  • Page 1 QuantaMesh T9032-IX9 Network Switch Installation Guide...

  • Page 3: Safety & Regulatory Information

    SAFETY & REGULATORY INFORMATION Copyright All specifications and figures are subject to change without prior notice. Actual products may look different from the photos. All trademarks and logos mentioned in this guide are the properties of their respective holders. Copyright © 2019 Quanta Computer Inc. All rights reserved. About the Manual This installation guide is meant for network administrators with inept knowledge in network management.
  • Page 4 SAFETY & REGULATORY INFORMATION Follow the safety guidelines below to ensure personal safety and protect the system and the working environment from potential damage. CAUTION  The power supplies in the system may produce high voltages and energy hazards which can cause bodily harm. Do not remove the covers and access any of the components inside the system.
  • Page 5 SAFETY & REGULATORY INFORMATION  The power cable, extension cable, or plug is damaged  The equipment has been exposed to water  The equipment has been dropped or damaged  The equipment does not operate correctly when you follow the operating instructions ...
  • Page 6 SAFETY & REGULATORY INFORMATION Installation Assembly Safety Instructions  The power supply in this product contains no user-serviceable parts. Refer servicing only to qualified personnel.  Do not attempt to modify or use the supplied AC power cord if it is not the exact type required.
  • Page 7 SAFETY & REGULATORY INFORMATION  The power is active whenever the system is plugged in. To remove power from the system, you must unplug the AC power cord from the wall outlet. Your system may use more than one AC power cord. Make sure all AC power cords are unplugged.
  • Page 8 SAFETY & REGULATORY INFORMATION System Access Warnings CAUTION  To avoid personal injury or property damage, the following safety instructions apply whenever accessing the inside of the product:  Turn off all peripheral devices connected to this product.  Disconnect the AC power by unplugging all AC power cords from the system or wall outlet.
  • Page 9 SAFETY & REGULATORY INFORMATION  Circuit Overloading - Consideration should be given to the connection of the equipment to the supply circuit and the effect that overloading of the circuits might have on overcurrent protection and supply wiring. Appropriate consideration of equipment nameplate ratings should be used when addressing this concern.
  • Page 10 SAFETY & REGULATORY INFORMATION may accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 11 SAFETY & REGULATORY INFORMATION to. Interchanging or use of other component will void the UL listing and other product certifications and approvals. Updated product information for configurations can be found on the site at the following URL: http://www.QuantaQCT.com If you do not have access to the Web address, please contact your local representative. ...
  • Page 12 SAFETY & REGULATORY INFORMATION Product Regulatory Compliance Markings This product is marked with the following product certification markings: Regulatory Region Marking Compliance cULus Listing USA / Marks Canada CE Mark Europe FCC Marking This device complies with Part 15 of the FCC Rules. (Class A) Operation of this device is subject to the following two conditions:...

  • Page 13: Table Of Contents

    Table of Contents SAFETY & REGULATORY INFORMATION ........1 QuantaMesh T9000 Series ............12 Chassis for the T4048-IX9 Switch ..............12 LED Indicators of T9032-IX9................13 Ports of T9032-IX9 ..................15 Data Port Connection ..................15 QSFPDD Port Connection ................. 15 Fan Tray of T9032-IX9 ..................

  • Page 14: Quantamesh T9000 Series

    QuantaMesh T9000 Series QuantaMesh T9032-IX9 supports 32 QSFPDD (40/100/200/400GbE speed) ports and is equipped with BMC in a compact rack unit size. By levering merchant silicon chip, T9032- IX9 is a high performance high density Ethernet switch with advanced features such as smart table, dynamic load balancing, and VxLAN/RIOT support.

  • Page 15: Led Indicators Of T9032-Ix9

    QuantaMesh T9000 Series LED Indicators of T9032-IX9 System State Description PWR LED (front LED number One per system on the front panel) panel (single color – The unit is non operational green) Green (Solid) Power is provided to the switch Green (Blinking) None...
  • Page 16 QuantaMesh T9000 Series State Description Amber (Solid) The port is operating at 1Gbps Amber (Blinking) None Green (Solid) The port is operating at 100Mbps Green (Blinking) None Management LED number One per unit (on the right of Port Link/ MGMT port) Activity LED No link or port disable (bi-color –...

  • Page 17: Ports Of T9032-Ix9

    QuantaMesh T9000 Series Ports of T9032-IX9 The switch chassis is equipped with the following ports:  32 QSFPDD ports (40/100/200/400GbE speed)  1 Management port  1 Console port  1 USB port The chassis has 32 QSFPDD ports. Each of these ports uses an optical transceiver, active optical cables, or direct-attached cable to connect the QSFPDD port to servers and other Ethernet switches.
  • Page 18 400GBASE-FR8 QSFPDD Transceiver Optic QSFPDD Up to 10km 40GBASE-LR4 QSFP+ Transceiver Optic QSFP+ (LC) 100GBASE-LR4 QSFP28 Transceiver Optic QSFP28 (LC) 400GBASE-FR4 QSFPDD Transceiver Optic QSFPDD NOTE:  For more information about the cable/transceiver, please contact QCT sales. Network Switch Installation Guide 16...

  • Page 19: Fan Tray Of T9032-Ix9

    QuantaMesh T9000 Series QSFPDD Port Connection The switch is equipped with 32 QSFPDD ports. The QSFPDD ports support 400GbE IEEE 802.3by Ethernet for fiber mediums. The QSFPDD ports are numbered and have corresponding QSFPDD port LEDs. To install an QSFPDD module, do the following: Slide the QSFPDD module into an QSFPDD port.

  • Page 20: Power Supply Of T9032-Ix9

    QuantaMesh T9000 Series Power Supply of T9032-IX9 The switch is equipped with two power supply, you can hot swap one of the PSU during the operations.  Blue: indicates back-to-front airflow. The AC power connector is a standard three-pronged connector. The switch automatically adjusts its power setting to any supply voltage in the range from 100~240 VAC at 50~60 NOTE: ...

  • Page 21: Bmc Of T9032-Ix9

    QuantaMesh T9000 Series BMC of T9032-IX9 T9032-IX9 has a built-in baseboard management controller (BMC) that plays the role of monitoring the whole system. The BMC is an independent subsystem with its own processor and memory so that it can run well even if the switch system hangs or powers down.

  • Page 22: Airflow Direction

    QuantaMesh T9000 Series Airflow Direction The switch ships with six fan modules and two AC power supplies. The direction of the airflow  Blue: indicates back-to-front airflow (air outlet module). CAUTION  Do not mix power supplies and fan modules with different airflow in the same chassis.

  • Page 23: Hardware Installation

    Hardware Installation Unpacking the Hardware Upon receiving the switch, inspect the packing box. If the packing box was not damaged in transit, unpack it carefully. NOTE:  Retain the packing box in case you need to transport the switch.  The packing box is heavy. It is recommended for two persons to carry the box and perform the installation.

  • Page 24: Positioning The Switch

    Hardware Installation Rack Mounting If installing on a rack, verify the following:  Ensure the cabinet is stable and secure to withstand any unexpected movement, such as an earthquake.  Ensure the rack or cabinet can support the weight of the switch and other additional weight.
  • Page 25 Hardware Installation Mounting the Switch into Standard Rack with BES-53248A1-SRMK Rail Kit Remove the inner rails. Pull the inner rail out until it is fully extended, and then push the tab forward to release the inner rail from the middle rail. Remove the inner rail. NOTE: ...
  • Page 26 Hardware Installation Remove the rail mounting brackets and screws from the accessory bag. Align the holes on the rail mounting brackets with the switch. Secure the rail mounting brackets with screws. Align the hooks on the switch with the holes in the inner rail, and then slide the inner rail backward until it is locked in place.
  • Page 27 Hardware Installation Install the outer rails to the rack.  To install the front bracket: Pull the latch and install the rail by aligning the hooks with the front rack holes. Then release the latch to lock the hooks into place. ...
  • Page 28 Hardware Installation Secure the switch to the rack using the screws. Mounting the Switch into Ozeki Rack with BES-53248A1-ZRMK Rail Remove the inner rails. Pull the inner rail out until it is fully extended, and then push the disconnect latch forward to release the inner rail from the middle rail.
  • Page 29 Hardware Installation The switch supports front and rear rail installations. Align the hooks on the switch with the holes in the inner rail, and then slide the inner rail backward until it is locked in place. Secure the inner rail to the switch with the screws. Front Installation Rear Installation NOTE:...

  • Page 30: Connecting To The Console Port

    Hardware Installation Front Installation Rear Installation NOTE:  Repeat the similar steps to install another inner rail. NOTE:  Push the disconnect latch to release the switch when removing the switch and it is fully extended. Connecting to the Console Port The console port is used for setting up and managing the switch via a connection to a console terminal or PC using a terminal emulation program.

  • Page 31: Connecting To The Management Port

    Hardware Installation RJ-45 Port of DB9 Female Port of Abbreviation Description Switch Request To Send Ground Using the console port, you can perform the following:  Configure the switch using the CLI commands  Manage and monitor network activity by Command Line Interface (CLI) management ...

  • Page 32: Connecting The Power

    Hardware Installation Connect the other end of the Ethernet cable to a network. The Management port LED (Link/Activity LED) lights green when the network link is established. Connecting the Power CAUTION  Ensure that the socket outlet is installed near the equipment and be easily accessible.

  • Page 33: Components Replacement

    Components Replacement Troubleshooting Below is a list of the common problems that you may encounter when using the switch. Try to solve these problems with the suggested solutions before calling for service. If problems persist, contact customer support. Diagnostic Switch Indicator Problem Solution Power LED is off.

  • Page 34: In-Band Access

    Components Replacement In-Band Access You can access the management agent in the switch from anywhere within the attached network using Telnet, a Web browser, or other network management software tools. However, you must first configure the switch with a valid IP address, subnet mask, and default gateway.

  • Page 35: Replacing The Fan Tray

    Components Replacement Replacing the Fan Tray CAUTION  When installing a new fan module, make sure it has the same airflow direction as the fan modules and the power supply. The fan modules can be replaced without the use of special tools. Before replacing any of the fan modules, verify the status of the fan modules to determine if there is a need for replacement.

  • Page 36: Appendix

    Appendix QuantaMesh Ethernet Switches support multiple NOS by using ONIE to install. The following pages provide example of how to manually install ONIE installer of Quanta NOS from QuantaMesh BMS devices. Manually Install Vendor OS With QUANTA ONIE code, it allows user to manually download an installer. You can use the Download Installer function which supports 3 types of different protocols (i.e.
  • Page 37 Appendix d. Use the following command to set your switch box IP address: “ifconfig eth0 192.168.2.1”  ifconfig eth0: the command string  192.168.2.1: the switch IP address e. Use the “ipconfig” command to verify if the IP address setting is correct. In ONIE Linux shell, use the “install_url”...
