DSS-H | DSS-H2 | DSSR-H DSSR-H2
Square with Foot Activated
Bubbler Drinking Fountain
with optional Bottle Filler and Refrigeration model
Installation
Guide
MELBOURNE
SYDNEY
Britex Place Mirra Crt
16 Northumberland Drv
Bundoora VIC 3083
Taren Point NSW 2229
t (03) 9466 9000
t (02) 9531 2100
e vic@britex.com.au
e nsw@britex.com.au
DSS-H, DSS-H2, DSSR-H & DSSR-H2 Installation Guide | QID 2.6 | Rev 3 | 18 Oct 2023
