USER MANUAL
Monitor Slider
01/02
PARTS AND TOOLS
×1 PCE
A
B
×4 PCS
C
×4 PCS
D
×4 PCS
To mount your flat panel monitor or any parts at an
ergonomically correct position, start at step 1 and
continue as directed.
CAUTION
•Before assembling, please check assembly guide thoroughly to avoid any mistake.
•4006000102: 4006060601 :Weight capacity :3.5-5.5kg LCD monitors.
•4006000101: 4006000201: Weight capacity :5-7kg LCD monitors.
•Standard products include several small parts, keep out of children when assemble this
product and prevent children from swallowing them.
4006000102
ART. NO
4006000101
4006000202
4006000201
1
STEP 1
75MM × 75MM
100MM × 100MM
VESA INTERFACE
FORMINGFUNCTION.SE
Advertisement
Related Manuals for FORMING FUNCTION Monitor Slider 01
Summary of Contents for FORMING FUNCTION Monitor Slider 01
- Page 1 4006000102 USER MANUAL ART. NO 4006000101 4006000202 4006000201 STEP 1 Monitor Slider 01/02 PARTS AND TOOLS ×1 PCE ×4 PCS ×4 PCS ×4 PCS To mount your flat panel monitor or any parts at an ergonomically correct position, start at step 1 and continue as directed.
