Omron VISION COMPOSER Datasheet page 3

Operation procedure
1 Preparation
A Insert CD-ROM and install the Software
(Vision Composer Ver.2).
Installation
All Rights Reserved.
Made in Japan
2 Set
A processing flow chart is
created by dragging and
dropping items
Double-click
Vision Composer Integrated Control Software for the F150-3
List of processing items
Camera image input
Image input related Memory image input
Image transfer
Scrolling
One-unit scrolling
Postion correction related
Two-unit scrolling
Scrolling reset
Binary area
Binary center of gravity and
area
Bbinary center of gravity and
main axis angle
Dark-light search
High-precision search
Damage and dirt (linear)
Damage and dirt (circular)
Damage and dirt (circular arc) Inspects for damage and dirt on a circular arc
General measurement related
Damage and dirt (rectangular) Inspects for damage and dirt inside a rectangular area
Dark-light edge position
Dark-light edge number
Dark-light edge width
Darkness average/deviation
Rotation search
Obtains angle of circular object
Sorting
Model dictionary
Vision Composer
B Double-click on a box in the flow
chart to bring up a dialog box for that
Drag & Drop
particular item's conditions.
Input images from the camera
Input an image from the storage memory to the image memory
Transfer an image between image memories. Enables multi-stage pre-processing and background cut-off.
Image scrolling for position correction
Easy position correction (using one unit)
Easy position correction (using two units)
Resets scrolled image memory to original position
Obtains only binary area at high speed
Obtains binary center of gravity and area
Obtains binary center of gravity, area, and main axis angle
Searches stored model images
Searches the stored model images and obtains the search coordinates in sub-pixel units.
Inspects for damage and dirt on a straight line
Inspects for damage and dirt on a circle
Obtains the edge position by dark-light processing
Obtains the number of objects by dark-light edge detection processing.
Obtains the distance between two edges
Obtains the average darkness and deviation of a specified area
Searches objects that are rotated.
Obtains the angle of a circular object at high speed
Sorts up to eight models
Used with "Sort 2"; up to 16 types are sorted
B Please connect F150-3 with a personal
computer by the RS-232C cable.
RS-232C
3 Operation and adjustment
Even if there is no PC, change/adjustment of
conditions can be performed using a console.
C-23
