Sencor SWS 8600 SH User Manual

Sencor SWS 8600 SH User Manual

Smart multi-channel thermo-hygrometer with wireless sensor
Hide thumbs Also See for SWS 8600 SH:
Table of Contents

Advertisement

Quick Links

Download this manual
*Smart phone not included
*Chytrý telefon není součástí příslušenství
* Smartfón nie je súčasťou príslušenstva
*Az okostelefon nem tartozék
*Smartfon nie stanowi elementu akcesoriów
EN
User Manual
CZ
Uživatelská příručka
SK
Používateľská príručka
HU
Felhasználói kézikönyv
PL
Podręcznik użytkownika
Smart multi-channel thermo-hygrometer with
wireless sensor
Chytrý vícekanálový teploměr-vlhkoměr
s bezdrátovým snímačem
Inteligentný viackanálový teplomer–vlhkomer
s bezdrôtovým snímačom
Intelligens többcsatornás hőmérő és páratartalom
mérő vezeték nélküli érzékelővel
Inteligentny wielokanałowy termometr-
wilgotnościomierz z czujnikiem bezprzewodowym
SWS 8600 SH

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SWS 8600 SH and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sencor SWS 8600 SH

Summary of Contents for Sencor SWS 8600 SH

  • Page 1 SWS 8600 SH *Smart phone not included *Chytrý telefon není součástí příslušenství * Smartfón nie je súčasťou príslušenstva *Az okostelefon nem tartozék *Smartfon nie stanowi elementu akcesoriów User Manual Smart multi-channel thermo-hygrometer with wireless sensor Uživatelská příručka Chytrý vícekanálový teploměr-vlhkoměr s bezdrátovým snímačem...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS PRECAUTIONS ............................INTRODUCTION ............................OVERVIEW ..............................CONSOLE ............................4 LCD DISPLAY ............................5 WIRELESS THERMO-HYGRO SENSOR ...................5 INSTALLATION AND SETUP ........................INSTALL WIRELESS THERMO-HYGRO SENSOR ................6 SETUP THE CONSOLE ........................7 ADDITIONAL WIRELESS SENSOR(S) (OPTIONAL) .................8 OTHER SETTING & FUNCTIONS OF THE CONSOLE ................MANUAL CLOCK SETTING ........................8 SETTING ALARM TIME ........................9 ACTIVATING ALARM FUNCTION .......................9...

  • Page 3: Introduction

    Technical specifications and user manual contents for this product are subject to change without notice. This product is not to be used for medical purposes or for public information Do not subject the unit to excessive force, shock, dust, temperature or humidity. Do not cover the ventilation holes with any items such as newspapers, curtains etc.

  • Page 4: Overview

    This system come with a wireless thermo-hygro sensor and can support up to 7 additional sensors(optional). User can monitor and set multi trigger task to control other Tuya compatible device(s) according to the specific condition(s). The colorful LCD display shows the readings clearly and tidy, this system is a truly IoT system for you and your home.

  • Page 5: Lcd Display

    LCD DISPLAY 1. Time & Date 2. Temperature & humidity 3. Indoor temperature & humidity WIRELESS THERMO-HYGRO SENSOR 1. Transmission status LED 2. Wall mounting holder 3. [CHANNEL] slide switch to assign the sensor to Channel 1,2,3,4,5,6 or 7 4. [RESET] key 5.

  • Page 6: Installation And Setup

    INSTALLATION AND SETUP INSTALL WIRELESS THERMO-HYGRO SENSOR 1. Remove the battery door of the sensor. 2. Use the channel slide switch to set the channel number for the sensor (e.g. Channel 1) 3. Insert 2 × AA size batteries into the battery compartment according to the polarity marked on the battery compartment, and close the battery door.

  • Page 7: Setup The Console

    SETUP THE CONSOLE INSTALL THE BACKUP BATTERY Backup battery provides power to the console to retain clock time and date, max/min records and calibration value. Step 1 Step 2 Step 3 Remove the console battery door Insert a new CR2032 button cell Replace the battery door.

  • Page 8: Additional Wireless Sensor(S) (Optional)

    RESET AND FACTORY HARD RESET To reset the console and start again, press the [RESET] key once or remove the backup battery and then unplug the adapter. To resume factory settings and remove all data, press and hold the [RESET] key for 6 seconds. CHANGING BATTERIES AND MANUAL PAIRING OF SENSOR Whenever you changed the batteries of the wireless sensor, re-synchronization must be done manually.

  • Page 9: Setting Alarm Time

    1. In normal mode, press and hold [TIME SET] key for 2 seconds to enter setting. 2. The setting sequence: 12/24 hour format  Hour  Minute  Year  M-D/D-M format  Month  Day  Time sync ON/OFF  weekday Language. 3.

  • Page 10: Wireless Sensor Signal Receiving

    WIRELESS SENSOR SIGNAL RECEIVING 1. The console display signal strength for the wireless sensor(s), as per table below: Signal strength of wireless sensor channel No signal Weak signal Good signal 2. If the signal has discontinued and does not recover within 15 minutes, the signal icon will disappear.

  • Page 11: To View Max / Min

    MAX / MIN DATA RECORD The console can record MAX / MIN readings both daily and since last reset. Daily MAX reading Daily MIN reading MAX reading since MIN reading since last reset last reset TO VIEW MAX / MIN 1.

  • Page 12: Back Light

    BACK LIGHT The main unit back light can be adjusted, using the [HI / LO] sliding switch to select the appropriate brightness: Slide to the [HI] position for the brighter back light. Slide to the [LO] position for the dimmer back light. SET LCD DISPLAY CONTRAST In normal mode, press [ / CAL] key to adjust LCD contrast for best viewing on table stand or wall mounted.

  • Page 13: Specification

    WI-FI Communication Specification Standard 802.11 b/g/n Operating frequency: 2.4GHz Supported router security WPA/WPA2, OPEN, WEP (WEP only support Hexadecimal type password) APP Specification Sencor HOME Support App Tuya Smart, Smart Life Android smart phone Supported platform of App iPhone EN – 13...

  • Page 14: Wireless Thermo-Hygro Sensor

    WIRELESS THERMO-HYGRO SENSOR Dimensions (W × H × D) 58 × 125 × 19 mm (2.3 × 4.9 × 0.7in) Weight 144g (with Batteries) 2 × AA size 1.5V batteries Main power (Alkaline batteries recommended) Weather data Temperature and Humidity RF transmission range 150m (492 feet) straight distance RF frequency...
  • Page 15 This product complies with EU requirements. FAST ČR, a. s. hereby declares that the radio device type SWS 8600 SH complies with Directive 2014/53/EU. For full version of the EU declaration of conformity, please refer to the website: www.sencor.com...
  • Page 16 Manufacturer: FAST ČR, a.s., U Sanitasu 1621, Říčany 251 01, Czech Republic Visit www.sencor.com for detailed information about authorized service centers. The original version of the instructions is in the Czech language, other language versions are made by the appropriate translation.
