FREEDOM INNOVATIONS
9
Follow the instructions in the App to adjust resistance settings in the ankle
for plantar flexion, dorsiflexion and toe stiffness. For each re sistance change,
sliding the setting to the left will decrease resistance or stiffness and
sliding the setting to right, will increase resistance or stiffness. Adjust until
optimal setting achieved.
10
Follow next screens to demonstrate Low Battery, Dead Battery mode,
and Manual Lock.
11
The tool bar across the bottom of the screen provides short cuts to the
different functions of the ankle.
For more information, consult the Instructions for Use Manual or call +31 (0)53-20 30 300.
www.freedom-innovations.eu
Freedom Innovations Europe B.V.
Global Headquarters
European Head Office
3 Morgan
Jaargetijdenweg 4
Irvine, CA 92618
7532 SX Enschede
U.S.A.
The Netherlands
Free call: +1 888 818 6777
Tel.: +31 (0) 53 20 30 300
Tel.: +1 949 672 0032
Fax: +31 (0) 53 20 30 305
Fax: +1 949 672 0084
info@freedom-innovations.eu
©2019 Freedom Innovations Europe B.V. All rights reserved. CG-03-010 Rev. A - Kinnex 2.0 Prosthetist Setup Guide, English EU
Setup
Disconnect
Tools
Status
Help
Setup:
Allows prosthetist to go through Full Setup Process, or individually Calibrate, Adjust
resistance settings, or demonstrate to the patient the different modes available
Disconnect: Allows prosthetist to disconnect from ankle or unpair the ankle and disconnect
Tools:
Allows prosthetist to generate cadence report, update firmware or reset to factory defaults
Status:
Shows ankle connected, battery status, total steps, serial number, part number
and firmware version
Help:
Provides contact information for technical support
2.0
Prosthetist
Setup Guide
Alignment and Setup
