er, and there are volume controls to adjust both the speaker volume and microphone sensitivity. The 2 watt amplifi-
er can be used to power an auxiliary speaker for even greater volume and coverage.
The MSB-30 also has a momentary "CALL" button switch which can provide a momentary contact closure to trigger
the IP network camera, or ring a door bell. The front panel blue LED lights continuously to show the unit is powered,
and to help identify the "CALL" button location at night. An external contact closure can be used to turn off the blue
LED, or simply wire it in parallel with the momentary "Call" button switch to make the blue LED wink off when the but-
ton is pressed.
The MSB-30-EWP adds Enhanced Weather Protection (EWP). Use for outdoor installations where the unit is
exposed to precipitation or condensation. EWP products feature foam rubber gaskets and boots, sealed connections,
gel-filled butt connectors, as well as urethane or thermal plastic potted circuit boards with internally sealed, field-
adjustable trim pots. For more information, see DOD# 859.
