Firefly
phototherapy
MD
Infant Phototherapy for Jaundice Treatment
#
Firefly
111720641527
UDI
Effective date: December 2023
Issue Number: 01 Version: 15 EN
Issue Date: December 2023
User Manual
www.mtts-asia.com
Firefly. User manual
2265

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Firefly and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for mtts Firefly

  • Page 1 Firefly phototherapy User Manual Infant Phototherapy for Jaundice Treatment Firefly 111720641527 2265 Effective date: December 2023 www.mtts-asia.com Issue Number: 01 Version: 15 EN Firefly. User manual Issue Date: December 2023...
  • Page 2: Table Of Contents

    Contents Company Information Introduction Device Description Safety Information Setting up the Device Using the Device Alarm System Battery backup (optional) Cleaning and disinfection Irradiance measurement Irradiance measurement criteria Specifications Explanation of Symbols Warranty Policy V.1.15.EN Firefly. User manual...
  • Page 3: Company Information

    Company Information Introduction Intended purpose The Firefly Phototherapy is intended to provide phototherapy to treat infant jaundice when a photo- therapy is required and prescribed by a physician. Intended users a) The device is to be operated by qualified personnel only.
  • Page 4: Device Description

    4. Lower Light Blue light shines through a window onto the under-side of the patient. 5. Heat sink Heat from the LED light source escapes from below the Firefly, ensuring the device remains at a safe operating temperature. V.1.15.EN Firefly. User manual...
  • Page 5: Safety Information

    • When using Firefly phototherapy the patient should ALWAYS be placed in the bassinet. • Patients adjacent to the infant phototherapy equipment may need to be protected with protective • The Firefly has been designed so that the bassinet is removable. The patient should be placed in shields or eye protection.
  • Page 6: Setting Up The Device

    • Do not use the in the presence of potentially combustible gases including oxygen, nitrous oxide or other anaesthetics. Note: In the event of a power outage, eye coverings should be left on the patient whenever they are inside the Firefly to 12 V (DC) protect the patient’s eyes in case the power returns.
  • Page 7: Using The Device

    Using the Device Alarm System Error messages: In the case that the Firefly has a minor error then the error number will be dis- Plug in the Firefly. played on the control panel. The device recognises the connection by illuminating every LED on the Control If such an error occurs, this message will appear for 5 seconds after the device is connected to the Panel display.
  • Page 8: Battery Backup (Optional)

    Alarm System Battery backup (optional) LED lifetime warning: The blue LEDs in the Firefly are rated to provide effective treatment for Battery Backup 60,000 hours. The battery backup allows operating the device for 2 hours without AC power supply. The backup activates automatically as soon as the AC power supply is off.
  • Page 9: Cleaning And Disinfection

    Cleaning and disinfection E-MODE - extended battery operation • The Firefly bassinet should be disinfected, before and after the treatment of each patient. In the E-mode allows using the battery for extended period of time (additional 2 hours). case that a patient undergoes treatment for more than one week then be sure to disinfect the During that time the battery is discharged further.
  • Page 10: Irradiance Measurement Criteria

    Irradiance measurement Irradiance measurement criteria Note: to ensure that the device is functioning properly, regularly monitor the Firefly in the following The lights will decay gradually over time, reaching approximately 70% of their original irradiance way. at 60,000 hours. Measurement instructions: Note that the irradiance should be measured when the device has reached 60,000 hours.
  • Page 11: Specifications

    Skin sensitization as per ISO: 10993-Part 10 Energy Star Efficiency Level V compliant RoHS 3 compliant Cytotoxicity direct contact as per ISO 10993-Part 5 Over voltage / over current protection Primary skin irritation as per ISO:10993-Part 10 V.1.15.EN Firefly. User manual...
  • Page 12: Explanation Of Symbols

    MTTS. MTTS authorized service provider can provide you with MTTS MAKES NO OTHER EXPRESS WARRANTY OR details. MTTS will not alter form, fit, or function of this CE Marking with Notified Body Number. CONDITION WHETHER WRITTEN OR ORAL AND MTTS...
  • Page 13 MTTS product has recurring failures, MTTS at THE LESSER OF THE PRICE YOU HAVE PAID FOR THE your sales receipt is the date of purchase unless MTTS or ing one of the following: Locate and contact your nearest MTTS service pro-...
  • Page 14 MEDICAL TECHNOLOGY TRANSFER AND SERVICES Co., LTD House No. 26, Alley 41, An Duong Vuong Street, Tay Ho District, Hanoi City, Vietnam SRN: VN-MF-000036669 Tel: +84 24 3766 6521 Fax: +84 24 3718 8050 Email: assistance@mtts-asia.com www.mtts-asia.com Logic s.r.l. Via Antonio Pigafetta 1 34147 Trieste, Italy SRN: IT-AR-000012301 V.1.15.EN...
