GenConnex GXK-LPNG-EU7000is-EC5.0 Assembly Instructions

Genconnex
35 Pond Park Road, Hingham, MA 02043
support@genconnex.net
Disassembly
tep 1a - Remove fuel pump cover & left side door Disconnect fuel pump
a- Remove # 0mm side a-2 Pull back rubber gasket
bolt holding corner cover on and remove 2 # 0mm nuts
then pull up and remove
corner cover.
tep 1b - Remove fuel tank (U E CAUTION A
b- Disconnect gas tank vent tube
b-2/3 Gently twist tank vent tube and insert into forward
from underneath side of gas tank. No
hole on backside of door latch for safe keeping. This will
fuel should spill doing this. NOTE: pry
only be needed if you switch back to gasoline.
down from top vs pulling so as not to
rip tube.
tep 1c - Disconnect gasoline fuel injector and remove upper airbox
c- Unplug gasoline fuel injector wire harness
connector. This will prevent the gasoline fuel
injector from getting damaged by "dry firing" while
using alternate fuels. Tuck connector in behind
throttle body to keep it from bouncing around.
tep 1d - Remove air cleaner box outer and inner half for re-installation later
d- Unlatch the air cleaner cover in two
places then pull out with air cleaner filter.
Propane is a combustible fuel. It should be kept outdoors at all times, If you suspect a leak in you generator or
any hoses / connections, you should immediately turn off the fuel at the tank then test connections with soapy
water. Do not attempt to use any components including hoses that have leaks. Replace them immediately.
®
https://genconnexdirect.net/Liturature/Installation/EU7000is_Kit_r5.02_EC.pdf
Step 1
a-3 Lift off door to gain access to air
cleaner side of generator (left side
when looking at front)
c-2 Remove air box cover by prying
up on 4 corner clips. TIP: Remove
lower air filter cover just below air box
for better access to bottom two clips.
The outer cover and clips are not
used anymore.
d-2 Remove 4 fasteners (3 bolts and one
nut) holding the air cleaner back half onto
engine and save for later.
Genconnex ®
Copyright 2024 New England Gen-Connect LLC. All rights reserved.
Online PDF
a-4/5/6/7 Disconnect electrical connector for fuel pump by pressing tab. Then disconnect fuel line fitting from fuel
pump by pushing down on yellow tab then pushing in fuel hose quick fitting, then pull out fitting (pushing in first
makes release easier). Catch small amount of any remaining gasoline with small rag and use supplied caps to
seal both ends. Push round end in first.
IT TILL MAY CONTAIN
b-4/5 Locate and remove four # 0mm corner bolts with washers
then disconnect gas line from white clip on fuel pump bracket.
c-3 Remove the two nuts
holding on inner air box and
discard. New standoff nut will
be put in their place.
d-3 Remove the gray tube from its two holding
tabs, then remove the fuel line from its white
plastic clip, then pull the air cleaner back half
directly towards you to free it from the one
bottom right threaded stud (arrow). There will
be some resistance because the far right side
of the housing is still inserted into the front
bulkhead.
WARNING:
ngineered to the next level.
Genconnex
EFI Propane & Natural Gas kit
Assembly instructions
Version 5.02
#2 Phillips head screw driver
# 0mm box end wrench
flat head screw driver
0mm socket
+
spark plug socket
needle nose pliers or channel locks
socket extension
socket U joint (optional)
OME FUEL)
b-6 Lift back edge of tank - pull back, up and
away from back of unit to clear front frame bracket.
TIP lift up pull starter side of lid above black handle
as you are pulling back.
c-4/5 Remove inner upper airbox by rotating plastic away
from studs then remove from unit. NOTE if the steel standoffs
stay on the bolts you will need to remove them and put them
back into the plastic housing as shown
d-4 Once you get the back half of the
air cleaner housing free of the threaded
stud, carefully pull the left side out of the
cabinet first. Note the fuel line tends to
catch on the rubber coupler circled in
the picture.
® Honda EU7000is
d-5 Remove the three bolts
holding the air cleaner support
bracket in place and remove the
bracket. Note it will help to keep
the bolts in the holes they came
from while the bracket is off.
