Page 4
SAFETY & REGULATORY INFORMATION Follow the safety guidelines below to ensure personal safety and protect the system and the working environment from potential damage. CAUTION The power supplies in the system may produce high voltages and energy hazards which can cause bodily harm. Do not remove the covers and access any of the components inside the system.
Page 5
SAFETY & REGULATORY INFORMATION The power cable, extension cable, or plug is damaged The equipment has been exposed to water The equipment has been dropped or damaged The equipment does not operate correctly when you follow the operating instructions ...
Page 6
SAFETY & REGULATORY INFORMATION Installation Assembly Safety Instructions The power supply in this product contains no user-serviceable parts. Refer servicing only to qualified personnel. Do not attempt to modify or use the supplied AC power cord if it is not the exact type required.
Page 7
SAFETY & REGULATORY INFORMATION The power is active whenever the system is plugged in. To remove power from the system, you must unplug the AC power cord from the wall outlet. Your system may use more than one AC power cord. Make sure all AC power cords are unplugged.
Page 8
SAFETY & REGULATORY INFORMATION System Access Warnings CAUTION To avoid personal injury or property damage, the following safety instructions apply whenever accessing the inside of the product: Turn off all peripheral devices connected to this product. Disconnect the AC power by unplugging all AC power cords from the system or wall outlet.
Page 9
SAFETY & REGULATORY INFORMATION Circuit Overloading - Consideration should be given to the connection of the equipment to the supply circuit and the effect that overloading of the circuits might have on overcurrent protection and supply wiring. Appropriate consideration of equipment nameplate ratings should be used when addressing this concern.
Page 10
SAFETY & REGULATORY INFORMATION may accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
Page 11
SAFETY & REGULATORY INFORMATION to. Interchanging or use of other component will void the UL listing and other product certifications and approvals. Updated product information for configurations can be found on the site at the following URL: http://www.QuantaQCT.com If you do not have access to the Web address, please contact your local representative. ...
Page 12
SAFETY & REGULATORY INFORMATION Product Regulatory Compliance Markings This product is marked with the following product certification markings: Regulatory Region Marking Compliance cULus Listing USA / Marks Canada CE Mark Europe FCC Marking This device complies with Part 15 of the FCC Rules. (Class A) Operation of this device is subject to the following two conditions:...
Table of Contents SAFETY & REGULATORY INFORMATION ........1 QuantaMesh T4000 Series ............12 Chassis for the T4048-IX8D Switch ..............12 LED Indicators of T4048-IX8D ................. 13 Ports of T4048-IX8D ..................14 Data Port Connection ..................14 Fan Tray of T4048-IX8D .................. 17 Power Supply of T4048-IX8D ................
QuantaMesh T4000 Series QuantaMesh T4048-IX8D supports 48 SFP28 and 8 QSFP28 (10/25/40/50/100GbE speed) ports and is equipped with BMC in a compact rack unit size. By levering merchant silicon chip, T4048-IX8D is a high performance high density Ethernet switch with advanced features such as smart table, dynamic load balancing, and VxLAN/RIOT support.
QuantaMesh T4000 Series LED Indicators of T4048-IX8D System System System Power PSU1/2 Info Port Green Powering All Fans Powering Booting OK – – Working Amber Booting On – – – – – Going Powering Failed – – – – Failed Blue Show BMC ID –...
QuantaMesh T4000 Series Ports of T4048-IX8D The switch chassis is equipped with the following ports: 48 SFP28 ports (10/25GbE) 8 QSFP28 ports (10/25/40/50/100GbE speed) 1 Management port 1 Console port 1 USB port The chassis has 48 SFP28 and 8 QSFP28 ports. Each of these ports uses an optical transceiver, active optical cables, or direct-attached cable to connect the SFP28 or QSFP28 port to servers and other Ethernet switches.
Page 17
QSFP+ (MPO) 100GBASE-SR4 QSFP28 Transceiver Optic QSFP28 (MPO) Up to 10km 40GBASE-LR4 QSFP+ Transceiver Optic QSFP+ (LC) 100GBASE-LR4 QSFP28 Transceiver Optic QSFP28 (LC) NOTE: For more information about the cable/transceiver, please contact QCT sales. 15 Network Switch Installation Guide...
Page 18
QuantaMesh T4000 Series SFP28 Port Connection The switch is equipped with 48 SFP28 ports. The SFP28 ports support 10/25GbE IEEE 802.3by Ethernet for fiber mediums. The SFP28 ports are numbered and have corresponding SFP28 port LEDs. To install an SFP28 module, do the following: Slide the SFP28 module into an SFP28 port.
QuantaMesh T4000 Series Fan Tray of T4048-IX8D The switch chassis is equipped with six fan trays. There are two types of hot-swappable fan modules. Each fan module handle is color-coded to indicate its airflow direction. Red: indicates front-to-back airflow. ...
QuantaMesh T4000 Series Power Supply of T4048-IX8D Equipped with two supply modules, the switch can operate with either one or two power supply modules. If the switch uses two power supply modules, you can hot-swap one of the PSU during the operations. There are two types of PSU.
QuantaMesh T4000 Series BMC of T4048-IX8D T4048-IX8D has a built-in baseboard management controller (BMC) that plays the role of monitoring the whole system. The BMC is an independent subsystem with its own processor and memory so that it can run well even if the switch system hangs or powers down.
QuantaMesh T4000 Series Airflow Direction The switch ships with four fan modules and two AC power supplies. The direction of the airflow varies depending on the color of the fan module handle/plug retainer. Red: indicates front-to-back airflow (air inlet module). ...
QuantaMesh T7000 Series QuantaMesh T7032-IX7D supports 32 QSFP28 (10/25/40/50/100GbE speed) ports and is equipped with BMC in a compact rack unit size. By levering merchant silicon chip, T7032- IX7D is a high performance high density Ethernet switch with advanced features such as smart table, dynamic load balancing, and VxLAN/RIOT support.
QuantaMesh T7000 Series Rear panel Item Item PSU Warning LED PSU2 AC Power Connector (with Plug Hot-swappable Fan Modules Retainer) Earth Grounding (M6 screw) Fan LEDs PSU DC LED PSU1 PSU AC LED LED Indicators of T7032-IX7D System System System Power PSU1/2 Info...
QuantaMesh T7000 Series Data Port Port Speed QSFP28 LED Green Blue Amber Yellow 100G White Activity Blinking Ports of T7032-IX7D The switch chassis is equipped with the following ports: 32 QSFP28 ports (10/25/40/50/100GbE speed) 1 Management port 1 Console port ...
Page 26
QSFP28 (LC) NOTE: For more information about the cable/transceiver, please contact QCT sales. QSFP28 Port Connection The switch is equipped with 32 QSFP28 ports. Each single port supports 40G or 100G by using 40G or 100G cables or optical transceivers. The switch can support fan-out cable for 40G to 4 x 10G or 100G to 4 x 25G or 2 x 50G.
QuantaMesh T7000 Series Fan Tray of T7032-IX7D The switch chassis is equipped with six fan trays. There are two types of hot-swappable fan modules. Each fan module handle is color-coded to indicate its airflow direction. Red: indicates front-to-back airflow. ...
QuantaMesh T7000 Series Power Supply of T7032-IX7D Equipped with two supply modules, the switch can operate with either one or two power supply modules. If the switch uses two power supply modules, you can hot-swap one of the PSU during the operations. There are two types of PSU.
QuantaMesh T7000 Series BMC of T7032-IX7D T7032-IX7D has a built-in baseboard management controller (BMC) that plays the role of monitoring the whole system. The BMC is an independent subsystem with its own processor and memory so that it can run well even if the switch system hangs or powers down.
QuantaMesh T7000 Series Airflow Direction The switch ships with four fan modules and two AC power supplies. The direction of the airflow varies depending on the color of the fan module handle/plug retainer. Red: indicates front-to-back airflow (air inlet module). ...
Hardware Installation Unpacking the Hardware Upon receiving the switch, inspect the packing box. If the packing box was not damaged in transit, unpack it carefully. NOTE: Retain the packing box in case you need to transport the switch. The packing box is heavy. It is recommended for two persons to carry the box and perform the installation.
Hardware Installation Rack Mounting If installing on a rack, verify the following: Ensure the cabinet is stable and secure to withstand any unexpected movement, such as an earthquake. Ensure the rack or cabinet can support the weight of the switch and other additional weight.
Page 33
Hardware Installation Mounting the Switch into the Rack Remove the inner rails. Pull the inner rail out until it is fully extended, and then push the tab forward to release the inner rail from the middle rail. Remove the inner rail. NOTE: ...
Page 34
Hardware Installation Align the holes on the rail mounting brackets with the switch. Secure the rail mounting brackets with screws. Align the hooks on the switch and the holes in the inner rail, and then slide the inner rail backward until it is locked into place. Secure the inner rail to the switch with the screws.
Page 35
Hardware Installation Install the outer rails to the rack. To install the front bracket: Pull the latch and install the rail by aligning the hooks with the front rack holes. Then release the latch to lock the hooks into place. ...
Hardware Installation Secure the switch to the rack using the screws. Connecting to the Console Port The console port is used for setting up and managing the switch via a connection to a console terminal or PC using a terminal emulation program. You can connect the switch to a terminal or PC using the supplied console cable (RJ-45 male to RS-232 female cable) for serial communication.
Hardware Installation Connect the RS-232 end to a terminal or PC. Manage the switch using the CLI commands (refer to the CLI User Manual for more information). The switch uses the following default settings: Baud rate: 115200 Data width: 8 bits ...
Hardware Installation Connecting the Power CAUTION Ensure that the socket outlet is installed near the equipment and be easily accessible. The power cord must have safety ground pin or contact that is suitable for the electrical outlet. The power supply cord(s) must be plugged into socket outlet(s) that is/are provided with a suitable earth ground.
Components Replacement Troubleshooting Below is a list of the common problems that you may encounter when using the switch. Try to solve these problems with the suggested solutions before calling for service. If problems persist, contact customer support. Diagnostic Switch Indicator Problem Solution Power LED is off.
Components Replacement In-Band Access You can access the management agent in the switch from anywhere within the attached network using Telnet, a Web browser, or other network management software tools. However, you must first configure the switch with a valid IP address, subnet mask, and default gateway.
Components Replacement Replacing the Fan Tray CAUTION When installing a new fan module, make sure it has the same airflow direction as the fan modules and the power supply. The fan modules can be replaced without the use of special tools. Before replacing any of the fan modules, verify the status of the fan modules to determine if there is a need for replacement.
Appendix QuantaMesh Ethernet Switches support multiple NOS by using ONIE to install. The following pages provide example of how to manually install ONIE installer of Quanta NOS from QuantaMesh BMS devices. Manually Install Vendor OS With QUANTA ONIE code, it allows user to manually download an installer. You can use the Download Installer function which supports 3 types of different protocols (i.e.
Page 43
Appendix d. Use the following command to set your switch box IP address: “ifconfig eth0 192.168.2.1” ifconfig eth0: the command string 192.168.2.1: the switch IP address e. Use the “ipconfig” command to verify if the IP address setting is correct. In ONIE Linux shell, use the “install_url”...
