Summary of Contents for BZB Gear BG-UHD-VWP-1X4
- Page 1 BG-UHD-VWP-1X4 4K 1x4 Video Wall Processor User Manual...
-
Page 2: Table Of Contents
However, like all electronic equipment, the BG-UHD-VWP-1X4 should be used with care. Please read and follow the safety instructions to protect yourself from possible injury and to minimize the risk of damage to the unit. -
Page 3: Introduction
Virtually any setups for the display layout can be possible by the control software. The BG-UHD-VWP-1X4 allows user to input HDMI/ DisplayPort up to 4K2K@60Hz 4:4:4. And the embedded scaler converts signals from HDMI/ DisplayPort source to match the native resolution of monitors, flat panel displays, projectors as well as user-selectable output settings up to WUXGA (1920x1200). -
Page 4: Specifications
SPECIFICATIONS Model Name BG-UHD-VWP-1X4 Technical Role of usage Video Wall Processor HDCP compliance Input – Single link 600MHz [18Gbps] Video bandwidth Output –Single-link 225MHz [6.75Gbps] Input - 4K2K@60 (4:2:2 8bits) / 4K2K@60 (4:4:4 8bits) Video support Output – 1920x1080@60 / 1920x1200@60... -
Page 5: Hardware Installation
HARDWARE INSTALLATION BG-UHD-VWP-1X4 as master 1. Connect the sources to HDMI / DisplayPort Input of the BG-UHD-VWP-1X4. 2. Connect all displays to HDMI Outputs of the BG-UHD-VWP-1X4. 3. Connect the +12V DC power supply to the BG-UHD-VWP-1X4 CONNECTION DIAGRAM... -
Page 6: Panel Descriptions
PANEL DESCRIPTIONS Front Panel LED indicator: PWR – Power indicator LED LOCK – When device status is locked, it will shine 4K – If source resolution is 4K, the LED indicator will shine Source – When source from HDMI, the LED indicator will shine Source from DisplayPort, the LED indicator will blink IR SENSOR: IR sensor for receiving the IR commands from IR remote Control buttons:... -
Page 7: Supported Resolution
SUPPORTED RESOLUTION Input resolution Output resolution 720x480@60Hz 640x480@60Hz 720x576@50Hz 720x480@60Hz 1280x720@60Hz 720x576@60Hz 1920x1080@30Hz 800x600@60Hz 1920x1080@60Hz 1024x768@60Hz 4K2K@30Hz 1280x720@60Hz 4K2K@60Hz (4:2:2 8bits) 1280x768@60Hz 4K2K@60Hz (4:4:4 8bits) 1280x960@60Hz 1280x1024@60Hz 1366x768@60Hz 1440x900@60Hz 1680x1050@60Hz 1920x1080@60Hz 1920x1200@60Hz 1600x1200@60Hz... -
Page 8: Operation Approach
OPERATION APPROACH Method A: IR Remote Control Button Function Display device status (IN/OUT Resolution, INFO EDID, Layout) MUTE Turn off the stereo audio output POWER Power ON/OFF the video wall processor Fast switch to VW1x1 (Full Screen) SOURCE Source setting (HDMI or DisplayPort) Fast switch to VW3x1 (+90°) Fast switch to VW2x2 Fast switch to VW4x1 (-90°) - Page 9 Method B: Software Operation System Requirement and Precautions 1. Whenever power off BG-UHD-VWP-1X4, please stay unpowered at least 5 to 10 seconds to allow power capacitors to discharge. 2. The BG-UHD-VWP-1X4 provides software control program which runs under Microsoft Windows 7, 8.1, 10 through the interface of USB virtual com control.
- Page 10 Control Interface Connection Status: Show the connect information and status. If you use USB control Mode to connect device, the graph . For IP control, the graph of Ethernet is Quick Selection: *Quick Selection function is not available when the input resolution is 4K2K@60Hz In this part, you can set up the screen resolution, screen coordinate and split screen.
- Page 11 ➢ Output Selection and Resolution: (1) Step 1: check input resolution and choose output resolution Set the output resolution. You can choose the design display icon to select the output port and setup resolution. When setting the different resolution, the coordinate of output will also be changed.
- Page 12 (3) Step 2-1: quick selection If you choose the Quick Selection mode in step 2, this window will automatically pop up. In this mode, you can select default screen split and rotate screen (rotate screen only at 1080p resolution). ➢ 3x1: This mode will divide the screen into 3 parts and rotate the figure.
- Page 13 (5) Step 2-3: custom define In Custom define mode, you can define how to cut in both directions and the part you want to show on output TV. If you want to understand or estimate which part you may select, you can select the Grid button to show grid on the graph.
- Page 14 EDID (Extended Display Identification Data) (1) Learn EDID from the default ➢ Select Default EDID (1-5 default EDID). ➢ Click button to learn default EDID. (2) Learn EDID from Display ➢ Select the Output. ➢ Click button to learn display EDID. (3) Learn EDID from File ➢...
- Page 15 Advanced Setting (1) Machine Name You can set up your machine name in here. Please take a closer look at the length of string (Max Length: 8). (2) Change Graph You can change the default graph (splash screen) on this machine. ➢...
- Page 16 4K2K Setting When input is 4K2K@60Hz Resolution, the output display will be forced to 2x2 layout (other layout cannot set) and only can set up the output position. We also provide 8 preset spaces to save the frequently used scenarios into the device. Cloud setting-Association Code button to get an “association code”.
- Page 17 Info Read the software and firmware version. Refresh This function not only can refresh the information of setting but also can reconnect this device. You button to update the control connection. A “ReConnectForm” window will pop can click up for you to select the approach to connect this device. Method C: Firmware Update through mini-USB Port 1.
- Page 18 Method D: Cloud Control (IntriCloud) through Ethernet Port Create Account The first time to use the IntriCloud service, please create a new account. 1. Access IntriCloud (http://www.intri.cloud) and click “Create new account”. 2. The Registration page will pop up and please fill in your email and password information to create your private account.
- Page 19 Add Device to IntriCloud 1. Firstly, please make sure the device is connected to the Ethernet. Then please executing the software with device to get the association code (Note: the status of software is connected). 2. Access IntriCloud (http://www.intri.cloud), and then log in your account on the right top corner. Click Add device to add the device which you just got its association code.
- Page 20 After adding the device, the list of devices related to your account will show on the right top corner. You can click the button to switch device for control.
-
Page 21: Edid Learning
EDID LEARNING The EDID learning function is only necessary whenever you encounter any display on the HDMI output port that cannot play audio and video properly. Because the HDMI sources and displays may have various level of capability in playing audio and video, the general principle is that the source will output the lowest standards in terms of audio format and video resolutions to be commonly acceptable among all HDMI displays. -
Page 22: Warranty
WARRANTY The SELLER warrants the BG-UHD-VWP-1X4 4K 1x4 Video Wall Processor is free from defects in the material and workmanship for 1 year from the date of purchase from the SELLER or an authorized dealer. Should this product fail to be in good working order within 1 year warranty period, The SELLER, at its option, repair or replace the unit, provided that the unit has not been subjected to accident, disaster, abuse or any unauthorized modifications including static discharge and power surge. - Page 23 SECOND YEAR ASSURANCE BZB Gear wants to assure you peace of mind. We're so confident in the quality of our products that along with the manufacturer's one-year limited warranty, we are offering free second-year warranty coverage upon registration*. Taking advantage of this program is simple, just follow the steps below: 1.
