DDR2 | DDR2-R
Dado Round Double
Drinking Fountain
Installation
Guide
Refrigerated and
Non-refrigerated
MELBOURNE
SYDNEY
Britex Place Mirra Crt
16 Northumberland Drv
Bundoora VIC 3083
Taren Point NSW 2229
t (03) 9466 9000
t (02) 9531 2100
e vic@britex.com.au
e nsw@britex.com.au
DDR2 & DDR2-R Installation Guide | QID 1.24 | Rev 2 | 15 Jun 2023
PERTH
BRISBANE
Unit 1/8 Principal Link
19 Manilla St
Malaga WA 6090
East Brisbane QLD 4169
t (08) 9249 5464
t (07) 3363 2400
e wa@britex.com.au
e qld@britex.com.au
TITLE:
Round Drinking Fountain Double
ADELAIDE
The Britex Group
SA State Office
t 1300 764 744
e sa@britex.com.au
DDR2
Advertisement
Table of Contents
Related Manuals for Britex DDR2
Summary of Contents for Britex DDR2
- Page 1 (08) 9249 5464 t (07) 3363 2400 t 1300 764 744 e vic@britex.com.au e nsw@britex.com.au e wa@britex.com.au e qld@britex.com.au e sa@britex.com.au DDR2 & DDR2-R Installation Guide | QID 1.24 | Rev 2 | 15 Jun 2023 TITLE: DDR2 Round Drinking Fountain Double...
-
Page 2: Technical Parameters
Inlet Connection 1/2” BSP Male Recommended Inlet Pressure 350 kPa Maximum Inlet Pressure 500 kPa Water Supply Temperature 4-15°C Limitations Australia’s Finest Stainless | britex.com. DDR2 & DDR2-R Installation Guide | QID 1.24 | Rev 2 | 15 Jun 2023... - Page 3 HepVo UNLESS OTHERWISE SPECIFIED: DO NOT SCALE DR DIMENSIONS ARE IN MILLIMETERS Not Supplied Angle Mounting Strip Side Elevation Australia’s Finest Stainless | britex.com. DDR2 & DDR2-R Installation Guide | QID 1.24 | Rev 2 | 15 Jun 2023...
-
Page 4: Installation Instructions
3. Unit is ‘remotely’ located whether that’s in a cupboard space with adequate ventilation or in a janitorial/services room ideally adjacent to the fountain. Australia’s Finest Stainless | britex.com. DDR2 & DDR2-R Installation Guide | QID 1.24 | Rev 2 | 15 Jun 2023... - Page 5 8m Away 40mm Waste Solenoid Designed To Suit 1/2" Inlet Caroma 102115 or HepVo Angle Mounting Not Supplied Strip Side Elevation Australia’s Finest Stainless | britex.com. DDR2 & DDR2-R Installation Guide | QID 1.24 | Rev 2 | 15 Jun 2023...
- Page 6 The flow regulator screw may Rate of flow inadequate adjust flow regulating screw as not be adjusted correctly described above Australia’s Finest Stainless | britex.com. DDR2 & DDR2-R Installation Guide | QID 1.24 | Rev 2 | 15 Jun 2023...
-
Page 7: Spare Parts
74-08-0106 Pressure Relief Valve Battery for Electronic Piezo Button TW-BF-HF CWU-INT Drink Safe™ Fixed Spout Refrigerated Chiller Unit Bottle Filler Australia’s Finest Stainless | britex.com. DDR2 & DDR2-R Installation Guide | QID 1.24 | Rev 2 | 15 Jun 2023... - Page 8 The cover itself should be wiped over with a damp cloth. • When servicing/cleaning the unit please be aware that the unit is pressurised and contains gas. Australia’s Finest Stainless | britex.com. DDR2 & DDR2-R Installation Guide | QID 1.24 | Rev 2 | 15 Jun 2023...
-
Page 9: Care And Maintenance
Once all dirt, oil and grime is removed, rinse thoroughly with clean water and wipe dry. Australia’s Finest Stainless | britex.com. DDR2 & DDR2-R Installation Guide | QID 1.24 | Rev 2 | 15 Jun 2023... -
Page 10: Warranty
By purchasing our product, you agree to these terms and conditions. We appreciate your business and look forward to providing you with high- quality products and services. Australia’s Finest Stainless | britex.com. DDR2 & DDR2-R Installation Guide | QID 1.24 | Rev 2 | 15 Jun 2023... - Page 11 Australia’s Finest Stainless | britex.com. DDR2 & DDR2-R Installation Guide | QID 1.24 | Rev 2 | 15 Jun 2023...
- Page 12 (02) 9531 2100 t (08) 9249 5464 t (07) 3363 2400 t 1300 764 744 e vic@britex.com.au e nsw@britex.com.au e wa@britex.com.au e qld@britex.com.au e sa@britex.com.au DDR2 & DDR2-R Installation Guide | QID 1.24 | Rev 2 | 15 Jun 2023...
Need help?
Do you have a question about the DDR2 and is the answer not in the manual?
Questions and answers
