- Page 1 ELECTROLUX CUISINIERE INDUCTION EKI668900W Besoin d’un conseil ? Une question sur ce produit ? RDV sur la communauté SAV Darty : https://sav.darty.com Déjà 1/2 million de solutions grâce à l’avis des utilisateurs.
- Page 2 EKI668900W Cooker User Manual...
-
Page 3: Table Of Contents
18. ENVIRONMENTAL CONCERNS..............39 WE’RE THINKING OF YOU Thank you for purchasing an Electrolux appliance. You’ve chosen a product that brings with it decades of professional experience and innovation. Ingenious and stylish, it has been designed with you in mind. So whenever you use it, you can be safe in the knowledge that you’ll get great results every time. -
Page 4: Safety Information
ENGLISH SAFETY INFORMATION Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damage that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference. - Page 5 This appliance may be used in, offices, hotel guest • rooms, bed & breakfast guest rooms, farm guest houses and other similar accommodation where such use does not exceed (average) domestic usage levels. Only a qualified person must install this appliance and •...
-
Page 6: Safety Instructions
ENGLISH disconnect the appliance from power supply. In either case contact the Authorised Service Centre. After use, switch off the hob element by its control and • do not rely on the pan detector. WARNING: The appliance and its accessible parts •... - Page 7 • Do not pull the appliance by the • If the mains socket is loose, do not handle. connect the mains plug. • The kitchen cabinet and the recess • Do not pull the mains cable to must have suitable dimensions.
- Page 8 ENGLISH • Fats and oil when heated can release can cause scratches. Always lift these flammable vapours. Keep flames or objects up when you have to move heated objects away from fats and them on the cooking surface. oils when you cook with them. 2.4 Care and Cleaning •...
-
Page 9: Installation
2.6 Internal lighting • Read carefully all the instructions for Pyrolytic cleaning. • Keep children away from the WARNING! appliance while the Pyrolytic cleaning Risk of electric shock. operates. • Concerning the lamp(s) inside this The appliance becomes very hot and... - Page 10 ENGLISH 3.1 Location of the appliance 3.3 Levelling of the appliance Do not install the cooker near the sink or near the cabinet with sink. Humidity / water drops can enter between the side panel and the cabinet and in time may damage the paint of the side panel.
- Page 11 CAUTION! If the space between the bench cupboards is larger than the width of the appliance, you must adjust the side measurement to the centre of the appliance. 3.5 Electrical installation WARNING! The manufacturer is not 1. Install the anti-tilt protection 232 -...
-
Page 12: Product Description
ENGLISH 4. PRODUCT DESCRIPTION 4.1 General overview Knob for the temperature Electronic programmer Knob for the oven functions Heating element Lamp Shelf support, removable Cavity embossment Shelf positions 4.2 Cooking surface layout Induction cooking zone 1400 W with the PowerBoost 2500 W Induction cooking zone 2300 W with the PowerBoost 3600 W 140 mm... -
Page 13: Hob - Daily Use
5.2 Using the sensor fields Accessories can become hotter than usual. The oven can emit an odour and To activate the function press and hold smoke. Make sure that the airflow in the the selected symbol on the display for at room is sufficient. - Page 14 ENGLISH Sensor Function Comment field Hob²Hood To activate and deactivate the manual mode of the function. Lock / Child Safety To lock / unlock the control panel. Device STOP+GO To activate and deactivate the function. To select the cooking zone. To increase or decrease the time.
- Page 15 • when the hob is deactivated but the Touch at the same time to cooking zone is still hot. deactivate the cooking zone. The indicator disappears when the 6.7 Automatic Heat Up cooking zone has cooled down. If you activate this function you can get a 6.4 Activating and deactivating...
- Page 16 ENGLISH To activate the function: activate the If the timer is not set, all hob with . Do not set any heat setting. indicators disappear after 3 seconds. Touch for 4 seconds. comes on. Deactivate the hob with Touch to set the time (00 - 99 To deactivate the function: activate the minutes).
- Page 17 When you finish cooking and Auto‐ Boil‐ deactivate the hob, the hood Frying matic fan may still operate for a light certain period of time. After that time the system Mode deactivates the fan automatically and prevents you from accidental...
-
Page 18: Hob - Hints And Tips
ENGLISH • The function sets the last selected zone to the selected power and reduces the power of other cooking zones to prevent a circuit overload. • The heat setting display of the reduced zones changes between two levels. • Power limit for all zones is the difference between maximum power allowed for appliance and the power consumption of oven. - Page 19 7.2 Minimum cookware • humming: you use a high power level. • clicking: electric switching occurs. diameter • hissing, buzzing: the fan operates. The noises are normal and do not Cooking zone Minimum cook‐ indicate any malfunction. ware diameter (mm) 7.4 Examples of cooking...
-
Page 20: Hob - Care And Cleaning
ENGLISH Heat setting Use to: Time Hints (min) 6 - 7 Gentle fry: escalope, veal as nec‐ Turn over when needed. cordon bleu, cutlets, rissoles, essary sausages, liver, roux, eggs, pancakes, doughnuts. 7 - 8 Heavy fry, hash browns, loin 5 - 15 Turn over when needed. - Page 21 The display with the maximum number of functions set. Display indicators Lock Assisted Cleaning Settings Fast Heat Up Cooking Timer in‐ dicators: Progress bar - for temperature, time, heat‐ ing up or residual heat. Steam cooking indicator 9.2 Settings menu 3.
- Page 22 ENGLISH 9.3 Oven functions WARNING! Do not pour any liquids into the cavity embossment before and during the cooking process. There is a risk of damage. Symbol Oven function Application Off position The oven is off. True Fan Cooking To bake on up to two shelf positions at the same time and to dry food.
- Page 23 Symbol Oven function Application Grilling To grill flat food and to toast bread. Turbo Grilling To roast larger meat joints or poultry with bones on one shelf position. Also to make gratins and to brown. Menu To enter the Menu: Assisted Cooking , Pyrolitic Cleaning, Settings.
-
Page 24: Oven - Clock Functions
ENGLISH After an automatic switch-off, press any interrupts the power supply. The oven button to operate the oven again. turns on again automatically when the temperature drops. The Automatic switch-off does not work with the 9.10 Cooling fan functions: Light, Duration, End. -
Page 25: How To Set: Assisted Cooking
10.5 Setting: Time Delay 6. The display shows: --:-- STOP . 7. Turn the knob for the temperature to 1. Turn the knob to choose the heating set the end time. function. 8. Press 2. Press repeatedly. 9. The timer starts counting down at a 3. - Page 26 ENGLISH Dish Weight Shelf level / Accessory Duration time Steak, medi‐ 180 - 220 g 15 min 3; roasting dish on wire per piece; 3 shelf; baking tray cm thick sli‐ Fry the meat for a few minutes on a hot pan. Insert to the oven.
- Page 27 Dish Weight Shelf level / Accessory Duration time Fish Whole fish, 0,5 - 1 kg 30 min 2; baking tray grilled per fish Season the fish with butter and use your favourite spices and herbs. Fish fillet 40 min 3;...
-
Page 28: Oven - Using The Accessories
ENGLISH Dish Weight Shelf level / Accessory Duration time All grain / 1 kg 40 min 2; baking tray lined rye / dark with baking paper or Greased bread all baking tray; loaf pan on wire grain in loaf shelf 13. - Page 29 14.3 Baking cakes Moisture can condense in the appliance or on the door glass panels. This is Do not open the oven door before 3/4 of normal. Always stand back from the the set cooking time is up. appliance when you open the appliance door while cooking.
- Page 30 ENGLISH Food Tem‐ Time Shelf Accessories pera‐ (min) posi‐ ture tion (°C) Soufflé 20 - 25 six ceramic ramekins on wire shelf Sponge flan base 15 - 25 flan base tin on wire shelf Sponge cake 30 - 40 cake tin on wire shelf Fish Fish in pouches 300 20 - 30...
- Page 31 14.7 Information for test institutes Food Function Temper‐ Accessories Shelf Time ature position (min) (°C) Small cakes (16 Conventional baking tray 30 - 40 per tray) Cooking Small cakes (16 True Fan baking tray 25 - 40 per tray)
-
Page 32: Oven - Care And Cleaning
ENGLISH Food Function Temper‐ Accessories Shelf Time ature position (min) (°C) Turbo Grilling grid / roasting 13- 16 Beef burger first side; 13 - 15 sec‐ ond side 1) Preheat the oven for 5 minutes 2) Preheat the oven for 10 minutes 14.8 Pizza Setting When you cook pizza, for best results turn the knob for... - Page 33 15.4 How to use: Pyrolytic CAUTION! Cleaning Be careful when you remove the shelf supports. CAUTION! Remove all accessories and 1. Pull the front of the shelf support removable shelf supports. away from the side wall. CAUTION! Do not use the hob at the same time as the Pyrolysis function.
- Page 34 ENGLISH 5. Release the locking system to remove the glass panels. 2. Lift and turn the levers fully on both hinges. 6. Turn the two fasteners by 90° and remove them from their seats. 90° 3. Close the oven door halfway to the 7.
-
Page 35: Troubleshooting
Make sure that you put the glass panels The drawer below the oven can be (A and B) back in the correct sequence. removed for cleaning. 1. Pull the drawer out until it stops. 2. Slowly lift the drawer. - Page 36 ENGLISH 16.1 What to do if... Problem Possible cause Remedy You cannot activate the The appliance is not con‐ Check if the appliance is appliance. nected to an electrical sup‐ correctly connected to the ply or it is connected incor‐ electrical supply.
- Page 37 Problem Possible cause Remedy Automatic Switch Off oper‐ Deactivate the hob and ac‐ comes on. ates. tivate it again. The Child Safety Device or Refer to "Hob - Daily use" comes on. the Lock function operates. chapter. There is no cookware on Put cookware on the zone.
- Page 38 ENGLISH Problem Possible cause Remedy Steam and condensation You left the dish in the Do not leave the dishes in settle on the food and in oven for too long. the oven for longer than 15 the cavity of the oven. - 20 minutes after the cooking process ends.
-
Page 39: Energy Efficiency
The necessary data for the service centre is on the rating plate. The rating plate is on the front frame of the appliance cavity. Do not remove the rating plate from the appliance cavity. We recommend that you write the data here: Model (MOD.) -
Page 40: Environmental Concerns
ENGLISH Model identification EKI668900W 943005532 Energy Efficiency Index 91.1 Energy efficiency class Energy consumption with a standard load, con‐ 0.91 kWh/cycle ventional mode Energy consumption with a standard load, fan- 0.72 kWh/cycle forced mode Number of cavities Heat source Electricity... - Page 41 Return the Electrolux Appliances AB - Contact Address: Al. Powstańców Śląskich 26, 30-570 Kraków, Poland...
- Page 45 www.electrolux.com/shop...
