Page 1: Instructions For Use
INSTRUCTIONS FOR USE Plié® 2.0 MPC Knee Instructions for Use (R-720-109 Rev. E), English! -
Page 2: Table Of Contents
Table of Contents Product Number: KS2-00-KNEE1-KT/KD2-00-KNEE2-KT Appropriate Use! Symbols Legend! Safety Information! Knee Functions! Technical Data! Plié® 2.0 MPC Knee Specifications! Battery and Battery Charger Specifications! Environmental Specifications! Storage! Water Resistance! Cleaning! Finishing Options! Battery and Power Information! Battery Charging! - Page 3 Plié® 2.0 MPC Knee (images not to scale) Plié® 2.0 MPC Knee Instructions for Use (R-720-109 Rev. E), English!
- Page 4 Recommended Foot Components Plié® 2.0 MPC Knee Instructions for Use (R-720-109 Rev. E), English!
-
Page 5: Appropriate Use
Available Pictured Part Description Part Number Included w/knee Quantity Separately Plié MPC Knee KS2-00-KNEE1-00 Plié® 2.0 MPC Knee, Threaded Top KD2-00-KNEE2-00 ✓ ✓ Wireless USB Adapter KS1-00-BLUE2-00 ✓ Battery Case ✓ ✓ Software CD-ROM KS2-00-SFTW1-00 ✓ ✓ Lithium Ion Battery (w/battery case) KS1-00-BATT1-00 ✓... -
Page 6: Symbols Legend
Symbols Legend The following symbols are found on the Plié® 2.0 MPC Knee: • Attention, refer to Plié® 2.0 MPC Knee Instructions for Use. • Type BF applied part. • Conformité Européene (European conformity). • Federal Communications Commission (USA conformity). •... - Page 7 Plié® 2.0 MPC Knee user prior to use. • The Plié® 2.0 MPC Knee is not field-serviceable and may only be repaired by Freedom Innovations, LLC. Attempts to disassemble, repair, or modify the Plié® 2.0 MPC Knee, including changes to the tension on any of the threaded fasteners, could put the user at risk for serious injury and will void the warranty.
-
Page 8: Knee Functions
Knee Functions The Plié® 2.0 MPC Knee is a single axis prosthetic knee joint system providing microprocessor control of both the swing and stance phases of gait. The microprocessor monitors an embedded load sensor and an angle sensor to precisely control the transitions between the stance and swing phases of gait. Three manual settings allow the hydraulic cylinder to provide adjustable resistance for stance flexion, swing flexion, and swing extension. -
Page 9: Finishing Options
Finishing Options The Plié® 2.0 MPC Knee may be finished with a cosmetic/protective cover. However, the choice of cover material may affect normal knee function. A cover should be modified or not used if it detrimentally affects the knee performance. A discontinuous, two-piece cover is recommended as its impact on knee performance is minimal. !Care should be taken during cover fabrication to ensure the user has adequate access to the battery !compartment and the posterior manual knee settings of the hydraulic cylinder. -
Page 10: Plié 2.0 Control
Figure A Figure B Plié 2.0 Control The Plié 2.0 Control software is necessary for programming Plié® 2.0 MPC Knees (Figure A). The Plié 2.0 Control consists of a main window and four auxiliary windows. The auxiliary windows may be accessed from the main window. - Page 11 Figure C 7. Calibrate - Select Calibrate to establish the reference zero values for the embedded sensors. 8. Wireless Sync - Select Wireless Sync if the software and knee fail to sync (circles remain red). 9. Setting Wizard - Select the Setting Wizard to open the Plié 2.0 Setup Wizard window (Figure B). The Plié 2.0 Setup Wizard includes a sophisticated algorithm designed to optimize the Toe Threshold, Swing Transition, and the advanced Stumble Recovery (Plié...
- Page 12 Figure D Plié 2.0 Real Time Data Display The Plié 2.0 Real Time Data Display allows the viewing of live data as the user ambulates. The Plié 2.0 Real Time Data Display provides a data rate of 4 Hz (4 samples per second). Due to the limited data stream bandwidth (knee microprocessor data rate is 1000 Hz), the Plié...
-
Page 13: Plié Gait Lab
trochanter knee ankle Figure E Figure F Figure G Figure H Figure I Manually adjusting the Additional Parameters is not recommended. If the Setup Mode box is checked, the advanced stumble recovery is not active. The knee should only be in Setup Mode during set-up. Plié... -
Page 14: Alignment
14mm Swing Swing Flexion Stance Stance Flexion 235m 235mm Swing Extension Swing Figure K Figure J The white tabs on the bottom and left frames of the data window allow the data view to be modified. To scroll the data, simultaneously place the cursor between the white tabs, hold the left mouse button, and drag the mouse. -
Page 15: Bench Alignment
Figure L spinal column (Figure H). !During ambulation, an unaccommodated hip flexion contracture may cause an excessively asymmetrical !gait pattern. Bench Alignment The Plié® 2.0 MPC Knee was designed to be in a fully extended position during stance phase for level ground ambulation. -
Page 16: Dynamic Alignment
b. With equal weight on each limb, adjust the height of the prosthesis as necessary. c. Ensure the trochanter-knee-ankle (TKA) alignment follows the recommendations of inherent stability. d. Ensure the transverse rotation of the knee and foot is appropriate. e. Instruct the user to sit in a chair. Adjust the height of the knee joint axis to match the contralateral limb as closely as possible. -
Page 17: Adjust Manual Hydraulic Settings
d. Instruct the user to ambulate. If the knee does not release into swing, lower the Toe Threshold setting in the Plié Control window until the knee releases. e. Select Next to continue. 3. Adjust Manual Hydraulic Settings Adjust the default manual hydraulic settings in the following order to ensure the knee motion is smooth and symmetrical for the user (Figure K). -
Page 18: Document
For the warranty to remain in effect, the knee must be serviced 12 and 24 months after purchase. A loaner knee is provided at the time of knee service. For knee repairs, please contact Freedom Innovations toll-free at 1-888-818-6777. A loaner knee will be provided upon request. For service and/or repair, please ship the knee in the provided shipping case. -
Page 19: Regulatory Compliance, Disclosures, And Classification
Regulatory Compliance, Disclosures, and Classification Wireless Operation Plié® 2.0 MPC Knee Bluetooth Certification QPLN Ref. No.: Q31606_WT11_SGS The Plié® 2.0 MPC Knee complies with the following: • FCC ID AMPCK001 or FCC ID QOQWT11. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
