CARESCAPE R860:
QUICK START GUIDE
CONNECT AND SET UP DEVICEType A ICU
1
How do I connect the ventilator?
(Image A)
• Connect the mains power cable to
the power inlet shown in
and
shows the power switch, both at the
back of the ventilator
• Connect the air supply (
) and
oxygen (
) to the corresponding
high pressure inlets via NIST
• Cylinder or wall oxygen can be used
3
3
Navigation system for setting control? (Image C)
• The ventilator is controlled by a touch screen (
at
illuminates when connected to the main power supply
• There are hard keys/ buttons running along the bottom of the monitor,
under the display screen as shown in
'lock/unlock', 'audio pause'
• The trim knob scrolls through values and is pressed to confirm
• The patient status is shown in
the monitoring area is in
• Additional controls access procedures, e.g. nebuliser, suction,
inspiratory and expiratory hold and to measure auto PEEP
This quick start guide has been developed by the NHS and should be used in conjunction with the manufacturers Instructions for Use
CONNECT AND SET UP THE R860
A
Ventilator back view
4
SET THE CONTROLS ON THE R860
). The LED indicator
e.g.: 'increase O2', 'home',
, active ventilation mode in
and the patient menu, shown in
2
How do I set up the breathing system
and the HME filter? (Image B)
• A double limb circuit is used. Attach the inspiratory
2
safety guard
1
machine, and attach the inspiratory limb
safety guard. The inspiratory safety guard must be used
at all times during ventilation
• Attach the exhalation valve housing to the expiratory
port
. Attach the expiratory limb
port via the expiratory filter
• Connect the HME
the Y Piece shown in
C
,
2
to the inspiratory port, at the front of the
to this
to the expiratory
5
to
6
8
7
1
6
3
4
TYPE A ICU VENTILATOR
B
Ventilator front view
1
3
2
4
5
