During that period any malfunctioning or damaged units will be repaired, service and calibrated GOMA Pro offers 3 channels to amplify (up to x10 gain!), into your workshop. attenuate or polarize (attenuverter) any signal, from CV, audio to line level sources.
Connect the provided ribbon cable’s 10-pin head to the GOMA Pro, making sure the red stripe matches the one indicated on the board. Red stripe down! Place GOMA Pro on the rails of your system.
Structure GOMA Pro offers 3 channels normalized to 5 volts, processed individually by the scalers and the attenuverters. Their outputs are cascaded for mixing purposes. Back panel IN and OUT pins enable daisy chaining any modules from the GOMA family together.
Features Input normalization: fixed voltage generator While each channel handles external signals, they are normalized to a high precision 5V internal reference when no input jack is connected. The fixed voltage is processed by the scaler and the attenuverter to reach any value within the -10V to +10V range.
Page 7
Features Attenuverter The 2-position switch set each channel’s knob behavior. • Attenuator, controlling the amplitude (aka “volume”) from 0% to 100%. • Attenuverter (aka polarizer) with 0% at center position. Clockwise direction provides attenuation from 0% to 100%. Counterclockwise offers similar outcome with an inverted version of the signal: positive voltage becomes negative, and vice versa.
Page 8
Features Scaler GOMA Pro allows to set the attenuverter’s range with a 5-position switch featuring symbols explained in the center of the faceplate: two levels of attenuation, precise unity gain and two levels of amplification. A clipper confines the output to -/+10V, hard clipping the signal in unipolar mode, and reversing it in bipolar mode.
Page 9
Features Cascade Mixer Unpatched outputs are automatically mixed with the next channel’s output, every unpatched output forming a link in a flexible mixing chain. Patching only the last output of the module turns it into a standard mixer. 1+2+3...
Page 10
Features Daisy chain The cascade mixing system described above can be extended across any modules from the GOMA family, by using the included 1-pin cable to connect the OUT pin from the first module to the IN pin from the next module.
Practical uses Attenuator Attenuverter Adjust the gain of an audio signal Process a signal with the scaler to Turn a LFO ramp waveform upside Process a signal with the scaler to (volume knob), or set the range of center position and the polarizer down, prepare an audio signal for center position and the polarizer a CV signal before sending it to a...
Mixer Daisy chain mixer Mix audio signals, create complex Patch two or more inputs. patch Extend the cascade mixing system Ensure the modules are daisy modulation signal by combining the lowest used channel output through any module from the chained as shown in p7. LFO shapes.
Full range fixed voltage Offset Set a knob to control any Use a channel without input Bring a unipolar LFO in the bipolar Combine an external signal (output modulation input over a full range connected to enable the 5V range and vice versa, prepare unpatched) with an offset (input from -10V to +10 V.
line level external effect Amplifier Line level in/out Amplify an Audio signal or prepare Process a signal with the scaler to Eurorack signals (10V peak to Patch a signal and set the scaler on peak) are too hot to be processed the /10 position to reach line level a CV signal for a modulation input higher or top position.
Waveshaper Hard clip distortion Multi-fold waveshaper for audio Set all channels in series (each Hard clipping distortion to an Patch an signal and set the scaler distortion with character. output in next input), x10 gain, audio signal, crop a CV signal to a to maximum position, use the knob bipolar switch.
seq - keyboard V/OCT V/OCT VCO fine tune Very precise tunning adjustment Combine a 1V/oct signal (output for a VCO by processing a 1V/ unpatched) with an offset channel oct signal from sequencer or (input unpatched). keyboard. Set the scaler at the lowest position and switch to bipolar for a -/+ 3 semi-tone range.
external poly synth kick GOMA II LINE snare mix output hats bass line poly synth attenuator Multi-function mixer Take full control of the Goma familly’s capabilities in a bassline waveshaper, gain to x10, bipolar switch, output drum tracks as source and last channel for mix. complex mixer patch to next channel’s input to lower the volume and mix with Any available next channel can be used separately for...
