CAMEO
Installation Guide
Vanity Unit
CAM-F600
CAM-F800
CAM-F600
Keep for future reference
CAM-F800
Advertisement
Table of Contents
Related Manuals for VADO CAMEO CAM-F600
Summary of Contents for VADO CAMEO CAM-F600
- Page 1 CAM-F600 CAM-F800 This instruction booklet covers these models: CAM-F600, CAM-F800 (All finish options) CAM-F600 CAM-F800 Vado Wedmore Road, Cheddar, Somerset, England BS27 3EB tel 01934 744466. fax 01934 744345 aftersales @ vado.com www.vado.com Keep for future reference Version 1, 1-1-24...
-
Page 2: Important - Please Read
Important - Please Read Contents of Packaging VADO reserves the right to make technical improvements and enhance the appearance of the products included in this instruction manual. Please read these instructions carefully before starting the installation and keep for future reference. - Page 3 Dimensions - CAM-F600 Dimensions - CAM-F800 793mm 593mm 420mm 795mm 420mm 595mm...
-
Page 4: Installation
Installation Installation Locking pin For illustration purposes the CAM-F800 is shown X mm 95mm Pin locks into side of drawer Outline of unit (Drawer not shown) Model CAM-F600 559mm CAM-F800 759mm Bracket Decide on the position and height of the unit. The recommended basin height is Remove the drawers prior to fitting the unit on to the wall. - Page 5 Installation Installation - additional fixing method If required, the vanities can also be fixed in the positions shown below. 2 holes in top brace Latch Bracket 2 holes in top brace CAM-F600 2 holes also on bottom brace With two people lift the unit over and onto the brackets, make sure that both latches are over the brackets before releasing the unit.
- Page 6 Installation - worktop installation Installation - drawers Apply a non-acidic silicone Apply a bead of silicone Fix basin by applying along the top edge of the along the back and sides of silicone on the outer edge CAM-F800 unit and carefully position the countertop.
-
Page 7: Cleaning Instructions
Installation - door handle Cleaning Instructions The coating on this product is finished to the highest standard. Due care needs to be CAM-HAN6 and CAM-HAN8 handles taken to ensure the appearance is retained. Line up the handle on the drawer We recommend cleaning all products with a soft damp cloth ONLY and advise strongly making sure the edges are flush with the against the use of all aggressive/corrosive cleaning products i.e. - Page 8 In situations where like-for-like replacements are not possible, VADO will endeavour to provide the closest alternative. E&OE. NOTES: [1] Labour via our engineer network is only available in the UK. Attendance by a VADO engineer or sub-contract engineer will be under our standard terms and conditions. [2] Excludes any electrical components.
