Omron V400-F Datasheet

Fixed 2D Code Reader
V400-F
One step to read the Code
The V400-F achieves highest 2D Code reading perfor-
mance on challenging materials and environmental con-
ditions. In combination with the easy and intuitive usage,
the V400-F makes the difference. Pressing the teach but-
ton once is sufficient, to automatically adjust the settings
for light and filter. This enables V400-F to read any Code
correctly, independent of the quality or changing environ-
ment. V400-F is a compact system, which is available
with integrated lense and lighting or as C-Mount variant.
• Easy adjustment of parameters
• Accurate reading of Codes
• Direct print marks on any material
• Eliminate the effects of print quality and work piece
changes
Ordering Information
2D Code Readers
Name
Special Lighting Lens
C-Mount
Accessories (Order Separately) and Cables
Name
Communications Cable
Monitor Cable
Monitor
Name
LCD Monitor
*1.
There is no need for an external power supply when this Monitor is used.(Power
is supplied from the V400-F.)
V400-F
Model
V400-F250
V400-F350
V400-F050
Model
V400-W23 (NPN)
V400-W23P (PNP)
V400-W24 (NPN)
V400-W24P (PNP)
V400-WM0
Model
*1
F150-M05L-2D
Field of vision
14 x 18 mm
31 x 42 mm
Changes according to the lens
Cable length Remarks
5 m For connection to SYSMAC Series PLC (in-
cludes power line)
For connection to an IBM PC/AT or compatible
(includes power line)
A-1
