- Page 1 USER MANUAL CRAWL SPACE DEHUMIDIFIER Model:OX-80P Please keep this manual carefully for further reference Email:support@aptook.com Website:www.aptook.com...
-
Page 2: Table Of Contents
CONTENT INSTRUCTIONS........................1 BEFORE YOU BEGIN......................2 IMPORTANT SAFETY TIPS...................4 PRODUCT OVERVIEW.....................8 OPERATION INSTRUCTION..................9 INSTALLATION AND ASSEMBLY OF ACCESSORIES........11 DRAINAGE METHOD......................17 CLEANING AND MAINTENANCE................19 PART LIST..........................21 TROUBLESHOOTING....................22 CUSTOMER SERVICE....................23... -
Page 3: Instructions
Place your dehumidifier away from obstructions, and keep it away from anything that could block airflow into and out of the unit. We also kindly ask you to take a few minutes to register your product at www.aptook.com for more efficient support. -
Page 4: Before You Begin
The user manual contains instructions and notes on the operation and use of this unit. APTOOK recommends that you use genuine accessories from APTOOK. APTOOK shall not be responsible for any damage or expense that might result from the use of parts other than genuine parts from the APTOOK. - Page 5 ■ This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
-
Page 6: Important Safety Tips
IMPORTANT SAFETY TIPS Your safety is the most important thing we concerned! Please read this manual carefully and fully understand before operating your appliance. WARNING OPERATIONAL PRECAUTIONS WARNING-to reduce the risk of fire,electric shock or injury to persons or property: ■... - Page 7 ■ Do not use means to accelerate the defrosting process or to clean, other than those recommended by the manufacture. ■ The appliance shall be stored in a room witllout continuously operation sources (for cxample:open flames,an operating gas appliance or an operating electric heater). ■...
- Page 8 3.General work area All maintenance staff and others working in the local area shall be instructed on the nature of work being carried out. Work in confined spaces shall beavoided. The area around the work space shall be sectioned off. Ensure that the conditions within the area have been made safe by control of flammable material.
- Page 9 The following checks shall be applied to installations using flammable refrigerants: -The charge size is in accordance with the room size within which the refrigerant containing parts are installed; -The ventilation machinery and outlets areoperating adequately and are not obstructed; SPECIFICATIONS IMPORTANT SAFETY TIPS MODEL OX-60PB OX-80P OX-100P...
-
Page 10: Product Overview
PRODUCT OVERVIEW Parts Diagram Front View Handle Duct adapter Remote control Air outlet Control panel signal cable interface Acess door External pump signal cable interface Water pipe Screws Power cord Control panel Drain connect Unit cover Unit cover Air inlet with removable filter Ceiling mount gasket Adjustable feet... -
Page 11: Operation Instruction
OPERATION INSTRUCTION Humidity Display Auto Mode Water Full Alert Continuously Drying Mode Sleep Mode Temperature Display Timer Display Timer Down On/Off Up Mode Switch Button Description A.On/Off(Power) Button Press the on/off button and the machine will start running (one beep). Press the button again to the turn the machine off. - Page 12 D.ADD Button Press this button to adjust the set humidity (20-90%) or timing time (0-24h) in an upward cycle.Press the button for 3 seconds to switch between Fahrenheit and Celsius temperatures.Increase the humidity by pressing this button at normal mode, humidity increase 1%RH with each press, buzzer rang each time with the press, press the button for 1 second can increase the humidity continuously;...
-
Page 13: Installation And Assembly Of Accessories
Humidity Control In auto mode or sleep mode, press the up and down adjustment button to cyclically adjust the set humidity. Each time the up (or down) button is pressed, the set humidity will increase (or decrease) by 1%. During the adjustment of the set humidity, the set humidity will flash and display, after the adjustment is completed, it will flash and display 5 times to confirm, and then switch to display the ambient humidity. - Page 14 Ⅱ: Take out the duct adapter and adjustable rubber feet from the machine body 1. Unscrew the 2 screws under the lower cover, and remove the lower front panel. 2. Use a screwdriver to remove the 2 screws on the top cover and remove the top front panel. 3.
- Page 15 Ⅲ: Ducting installation 1. Align the duct adapter with the 4 screw positioning holes on the side. 2. Lock and fix the duct adapter with screws. 3. The user can put the exhaust pipe (purchased by the user according to the demand) on the duct adapter, and it must be placed within the buckle position.
- Page 16 Ⅴ: Ceiling mount gasket installation When the machine is suspended in the air, the machine needs to be installed with ceiling mount gasket. Spring Spacers Flat Spacers Ceiling Mount Gaskets Screws 1. Install the ceiling mount gasket in the body (accessories: 4 ceiling mount gaskets, 12 spring spacers, 12 flat spacers, 12 screws) 2.
- Page 17 Ⅵ: Wall assembly method for control panel When the machine is shipped, the control panel is assembled on the front of the machine. In order to facilitate the user to install the control panel on the wall, the control panel needs to be removed and the control panel installed on a wall surface that is convenient for operation, as follows.
- Page 18 6. Connect the signal wires to the terminals of the control panel inside the upper cover of the control panel assembly, install them in place, and then fix the upper cover on the lower cover. Screws 7. Then plug the other end of the signal cable of the control panel into the signal interface of the machine. Control Panel Signal Cable Signal Cable Interface...
-
Page 19: Drainage Method
Drainage Method I: Water pipe drainage method Drain outlet/External water pump inlet Water Pipe Operation instructions: When using the water pipe drainage method, connect the water pipe at the drain, place the water pipe in place, place the other end of the water pipe at the drain, or at the drain sink, or in the water storage container;... - Page 20 Ⅱ.External pump drainage method(not include pump,need to buy) Vertical drainage available Drain outlet/External water pump inlet Water pipe A Water pipe B External pump signal cable interface Water pump signal line Water pump Water pump power cord When it is necessary to connect an external water pump, oneend of the drainpipe is connected to the water outlet, and theother end is connected to the water inlet of the water pump.
-
Page 21: Cleaning And Maintenance
Cleaning and Maintenance Note: Before cleaning and maintaining the machine, please make sure to turn off the machine and unplug it from the power source to prevent electric shock. Cleaning : Before doing any cleaning and maintenance work on the machine, the machine must be turned off, unplugged, and no water should be spilled on the machine. - Page 22 2. Clean the filter Use a vacuum cleaner to gently absorb the dust on the surface of the filter. If the filter is very dirty, you can use tap water to rinse the filter, and completely cool and dry it, then put it back into the forward air sheet, which can improve the performance of the machine.
-
Page 23: Part List
Part List Dust adapter Adjustable feet User manual... -
Page 24: Troubleshooting
Troubleshooting Symptom Cause Solution Power outage Restoration of power supply Power plug is not connected Connect the plug to the socket Machine Won't well The machine's protection device is Room temperature over 113 ℉ activated so that the machine does not or below 38℉... -
Page 25: Customer Service
These are our general terms for warranty service, but we always urge our customers to reach out to us with any issue, regardless of warranty terms. If you have an issue with a APTOOK product, please contact us at support@aptook.com,and we will do our best to resolve it for you. - Page 26 CRAWL SPACE DEHUMIDIFIER Model:OX-80P Email:support@aptook.com Website:www.aptook.com...
