USER MANUAL
Hold Monitor Arm
PARTS AND TOOLS
×2 PCS
A1
A2
×2 PCS
×2 PCS
M6x12
B1
B2
×2 PCS
M6x14
B3
×2 PCS
M6x18
C
×1 PCE
4mm
D
×1 PCE
M4x10
E
×4 PCS
×4 PCS
M4x15
F
G
×4 PCS
4481001602
4481001702
CAUTION
•Standard product fit VESA interface 75*75mm and 100*100mm.
•Before assembling, please check assembly guide thoroughly to avoid any mistake.
•4481001602:Weight capacity for 1~6kg LCD monitors.
•4481001702: 4481001802: 4481001801 Weight capacity for 1 ~8kg LCD monitors.
•Standard products include several small parts, keep out of children when assembling
this product and prevent children from swallowing them.
•Do not put your fingers on the joint while moving the arm to prevent clipping.
4481001602
ART. NO
4481001702
4481001802
4481001801
16/17/18
4481001802
4481001801
UNIFORM RAIL
A1
B2
1
F PROFILE
A2
B2
OTHER POSSIBLE ASSEMBLIES
A2
B3
A1
C
C
A2
A2
B1
B3
FORMINGFUNCTION.SE
B2
A2
B2
Advertisement
Related Manuals for FORMING FUNCTION Hold Monitor Arm 16
Summary of Contents for FORMING FUNCTION Hold Monitor Arm 16
- Page 1 USER MANUAL 4481001602 ART. NO 4481001702 4481001802 4481001801 UNIFORM RAIL Hold Monitor Arm 16/17/18 PARTS AND TOOLS ×2 PCS ×2 PCS ×2 PCS M6x12 ×2 PCS M6x14 ×2 PCS M6x18 ×1 PCE F PROFILE ×1 PCE M4x10 ×4 PCS ×4 PCS M4x15 ×4 PCS OTHER POSSIBLE ASSEMBLIES...
