NHS HAMILTON-G5 VENTILATOR Quick Start Manual

HAMILTON-G5 VENTILATOR:
CONNECT AND SET UP THE G5
1
How do I connect the ventilator?
(Image A)
Connect high pressure gas supply to rear of
machine:

High pressure NIST AIR connection.

High pressure NIST OXYGEN connection.

High pressure gas water trap and filter

AC power socket and Power button also
found to rear of machine.
3
Navigation system for setting
controls (Image C)
• Ventilator can be controlled via
touchscreen or press-and-turn

rotatory knob
• Instructions displayed on screen
• Hard button functions as labelled
This quick start guide has been developed by the NHS and Cabinet Office and should be used in conjunction with the manufacturers Instructions for Use
QUICK START GUIDE
A
4
1
2
3
Rear view of Hamilton G5 ventilator
SET THE CONTROLS ON THE G5
2 1
C
3
4
5 6 7 8
2
How do I set up the breathing system and the HME filter?
(Image B)
• Inspiratory limb tubing connected
attaches to inspiratory port
(inspiratory filter needed first)

• Expiratory valve set locks
clockwise in place. Expiratory limb
connects to expiratory port
further connections needed for
.
expiratory exhaust
• Inspiratory and expiratory limbs

connected by Y-piece .

• Flow sensor attaches to Y-piece.
Colour coded flow sensor tubing

attach to connection ports
• HME attaches to flow sensor

then catheter mount

Alarm lamp (illuminates when alarm triggered)

Touch screen display

Manual breath

100% 0 flush
2

Audio Pause

Screen lock/unlock

Nebuliser setup

Standby mode

Print screen (if enabled)

Press-and-turn rotatory knob
9 10
B
.

. No
1
5
6

,
TYPE A ICU
7
2
3 4
8
9
