- Page 1 VV-100 Vein Viewer User Manual Shenzhen Enmind Technology Co.,Ltd.
- Page 2 Preface 1. Application Scope Applicable to VV100 Vein Viewer of our company. This User Manual describes the product’s most complete configuration, accessories and functions may not exist in the product of the user, for more detailed information, please contact manufacturer. 2.
-
Page 3: Table Of Contents
Content Chapter1 Safety Instruction ……………………………………………………………………………………………………………………………………………1 1.1 Warning 1.2 Equipment safety classification 1.3 Electromagnetic interference: 1.4 Environmental protection 1.5 Symbols Chapter 2 Product Description ………………………………………………………………………………………………………………………………………3 2.1 Definition 2.2 Working Principle 2.3 Application Scope Chapter 3 Appearance……………………………………………………………………………………………………………………………………………………4 3.1 Front View 3.2 Back View 3.3 Operation Panel 3.4 Display Chapter 4 Use Instruction…………………………………………………………………………………………………………………………………………………7... -
Page 4: Chapter1 Safety Instruction
Chapter 1 Safety Instruction 1.6 Warning Before using, please check the equipment, connecting wire and accessories to ensure that it can work normally and safely. If there’s anything abnormal, immediately stop working and contact our after sale service department. Additionally, the adhesion or intrusion of fluid/drug may possibly cause the equipment fault and malfunction. -
Page 5: Symbols
1.5 Symbols Not all of the below symbols are existed in the equipment you have purchased. Marks Description Marks Description Caution Type BF Marker Protective earth (ground) Equipment power switch... -
Page 6: Chapter 2 Product Description
Chapter 2 Product Description 2.1 Definition Venipuncture is a commonly used medical method. This blood vessel imaging device can make it easier for doctors and nurses to find veins, improve the success rate of venipuncture in children and obese people, and reduce the pain caused by the failure of venipuncture. -
Page 7: Chapter 3 Appearance
Chapter 3 Appearance 3.1 Front View ① ⑥ ② ⑤ ③ ④ Display Menu [UP] Select [FORWARD] Menu [DOWN] Select [BACK] Power... -
Page 8: Back View
3.2 Back View ① ② Camera Stand Connector... -
Page 9: Display
2.3 Display 2.3.1 Size: S(Small)/M(Medium)/L(Large) 2.3.2 Color: 2.3.2.1 Normal Mode White/Yellow/Pink/Red/Light Blue/Green/Deep Blue 2.3.2.2 Enhancement Mode Purple/Blue/Yellow 2.3.3 Inverse Mode: Inverse/Non-Inverse 2.3.4 Brightness: L(Low)/M(Medium)/H(High) -
Page 10: Chapter 4 Use Instruction
Chapter 4 Use Instruction 1) The instrument was placed about 20-25CM above the patient's puncture site. The lens is aligned to the applicable location and blood vessels. Turn on the power supply, press the power button for a long time until the boot-up interface appears on the screen, the machine starts to work, and the projector lights up. -
Page 11: Chapter 6 Transportation And Storage
Chapter 6 Transportation and Storage 1) Shocks, severe vibration and dampness should be prevented during transportation. Transportation requirements are stipulated in the order contract. 2) Conditions of transport and storage: Packed venous imaging equipment should be stored in a non-corrosive gas and well ventilated room. A) ambient temperature range: - 40 ~55 C;...
