LX WP Series Instruction Manual

Installation diagram
71
2FBT
140
170
202
max Hmax
Q
Model
(L/min) (m)
WP200-I 620 14
WP250-I 670 16
WP300-I 730 18
WP200-II 620 14
WP250-II 670 16
WP300-II 730 18
Remark:WP200-II WP250-II & WP300-II with 2 speed
V/Hz esp: See pump nameplate. liquid temperature:4 C ~ 50 C
o o
Storage temperature: -10 C ~ +50 C. Relative Air Humidity:95% Max.
71
125 195
L
Power(P )
1
L
HP
kW
1.50 2.0 414
1.85 2.5 414
2.20 3.0 414
(Low speed) 0.35 3/8
431
(high speed) 1.50
2.0
(Low speed) 0.40
1/2
431
(high speed)1.85
2.5
(Low speed) 0.45
5/8
431
(high speed)2.20 3.0
o o
Edition :2007-05 2
-4-
IMPORTANT SAFETY INSTRUCTIONS
When installing and using this electrical equipment, basic safety
precautions should always be followed, including the following:
1.READ AND FOLLOW ALL
INSTRUCTIONS
2.WARNING To reduce the risk of injury.
do not permit children to use this product
unless they are closely supervised at all
times.
3.WARNING Risk of Electrical Shock.
Connected only to grounding type rece-
ptacle protected by a ground fault circuit
interrupter(GFCI). Contact a qualified
electrician if you cannot verify that the
receptacle is protected by GFCI.
4.CAUTION Do not bury cord. Locate
cord to minimize abuse from lawnmowers,
hedge trimmers, and other equipment.
5.CAUTION In case the running
parts will injure people, don't make
the electric pump running before then
pipeline have been connected.
6.WARNING To reduce the risk of
electrical shock, replace damaged
cord immediately.
1.General
These instructions are for correct installation, and optimum performance of the Bath pumps, so they should be
read carefully. These are single-stage centrifugal pumps designed to operate with compact hydromassage
equipment, They are equipped with a total-emptying system to prevent the discharge of residual liquid in each
stopping.
These units are designed to operate with clean water at a maximum water temperature of 50 C.
Built of top quality materials, they are subjected to strict hydraulic and electrical controls and are carefully verified.
Correct installation is ensured by following these instructions and those of the wiring diagram; otherwise, over
loads may be produced in the motor. We decline responsibility for any damage caused by not following these
instructions. .
POOL AND SPA PUMP
INSTRUCTION MANUAL
WP SERIES PUMPS
7.WARNING To reduce the risk of
electrical shock, do not use extension
cord to connect unit electric supply;
a properly located outlet.
provide
8.CAUTION Jetpump for jetted bathtubs,
spapools, swimmingpools, massage
stations, cleaning system.
9 Do not install within an outer encl- .
osure or beneath the skirt of a hot tub
unless so marked.
10. T his appliance is not intended for use
by young children or infirm persons unless
they have been adequately supervised by
a responsible person to ensure that they
can use the appliance safely.
11. Young children should be supervi-
sed to ensure that they do not play with
the appliance.
12.FOR INDOOR USE ONLY.
13.SAVE THESE INSTRUCTIONS
-1-
