TABLE OF CONTENTS
1.
1.1. PREFACE.............................................................................................................1-1
1.2. KEY FEATURES ..................................................................................................1-1
1.3. PERFORMANCE LIST.........................................................................................1-2
1.4. BLOCK DIAGRAM ...............................................................................................1-3
1.5. INTRODUCE THE Pentium ® II Processor ..........................................................1-4
1.6. What is AGP? .......................................................................................................1-6
2.
2.1. HARDWARE ........................................................................................................2-1
2.2. SOFTWARE.........................................................................................................2-2
2.3. ENVIRONMENT...................................................................................................2-2
3.
3.1. UNPACKING ........................................................................................................3-1
3.2. MAINBOARD LAYOUT ........................................................................................3-2
3.3. QUICK REFERENCE FOR JUMPERS & CONNECTORS ................................3-2
3.4. DRAM INSTALLATION........................................................................................3-5
3.5. CPU SPEED SETUP ...........................................................................................3-5
3.6. CMOS RTC & ISA CFG CMOS SRAM................................................................3-6
3.7. SPEAKER CONNECTOR INSTALLATION ........................................................3-7
3.8. HARDWARE RESET SWITCH CONNECTOR INSTALLATION.......................3-7
21
Advertisement
Table of Contents
Related Manuals for Gigabyte GA-6EA Rev. 1.x
Summary of Contents for Gigabyte GA-6EA Rev. 1.x
-
Page 1: Table Of Contents
TABLE OF CONTENTS INTRODUCTION 1.1. PREFACE......................1-1 1.2. KEY FEATURES ....................1-1 1.3. PERFORMANCE LIST..................1-2 1.4. BLOCK DIAGRAM ....................1-3 1.5. INTRODUCE THE Pentium ® II Processor ............1-4 1.6. What is AGP? .......................1-6 SPECIFICATION 2.1. HARDWARE ......................2-1 2.2. SOFTWARE......................2-2 2.3. ENVIRONMENT....................2-2 HARDWARE INSTALLATION 3.1. - Page 2 Table of Contents 3.9. POWER LED CONNECTOR INSTALLATION ...........3-7 3.10. IDE & ATAPI DEVICE INSTALLATION.............3-7 3.11. PERIPHERAL DEVICE INSTALLATION............3-7 3.12. KEYBOARD & PS/2 MOUSE INSTALLATION..........3-7 BIOS CONFIGURATION 4.1. ENTERING SETUP .....................4-1 4.2. CONTROL KEYS ....................4-1 4.3. GETTING HELP....................4-2 4.3.1. Main Menu....................4-2 4.3.2.
-
Page 3: Introduction
INTRODUCTION 1.1. PREFACE Welcome to use the 6EA motherboard. It is a Pentium ® II Processor based PC / AT compatible system with AGP / PCI / ISA Bus, and has been designed to be the fastest PC / AT system. There are some new features allow you to operate the system with just the performance you want. -
Page 4: Performance List
Introduction 1.3. PERFORMANCE LIST The following performance data list is the testing results of some popular benchmark testing programs. These data are just referred by users, and there is no responsibility for different testing data values gotten by users. (The different Hardware & Software configuration will result in different benchmark testing results.) •... -
Page 5: Block Diagram
1.4. BLOCK DIAGRAM 66MHz 14.318MHz SLOT 1 3.3V EDO/SDRAM DIMM Sockets SLOT Host Bus 82443EX AGP Bus CHIPSET DRAM Bus 33MHz 66MHz 66MHz 33MHz Ultra DMA/33 52C64-05 24MHz IDE Ports PCI Bus 33MHz PIIX4 48MHz 82371EB 14.318MHz USB Ports IDE Bus CHIPSET USB Bus 14.318MHz... -
Page 6: Introduce The Pentium ® Ii Processor
Introduction 1.5. INTRODUCE THE Pentium ® II Processor Figure 1:Retention Mechanism & attach Mount Figure 2:OEM Pentium ® II Processor... - Page 7 Figure 3:Heatsink / FAN & Heat sink support for OEM Pentium ® II Processor Figure 4:Boxed Pentium ® II Processor & Heat sink support...
-
Page 8: What Is Agp
Introduction 1.6 What is AGP? The Accelerated Graphics Port (AGP) is a new port on the Host-To-PCI bridge device that supports an AGP port. The main purpose of the AGP port is to provide fast access to system memory. The AGP port can be used either as fast PCI port (32-bits at 66MHz vs. 32-bits at 33MHz) or as an AGP port which supports 2x data-rate, a read queue, and side band addressing. -
Page 9: Specification
SPECIFICATION 2.1. HARDWARE • Pentium ® II processor 200 – 633 MHz. − − 242 pins 66MHz slot1 on board. • − 66 MHz system speed. SPEED − 66 MHz AGP bus speed. (133MHz 2X mode) − 33 MHz PCI-Bus speed. −... -
Page 10: Software
Specification − Suspend mode support. • GREEN FUNCTION − Green switch & ACPI LED support. − IDE & Display power down support. − Monitors all IRQ / DMA / Display / I/O events. • − BIOS 2M bits FLASH RAM. −... -
Page 11: Hardware Installation
HARDWARE INSTALLATION 3.1. UNPACKING The mainboard package should contain the following: • The 6EA main board. • The Retention Mechanism & Attach Mount • USER'S MANUAL for main board. • Cable set for IDE, Floppy & I/O devices. • CD for main board Utility. (Bus Master IDE Driver, Suspend to HD Utility, LDCM, SIV, Patch 95) The main board contains sensitive electric components, which can be easily damaged by static electricity, so the main board should be left in its original... -
Page 12: Mainboard Layout
Hardware Installation 3.2. MAINBOARD LAYOUT ISA 2 ISA 1 BIOS PCI 3 PIIX4E BAT1 WAKE PCI 2 LANE PCI 1 SB-LINK BANK 1 BANK 0 COM A Intel 440EX 82443LX COM B FLOPPY ATX POWER POWER ×Figure 3.1Ø 3.3. QUICK REFERENCE FOR JUMPERS & CONNECTORS I/O Ports Connector USB port. - Page 13 IR : INFRARED Connector (IR) -- Function Option Pin No. Function IR Data Output IR Data Input Signal POWER (+) PWR : POWER ON LED ( PW-LED) Pin No. Function LED POWER (+) LED POWER (-) LED POWER (-) SPK : SPEAKER Connector Pin No.
- Page 14 Hardware Installation Soft PWR : Soft Power Switch Pin No. Function CTRL-Signal FAN PWR : CPU cooling FAN Power Connector Pin No. Function GND. +12V SENSE J10 : System After Ac Back Pin No. Function 1-2 Open Soft Off. 1-2 Close Full On.
-
Page 15: Dram Installation
3.4. DRAM INSTALLATION The main board can be installed with 8 / 16 / 32 / 64 / 128 / 256 MB 168 pins DIMM module DRAM, and the DRAM speed must be 50 or 60 ns for EDO & 67MHz for SDRAM when system bus speed is set to 66MHz. -
Page 16: Cmos Rtc & Isa Cfg Cmos Sram
Hardware Installation DIP SWITCH (SW) FREQ. EXT.CLK. INT.CLK. CPU Type RATIO Pentium ® II 233 MHz Pentium ® II 266 MHz Pentium ® II 300 MHz Pentium ® II 333 MHz Pentium ® II 366 MHz MAIN CLOCK 66MHz 75MHz 83MHz The CPU is a sensitive electric component and it can be easily damaged by static electricity, so users must keep it away from metal... -
Page 17: Speaker Connector Installation
3.7. SPEAKER CONNECTOR INSTALLATION There is a speaker in AT system for sound purpose. The 4 - Pins connector SPK is used to connect speaker. 3.8. HARDWARE RESET SWITCH CONNECTOR INSTALLATION The RESET switch on panel provides users with HARDWARE RESET function. The system will do a cold start after the RESET switch is pushed and released by user. - Page 20 USER'S MANUAL System power on by PS/2 Mouse: First, enable this function in CMOS Setup, then you can power on the system by double clicking the right or left button of your PS/2 Mouse. System power on by Keyboard: If your ATX power supply supports larger than 720 mA 5V Stand-By current, you can power on your system by entering password from the Keyboard after setting the “Keyboard power on”...
- Page 22 The author assumes no responsibility for any errors or omissions which may appear in this document nor does it make a commitment to update the information contained herein. Third-party brands and names are the property of their respective owners. Sound Blaster is a registered trademark of Creative Technology Ltd in the United States and certain other countries.
- Page 23 Quick Installation Guide I. Quick Installation Guide : CPU SPEED SETUP The system bus speed can be selectable between 66.6MHz. The user can select the system bus speed (JP2,JP3,JP4) and change the DIP SWITCH (SW) selection to set up the CPU speed for 200 - 366MHz processor. The CPU speed must match with the frequency RATIO.
- Page 24 SDRAM, Cards, etc. 1. Pentium ® II 233 / 66 MHz FSB 4 3 2 1 PIIX4E Intel 82443LX 440EX 2. Pentium ® II 266 / 66 MHz FSB 4 3 2 1 PIIX4E Intel 82443LX 440EX...
- Page 25 Quick Installation Guide 3. Pentium ® II 300 / 66 MHz FSB 4 3 2 1 PIIX4E Intel 82443LX 440EX 4. Pentium ® II 333 / 66 MHz FSB 4 3 2 1 PIIX4E Intel 82443LX 440EX...
- Page 26 5. Pentium ® II 366 / 66 MHz FSB 4 3 2 1 PIIX4E Intel 82443LX 440EX II. Jumper setting : IR : Infrared Connector (Optional)
- Page 27 Quick Installation Guide PIIX4E Intel Pin No. Function 82443LX 440EX IR Data Output IR Data Input Signal POWER (+) PWR : Power LED PIIX4E Intel 82443LX 440EX Pin No. Function LED anode (+) LED cathode (-) LED cathode (-) SPK : Speaker Connector...
- Page 28 PIIX4E Intel 82443LX 440EX Pin No. Function Signal TD : Turbo LED Connector PIIX4E Intel 82443LX 440EX Function LED anode (+) LED cathode(-)
- Page 29 Quick Installation Guide TB : Turbo Switch Connector PIIX4E Intel 82443LX 440EX Function Signal RST : Reset Switch PIIX4E Intel 82443LX 440EX Open : Normal operation. Close : Reset system...
- Page 30 GD : Green LED Connector PIIX4E Intel 82443LX 440EX Function LED anode (+) LED cathode(-) GN : Green Function Switch PIIX4E Intel 82443LX 440EX Open : Normal operation. Close : Entering Green Mode...
- Page 31 Quick Installation Guide HD : IDE Hard Disk Active LED PIIX4E Intel 82443LX 440EX Function LED anode (+) LED cathode(-) Soft PWR : Soft Power Connector PIIX4E Open: Normal Operation Intel 82443LX 440EX Short: Power On/Off Function Signal POWER : Power Connector...
- Page 32 PIIX4E Pin No. Function Intel 82443LX Power Good 440EX VCC (+5V) 2,10,11,12 +12V -12V 5,6,7,8 ATX POWER : ATX POWER Connector PIIX4E Function Pin No. 3,5,7,13,15-17 VCC (+5V) 4,6,19,20 +12V Intel 82443LX -12V 440EX Power Good 5V SB (Stand by +5V) PS-ON (Soft ON/OFF) FAN PWR : CPU Cooling Fan Power Connector...
- Page 33 Quick Installation Guide PIIX4E Intel 82443LX 440EX Function +12V SENSE IDE1: For Primary IDE port PIIX4E Intel 82443LX 440EX RED LINE IDE2: For Secondary IDE port...
- Page 34 PIIX4E Intel 82443LX 440EX RED LINE FLOPPY : FLOPPY PORT PIIX4E Intel 82443LX 440EX RED LINE LPT : LPT PORT...
- Page 35 Quick Installation Guide PIIX4E Intel 82443LX 440EX RED LINE COMB : COM B PORT PIIX4E Intel 82443LX 440EX RED LINE COMA : COM A PORT...
- Page 36 PIIX4E Intel 82443LX 440EX RED LINE JP1 : Keyboard Power On (for ATX Power Supply only) PIIX4E 1-2 close : Enable Keyboard Power On. Intel 82443LX 440EX 2-3 Close : Disable Keyboard Power On. K.B : Keyboard Connector...
- Page 37 Quick Installation Guide PIIX4E Intel Pin No. Function 82443LX 440EX Key Clock. Key Data VCC (+5V) J7 : PS/2 MOUSE PIIX4E Intel 82443LX 440EX RED LINE USB : USB Port...
- Page 38 PIIX4E Pin No. Function USBV 0- USBV 0+ Intel 82443LX 440EX USBV1- USBV1+ Wake on Lan (for ATX Power Supply only) PIIX4E Intel 82443LX 440EX Pin No. Function +5V SB Signal J10 : ATX Power Control Selection...
- Page 39 Quick Installation Guide PIIX4E Intel 82443LX 440EX Open: Soft Off Short: Full On Function Pin No. Signal SB-LINK : For PCI Audio / Sound Card use only (Creative PCI Sound Card Support) PIIX4E Pin No. Function Intel 82443LX Signal 440EX Signal Signal...
- Page 40 BAT1 : For Battery PIIX4E – Intel 82443LX 440EX M Danger of explosion if battery is incorrectly replaced. M Replace only with the same or equivalent type recommended by the manufacturer. M Dispose of used batteries according to the manufacturer’s instructions. III.
- Page 41 Quick Installation Guide Each value of items as above depends on your hardware configuration : CPU , SDRAM , Cards , etc. Please modify each value of items If your system does not work properly .
- Page 42 These data are just referred by users, and there is no responsibility for different testing data values gotten by users. (The different Hardware & Software configuration will result in different benchmark testing results.) • Pentium ® II processor • DRAM (32x 2) MB SDRAM (LGS GM72V661641CT7J) •...
