- Page 1 USER GUIDE www.aptook.com support@aptook.com OL70-D038AE Please keep this manual carefully for further reference...
-
Page 2: Table Of Contents
TABLE OF CONTENT INSTRUCTIONS BEFORE YOU BEGIN IMPORTANT SAFETY TIPS SPECIFICATIONS FEATURE PRODUCT OVERVIEW OPERATION WATER DRAINAGE MAINTENANCE PARTS LIST TROUBLE SHOOTING SAFETY PRECAUTIONS CUSTOMER SERVICE... -
Page 3: Instructions
Can be effectively avoided telecommunications equipment, materials, etc, are damaged due to dampness or rust. Dehumidifier reduces humidity in enclosed environments by removing water vapor from the air. The APTOOK R180B is ideal for crawlspace drying, humidity control and other applications. Transportation and Custody During transportation, this product should be handled preciously to prevent violent vibration. -
Page 4: Before You Begin
APTOOK www.aptook.com BEFORE YOU BEGIN support@aptook.com... -
Page 5: Important Safety Tips
APTOOK www.aptook.com IMPORTANT SAFETY TIPS support@aptook.com... -
Page 6: Specifications
APTOOK www.aptook.com SPECIFICATIONS Model# OL70-D038AE Voltage & Frequency AC 115V 60Hz 85Pints/D (80˚F/60%RH) Dehumidify Capacity 150Pints/D (86˚F, 80%RH) Rated Input Power&Current 1165W/10.2A @ 80˚F, 60% RH Refrigerant/Charge R410A/ 27.5oz Low Side Pressure 240Psi High Side Pressure 522psi BCSC Compressor Input RLA:6.4A/LRA:38A... -
Page 7: Feature
APTOOK www.aptook.com FEATURE support@aptook.com... -
Page 8: Product Overview
APTOOK www.aptook.com PRODUCT OVERVIEW Parts Diagram Pushing handle FRONT Control panel Power cord Air inlet Big wheel Continuous drainage hole BACK Air outlet Wrapping post Grille Small wheel support@aptook.com... -
Page 9: Operation
APTOOK www.aptook.com OPERATION Control Panel Guide POWER When the unit is plugged in, the display screen shows ‘--’. Press the power button, the unit starts and enters the continuous dehumidifying mode. The default setting humidity is 50% with default high fan speed. Press the power button again, the unit enters the standby mode, the compressor stops and fan will stop 1 minute later. - Page 10 APTOOK www.aptook.com MINUS Press the timer button first, then press this button to decrease the timing or humidity setting. The default humidity setting is 50%. Buzzer buzzes once for each pressing and the setting humidity decreases by 5% RH. The humidity setting procedure is 50%→45%→40%→35%→ 30%→25%→20%.
- Page 11 APTOOK www.aptook.com Display Screen: The digital display features the following functions: 1. When the unit is plugged in, it shows ‘--’, the machine is in standby mode. 2. When users press the power button, it shows the room humidity. 3. When users set the humidity, it shows the setting humidity.
-
Page 12: Water Drainage
APTOOK www.aptook.com WATER DRAINAGE Water Tank: When the tank is full, the water full indicator light turns on, the unit also makes a buzzing sound. Please press the power button to turn off the unit, then open the front panel to get access to the water tank. - Page 13 APTOOK www.aptook.com support@aptook.com...
-
Page 14: Maintenance
APTOOK www.aptook.com MAINTENANCE Please cut off the power supply before cleaning or maintenance. Cleaning the Machine Body: Clean the machine body with a soft damp cloth. Do not sprinkle water on the unit. Do not use chemical solvent such as benzene, alcohol, gasoline. The surface may be damaged, even the whole case may be deformed. -
Page 15: Parts List
APTOOK www.aptook.com PARTS LIST What’s In The Box Picture Name Quantity Dehumidifier 1PCS Drain Hose 1PCS Pushing Handle 1PCS 6PCS Screw User Manual 1PCS support@aptook.com... -
Page 16: Trouble Shooting
APTOOK www.aptook.com TROUBLE SHOOTING Cautions: If unit malfunctions turn off the unit and unplug it immediately. Please contact your distributor for service issues. Do not dispose of electrical appliances in local landfills, or municipal waste locations. Many parts are recyclable. Contact your local government for information regarding the collection systems available in your area. -
Page 17: Safety Precautions
APTOOK www.aptook.com SAFETY PRECAUTIONS support@aptook.com... -
Page 18: Customer Service
APTOOK www.aptook.com CUSTOMER SERVICE support@aptook.com... - Page 19 Commercial Dehumidifier www.aptook.com support@aptook.com...
