macc SPECIAL 320 MS Instruction Manual

Band saw for ferrous metals
Hide thumbs
Table of Contents

Advertisement

Quick Links

SEGATRICE A NASTRO PER METALLI FERROSI
BAND SAW FOR FERROUS METALS
BANDSAEGEMASCHINE FÜR EISENMETALLE
SCIE A RUBAN POUR METAUX FERREUX
SIERRA DE CINTA PARA METALES FERROSOS
ЛЕНТОЧНЫЙ РАСПИЛОВОЧНЫЙ СТАНОК ДЛЯ МЕТАЛЛОВ
MANUALE DI ISTRUZIONI PER L'USO - INSTRUCTION MANUAL FOR OPERATION
BETRIEBSANLEITUNG
-
MANUEL D'INSTRUCTIONS POUR L'EMPLOI
MANUAL DE INSTRUCCIONES DE USO
РУКОВОДСТВО ПО ЭКСПЛУАТАЦИИ И ТЕХОБСЛУЖИВАНИЮ
COSTRUTTORE:
MANUFACTURER:
MACC s.r.l. SCHIO ( VI ) - ITALY
ERBAUER:
CONSTRUCTEUR:
CONSTRUCTOR:
ИЗГОТОВИТЕЛЬ:
MODELLO:
MODEL:
SPECIAL 320 MS
MODELL:
MODELE:
MODELO:
МОДЕЛЬ:
MATRICOLA:
SERIAL NUMBER:
KENNNUMMER:
MATRICULE:
MATRICULA:
СЕРИЙНЫЙ НОМЕР:
ANNO DI COSTRUZIONE:
YEAR OF CONSTRUCTION:
2023
BAUJAHR:
ANNEE DE CONSTRUCTION:
AÑO DE COSTRUCCION:
ГОД ИЗГОТОВЛЕНИЯ:

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SPECIAL 320 MS and is the answer not in the manual?

Questions and answers

Related Manuals for macc SPECIAL 320 MS

Summary of Contents for macc SPECIAL 320 MS

  • Page 1 MANUALE DI ISTRUZIONI PER L’USO - INSTRUCTION MANUAL FOR OPERATION BETRIEBSANLEITUNG MANUEL D'INSTRUCTIONS POUR L'EMPLOI MANUAL DE INSTRUCCIONES DE USO РУКОВОДСТВО ПО ЭКСПЛУАТАЦИИ И ТЕХОБСЛУЖИВАНИЮ COSTRUTTORE: MANUFACTURER: MACC s.r.l. SCHIO ( VI ) - ITALY ERBAUER: CONSTRUCTEUR: CONSTRUCTOR: ИЗГОТОВИТЕЛЬ: MODELLO: MODEL:...
  • Page 3 техническую документацию Macc Costruzioni Meccaniche s.r.l. MACC Costruzioni Meccaniche s.r.l. - Via Lago di Albano, 10 – 36015 Schio (VI) Italy Tel.: 0445/575005 Fax: 0445/575006 Nome del Rappresentante Legale - Name of the Legal Representative - Name des Gesetzlichen Vertreters Nom du Représentant Légal - Apellido del Representante Legal - Фамилия, имя...
  • Page 5 E' SEVERAMENTE VIETATO UTILIZZARE LA MACCHINA SENZA LIQUIDO DI TAGLIO. IT IS STRICTLY FORBIDDEN TO USE THE MACHINE WITHOUT CUTTING FLUID. ES IST STRENG VERBOTEN, DIE MASCHINE OHNE SCHNEIDFLÜSSIGKEIT IN BETRIEB ZU NEHMEN. IL EST SEVEREMENT INTERDIT D’UTILISER LA MACHINE SANS LIQUIDE DE COUPE.
  • Page 7 SISTEMA DI MICROLUBRIFICAZIONE: SE INSTALLATO SULLA MACCHINA, È OBBLIGATORIO L’USO DI MASCHERINA PROTETTIVA DELLE VIE AEREE. SI CONSIGLIA DI MANTENERE AREATO IL LOCALE. MICRO-LUBRICATION SYSTEM: IF INSTALLED ON THE MACHINE, THE USE OF PPE (AIRWAYS PROTECTION MASK) IS NECESSARY. KEEP THE PLACE AERATED. MIKRODOSIERGERÄT: FÜR MASCHINEN MIT MIKRODOSIERGERÄT IST ES STRIKT ERFORDERLICH EINE ATEMMASKE ZUM SCHUTZ DER ATEMWEGE ZU TRAGEN.

  • Page 11: Table Of Contents

    MACC S.r.l. products are guaranteed against material and manufacturing defects for a period of 12 months from the date of delivery or , if the machine is installed by MACC employees , from the date of machine start up . The buyer is only entitled to the replacement of parts which are acknowledged as faulty : carriage and packing are at the buyer's expense .

  • Page 12: Description Of The Machine

    4.2 DESCRIPTION OF THE MACHINE AND ITS COMPONENTS The SPECIAL 320 M/S band sawing machine produced by MACC has a sturdy frame made from welded and painted sheet- steel . The upper surface is designed to allow the complete draining away of the cutting fluid . The band support bow is made in cast iron , with a suitable dimension to provide the necessary stiffness and precision to the cutting unit .

  • Page 13: Main Technical Data

    The machine should be checked to make sure that it has not been damaged during transportation and handling . If the machine appears to have been damaged , contact MACC immediately . Fit all the supplied accessories onto the machine such as the bar stop 116 and the roller arm 143 ( DRAW.4 ENCL.2 ) .

  • Page 14: Tools Supplied

    Turn the main switch 228 and the changeover switch 203 into the desired speed . Switch on the hydraulic unit by pressing the RESET button of the keyborad MACC 8 , press again the RESET button to bring the bow at the desired up position , by means of the hand wheel 125 place the vice close ( 3-4mm ) to the material to be cut , take hold of the handle 36 located at the end of head lever and press the button to start the manual cutting mode , press the button again to start the manual cutting operation .

  • Page 15: Special Safety Checks

    RESET button motorized cooling pump ON-OFF button bow up button START button bow low limit memorization button bow down button RESET button warning light motorized cooling pump button warning light START button warning light bow bottom limit setting key warning light Descent regulator Change-over switch emergency button...

  • Page 16: Safety , Guidance , Notice Labels On The Machine

    8.7 SAFETY , GUIDANCE , NOTICE LABELS ON THE MACHINE 9. MAINTENANCE AND REPAIRS 9.1 GENERAL SAFETY MEASURES A. Lockable main switch . Use the padlock in the event of machine failure or replacement of the band . The padlock key should be entrusted to a responsible person .

  • Page 17: Information Regarding Environmental Noise

    C. Cleaning of the coolant tank . The coolant tank can be cleaned by simply removing the crucible 104 ( DRAW.12 ENCL.5 ) . Empty the coolant from the tank and collect the coolant in a container for future disposal . Clean away the shavings and the metallic powder , taking care not to scatter this over the machine especially around the motor and the box containing the electrical equipment .
  • Page 18 12. LIST OF SPARE PARTS POS. DESCRIPTION CODE Q.TY 044/38 Bow guard 045-A/38 Bow drip tray 034/38 Washer as drawing ø45 foro12,5 sp.6 040/06 Washer as drawing ø45 foro12,5 sp.6 040-A/06 Band 2825x27x0,9 MAR2450270958 Bow cylinder bracket bushing 070/38 Idle pulley spacer 048/32 Bearing 6207 2RS 103/32...
  • Page 19 Blade guide plate 044/35 Bearing 608 2RS 055/35 Guide blade eccentric bushing 027/35 Rear blade guide 025/35 Fixed guide blade rod 41/40 Rotation pin 108/38 Bearing 32008 XA 072/20 Rotation pin nut 027/38 Potentiometer fixing bush 044-A/41 Potentiometer support 115/38 Bow potentiometer 099/90 Guard potenziometer...
  • Page 20 Hydraulic cylinder 059/38 Vice jaw 032/35 Vice gib 031/03 Roller 076/32 Roller carrier arm 075/35 Big counter vice jaw 066/35 Small counter vice jaw 065/35 Hydraulic unit 074/90 Motor M71 4P 3F kW 0,55 B5 199/80 Bow lowering solenoid valve 351/90 Vice solenoid valve 350/90...
  • Page 47 &21752//$72 ,/ 13 07 SPECIAL 320 MS...
