Wunderlich 41973-001 Manual

Handlebar riser

Advertisement

Quick Links

Lenkererhöhung
handlebar riser | Rehausseur de guidon | Elevador de manillar | Riser del manubrio
41973-001
Art.-Nr:
Legende /
/
Key
file Légende
Schraube
Anbau Tipp
Fitting tip
Screw
Vis
Astuce de montage
Schraubensicherung
Achtung
Thread locking fluid
Attention
Freinfilets
Attention
Vergrößerung
Drehmoment
M
Torque
Magnification
Nm
Grossissement
Torque
Reiniger
Montagepaste
Cleaner
Fitting lubricant
Nettoyant
Lubrifiant de montage
0
10
20
30
40
50
Bauteil
DE
Die Farben der Abbildungen dienen nur der Veranschaulichung.
#
component
EN
The colors are for illustrating purposes only.
composant
FR
Les couleurs utilisées sont à titre indicatif seulement.
1
Zylinderschraube / Cylinder screw M8x75
(Torx)
2
Lenkererhöhung (
/ Handlebar riser (
rechte Seite)
3
Lenkererhöhung
/ Handlebar riser
(linke Seite)
4
Schraubensicherung
Thread locking fluid
/
Die Nr. 1 weltweit für hochwertiges BMW Motorradzubehör.
4
100
60
70
80
90
mm
DIN
ISO
912Z
4762
right side)
(left side)
3
Menge
quantity
quantité
4
1
1
1
1
1
2

Advertisement

loading
Need help?

Need help?

Do you have a question about the 41973-001 and is the answer not in the manual?

Questions and answers

Summary of Contents for Wunderlich 41973-001

  • Page 1 Lenkererhöhung handlebar riser | Rehausseur de guidon | Elevador de manillar | Riser del manubrio 41973-001 Art.-Nr: Legende / file Légende Schraube Anbau Tipp Fitting tip Screw Astuce de montage Schraubensicherung Achtung Thread locking fluid Attention Freinfilets Attention Vergrößerung Drehmoment...
  • Page 2 M8x75 19Nm Vor der Montage die Verkleidung mit einer Tankschutzdecke schützen. Lenker demontieren und nach hinten ablegen. Schrauben der Reihe nach festziehen .Lenkung auf Freigängigkeit prüfen ! Protect the fairing with a tank cover before fitting. Remove the handlebars and place them to the rear. Tighten the screws in sequence 1-2.
