Panasonic FV-15NLFS1H Service Manual

Service Manual
This service information is designed for experienced repair technicians only and is not designed for use by
the general public. It does not contain warnings or cautions to advise non-technical individual of potential
dangers in attempting to service a product. Products powered by electricity should be serviced o repaired
only by experienced professional technicians. Any attempt to service or repair the product or products
dealt with in this service information by anyone else could result in serious injury or death.
There are special components used in this equipment which are important for safety. These parts are
marked by in the Schematic Diagrams, Exploded Views and Replacement Part List. It is essential
that these critical parts are replaced with manufacturer´s specified parts to prevent shock, fire
or other hazards. Do not modify the original design without permission the manufacturer.
We suggest to handles such parts after the static electricity prevention.
It is forbidden to touch the PCB parts by bare hands during the repairing process.
CONTENTS
1.Specifications
2.Parts Identification
3.Wiring Diagram
4.Parts List
PESMX24020001CE
Version:2401
Ventilating Fan
FV-15NLFS1H
PAGE
1
2~4
5
6,7
