference purposes only. Actual product and functions may vary due to product enhancements. For further information, please go to www.mi.com For detailed e-manual, please go to www.mi.com/global/service/userguide Valve Cap Importer: Beryko s.r.o.
