macc SPECIAL 391 SVG Instruction Manual

Band saw for ferrous metals
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SEGATRICE A NASTRO PER METALLI FERROSI
BAND SAW FOR FERROUS METALS
BANDSAEGEMASCHINE FÜR EISENMETALLE
SCIE A RUBAN POUR METAUX FERREUX
SIERRA DE CINTA PARA METALES FERROSOS
ЛЕНТОЧНЫЙ РАСПИЛОВОЧНЫЙ СТАНОК ДЛЯ МЕТАЛЛОВ
MANUALE DI ISTRUZIONI PER L'USO - INSTRUCTION MANUAL FOR OPERATION
BETRIEBSANLEITUNG
-
MANUEL D'INSTRUCTIONS POUR L'EMPLOI
MANUAL DE INSTRUCCIONES DE USO
РУКОВОДСТВО ПО ЭКСПЛУАТАЦИИ И ТЕХОБСЛУЖИВАНИЮ
COSTRUTTORE:
MANUFACTURER:
MACC s.r.l. SCHIO ( VI ) - ITALY
ERBAUER:
CONSTRUCTEUR:
CONSTRUCTOR:
ИЗГОТОВИТЕЛЬ:
MODELLO:
MODEL:
MODELL:
SPECIAL 391 SVG
MODELE:
MODELO:
МОДЕЛЬ:
MATRICOLA:
SERIAL NUMBER:
KENNNUMMER:
MATRICULE:
MATRICULA:
СЕРИЙНЫЙ НОМЕР:
ANNO DI COSTRUZIONE:
YEAR OF CONSTRUCTION:
2023
BAUJAHR:
ANNEE DE CONSTRUCTION:
AÑO DE COSTRUCCION:
ГОД ИЗГОТОВЛЕНИЯ:

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SPECIAL 391 SVG and is the answer not in the manual?

Questions and answers

Related Manuals for macc SPECIAL 391 SVG

Summary of Contents for macc SPECIAL 391 SVG

  • Page 1 MANUALE DI ISTRUZIONI PER L’USO - INSTRUCTION MANUAL FOR OPERATION BETRIEBSANLEITUNG MANUEL D'INSTRUCTIONS POUR L'EMPLOI MANUAL DE INSTRUCCIONES DE USO РУКОВОДСТВО ПО ЭКСПЛУАТАЦИИ И ТЕХОБСЛУЖИВАНИЮ COSTRUTTORE: MANUFACTURER: MACC s.r.l. SCHIO ( VI ) - ITALY ERBAUER: CONSTRUCTEUR: CONSTRUCTOR: ИЗГОТОВИТЕЛЬ: MODELLO: MODEL:...
  • Page 3 техническую документацию Macc Costruzioni Meccaniche s.r.l. MACC Costruzioni Meccaniche s.r.l. - Via Lago di Albano, 10 – 36015 Schio (VI) Italy Tel.: 0445/575005 Fax: 0445/575006 Nome del Rappresentante Legale - Name of the Legal Representative - Name des Gesetzlichen Vertreters Nom du Représentant Légal - Apellido del Representante Legal - Фамилия, имя...
  • Page 5 E' SEVERAMENTE VIETATO UTILIZZARE LA MACCHINA SENZA LIQUIDO DI TAGLIO. IT IS STRICTLY FORBIDDEN TO USE THE MACHINE WITHOUT CUTTING FLUID. ES IST STRENG VERBOTEN, DIE MASCHINE OHNE SCHNEIDFLÜSSIGKEIT IN BETRIEB ZU NEHMEN. IL EST SEVEREMENT INTERDIT D’UTILISER LA MACHINE SANS LIQUIDE DE COUPE.
  • Page 7 SISTEMA DI MICROLUBRIFICAZIONE: SE INSTALLATO SULLA MACCHINA, È OBBLIGATORIO L’USO DI MASCHERINA PROTETTIVA DELLE VIE AEREE. SI CONSIGLIA DI MANTENERE AREATO IL LOCALE. MICRO-LUBRICATION SYSTEM: IF INSTALLED ON THE MACHINE, THE USE OF PPE (AIRWAYS PROTECTION MASK) IS NECESSARY. KEEP THE PLACE AERATED. MIKRODOSIERGERÄT: FÜR MASCHINEN MIT MIKRODOSIERGERÄT IST ES STRIKT ERFORDERLICH EINE ATEMMASKE ZUM SCHUTZ DER ATEMWEGE ZU TRAGEN.

  • Page 11: Table Of Contents

    MACC S.r.l. products are guaranteed against material and manufacturing defects for a period of 12 months from the date of delivery or , if the machine is installed by MACC employees , from the date of machine start up . The buyer is only entitled to the replacement of parts which are acknowledged as faulty : carriage and packing are at the buyer's expense .

  • Page 12: Index Of Chapters , Drawings , Diagrams And Tables

    4.2 DESCRIPTION OF THE MACHINE AND ITS COMPONENTS The SPECIAL 391 SVG band sawing machine produced by MACC has a sturdy frame made from welded and painted sheet- steel . The upper surface is designed to allow the complete draining away of the cutting fluid . The band support bow is made in cast iron , with a suitable dimension to provide the necessary stiffness and precision to the cutting unit .

  • Page 13: Intended And Unsuitable Uses Of The Machine

    4.3 INTENDED AND UNSUITABLE USES OF THE MACHINE The SPECIAL 391 SVG band sawing machine has been designed and built to cut bars , structural steel and ferrous metal pipes in accordance with the instructions contained in this manual . Therefore , the cutting of other materials is not permitted : if the above recommendations are not observed , the machine could be damaged and the health and safety of the operator put at risk .

  • Page 14: Tools Supplied

    8.2 TOOLS SUPPLIED no. 1 hexagonal bar wrench ( 3 ) no. 1 hexagonal bar wrench ( 5 ) no. 1 hexagonal bar wrench ( 6 ) no. 1 hexagonal bar wrench ( 8 ) no. 1 hexagonal bar wrench ( 10 ) 8.3 OPERATION CHECKS TO CARRY OUT BEFORE EACH CUT A.

  • Page 15: Special Safety Checks

    RESET button motorized cooling pump ON-OFF button bow up button START button bow low limit memorization button bow down button RESET button warning light motorized cooling pump button warning light START button warning light bow bottom limit setting key warning light Descent regulator Change-over switch emergency button...

  • Page 16: Safety , Guidance , Notice Labels On The Machine

    Safety , Guidance , Notice Labels on the Machine 9. MAINTENANCE AND REPAIRS 9.1 GENERAL SAFETY MEASURES A. Lockable main switch . Use the padlock in the event of machine failure or replacement of the band . The padlock key should be entrusted to a responsible person . B.

  • Page 17: Information Regarding Environmental Noise

    -Check the exact alignment of the blade guides , with the mobile one in different positions ( act on the grains ) . INFORMATION REGARDING ENVIRONMENTAL NOISE An environmental noise test carried out on the SPECIAL 391 SVG band saw machine , identical to the machine to which these operation instructions refer , has given the following results : ACOUSTIC RADIATION PRESSURE 1.
  • Page 18 12. LIST OF SPARE PARTS Allegato / Encl. 3 Pos./Cod. DENOMINATION Q.tà 001/44 Base 002-B/35 Positioning pin 002/44 Electrical box door 003/44 Chips tank 004/44 Cooling tank 008/44 Counter-vice bracket 009/44 Small lateral grate 019/44 Drainage slide 034/35 Bench lever hub 076/11 Handwheel 6L M8 Female 082/14...
  • Page 19 Allegato / Encl. 6 005/44 Rotating arm 006/44 Front column 007/44 Front column guard 011/44 Rotating bank floor 012/44 Countervice 013/44 Countervice left jaw 014/44 Countervice right jaw 015/44 Vice jaw 016/44 Countervice cylinder support 017/44 Countervice pin 027/04 Bank lever nut 028/36 Bank lever Hexagon grub screw UNI-5929 DIN-916 M8...
  • Page 20 Allegato / Encl. 10 Pos. DENOMINATION Brand Code Q.ty Solenoid valve DHI.0711.23 - 24VDC ATOS 351/90 Plug TP1.02600 Block solenoid valve 074-C/90 Cube BL41 Manometer 0/100 A.R. ø63 ITALMANOMETRI 164/36 Excluder FPEA1G1/4B FLUID PRESS Pump N1031083 MARZOCCHI Motor 0.55kW 4P B5 230/400V 50Hz 220-B/90 Filter FR1.02392 Tank ( to drawing )
  • Page 23 MOVIMENTAZIONE MOVIMENTAZIONE HANDLING AND HANDLING AND MANUTENTION MANUTENTION MOVILIZACION MOVILIZACION HANDHABUNG HANDHABUNG E TRASPORTO E TRASPORTO TRANSPORTATION TRANSPORTATION ET TRANSPORT ET TRANSPORT Y TRANSPÒRTE Y TRANSPÒRTE UND TRANSPORT UND TRANSPORT...
  • Page 24 1300 Basamento 1625 1113 * = PIANO DI LAVORO * = PIANO DI LAVORO WORKING TABLE HEIGHT WORKING TABLE HEIGHT DIMENSIONI DIMENSIONI OVERALL OVERALL DIMENSIONS DIMENSIONS DIMENSIONES DIMENSIONES AUSSENABMESSUNGEN AUSSENABMESSUNGEN MÀXIMAS EXTREMAS MÀXIMAS EXTREMAS D'INGOMBRO ED D'INGOMBRO ED DIMENSION AND DIMENSION AND HORS-TOUT ET HORS-TOUT ET...
  • Page 25 BASE BASE BASAMENTO BASAMENTO BASE BASE BASE BASE SOCKEL SOCKEL...
  • Page 26 ARCO ARCO BOGEN BOGEN ARCO ARCO...
  • Page 27 GUIDALAMA GUIDALAMA BLADE GUIDE BLADE GUIDE GUIDE-LAME GUIDE-LAME SÄGEBLATTFÜHRUNG SÄGEBLATTFÜHRUNG GUÍA-HOJA GUÍA-HOJA...
  • Page 28 007/44 006/44 126/37 014/44 013/44 011/44 012/44 015/44 320/17 016/44 280-09-006-A 005/44 Allegato Colonna posteriore 017/44 028/36 027/04 BENCH BENCH BANK BANK BANCO BANCO BANCO BANCO BANC BANC...
  • Page 29 128-A/37 COLONNA POSTERIORE POSTERIOR COLUMN COLONNE POSTÉRIEURE 136/37 HINTERER STÄNDER COLUMNAS POSTERIOR 117/37 214/37 227/37 211/37 136/37 212/37 101/11 125/37 208/37 216/37 125/37 207/37 COLONNA POST. COLONNA POST. COLUMN COLUMN COLONNE COLONNE HINTERER STÄNDER HINTERER STÄNDER COLUMNAS COLUMNAS...
  • Page 30 121/37 412/95 122/37 119/37 101-A/32 101-A/32 118/37 120/37 412/95 088/50 141/45 LÀMINA LÀMINA SPAZZOLA SPAZZOLA BRUSH BRUSH NETTOYAGE NETTOYAGE REINIGÜNGSBURSTE REINIGÜNGSBURSTE DE LIMPIEZA DE LIMPIEZA KLINGE KLINGE PULISCI LAMA PULISCI LAMA CLEANER BLADE CLEANER BLADE LAME DE BROSSE LAME DE BROSSE DEL CEPILLO DEL CEPILLO...
  • Page 31 087/90 A-A1 B -B1 086/90 053-G/38 098/90 002/90 374/90 087/90 E - E1 085/90 Pulsante RESET Pulsante elettropompa refrigerante ON-OFF Pulsante salita arco Pulsante START Pulsante di memorizzazione limite basso arco Pulsante discesa arco Spia pulsante RESET Spia pulsante elettropompa refrigerante Spia pulsante memorizzazione limite basso arco 100/38 Regolatore velocità...
  • Page 32 087/90 A - A1 B - B1 086/90 053-G/38 098/90 002/90 374/90 087/90 E - E1 085/90 Pulsante RESET Pulsante elettropompa refrigerante ON-OFF Pulsante salita arco Pulsante START Pulsante di memorizzazione limite basso arco Pulsante discesa arco Spia pulsante RESET Spia pulsante elettropompa refrigerante Spia pulsante memorizzazione limite basso arco 100/38...
  • Page 48 07/05/2020 CONTROLLATO IL: REV.: SPECIAL 391 SVG...
