- Page 1 VC-01A Handheld Vibration Calibrator Product Manual ROGA Instruments | Im Hasenacker 56 | 56412 Nentershausen | GERMANY Phone: + 49(0)6485-8815803 | Fax: +49(0)6485-8818373 | E-mail: contact@roga-instruments.com...
-
Page 2: Table Of Contents
Without man-made damage, the warranty period is 12 months. ROGA Instruments | Im Hasenacker 56 | 56412 Nentershausen | GERMANY Phone: + 49(0)6485-8815803 | Fax: +49(0)6485-8818373 | E-mail: contact@roga-instruments.com... -
Page 3: Introduction
1. Introduction VC-01A Handheld Vibration Calibrator is a small, portable calibration instrument. It provides a stable vibration reference source, which can conveniently and accurately calibrate accelerometers, velocity sensors and displacement sensors, and could also test the measurement system composed of sensors to determine whether the sensors and the whole measurement system are working properly. - Page 4 This instrument has the following features: 1) Portable, Built-in battery 2) Small size and light weight Acceleration, velocity displacement calibration 4) Quick, easy field calibration of vibration measurement and recording systems 5) High-precision operating at 4 frequencies and 3 accelerations Page 2...
-
Page 5: Technical Parameters
2. Technical parameters 1) Operating frequency(±0.5%): 40Hz, 80Hz, 159.2Hz, 1kHz 2) Acceleration output (m/s rms): 0.98, 4.91, 9.81 3) Velocity output (mm/s rms): 0.98, 4.91, 9.81 4) Displacement output (μm rms): 0.98, 4.91, 9.81 5) Distortion: ≤5% 6) Accuracy: ≤5% 7) Maximum load: 200 grams 8) Automatic switch off time: ~50 seconds 9) Temperature range: 0~+55℃... -
Page 6: Principle Of Operation
3. Principle of operation The VC-01A Handheld Vibration Calibrator uses a built-in standard accelerometer and an external transducer under test mounted back-to- back for testing by the comparison method, using closed- loop control to provide a highly stable vibration reference source. - Page 7 0.98, 4.91, 9.81g rms. The reference signal may also be used for velocity and displacement, at 0.98, 4.91, 9.81mm/s rms and 0.98, 4.91, 9.81μm rms, respectively. Figure 2 VC-01A Cross-Section of Handheld Shaker Vibration Head Page 5...
-
Page 8: Panel Function
4. Panel function Figure 3 VC-01A Panel Diagram 1) Power button (ON/OFF) 2) Status indicator During normal operation, the LED shows green; when the LED shows orange, please unscrew the bottom part of the calibrator and remove the battery for charging. -
Page 9: How To Use
5. How to use 1) Fix the under-testing sensor on the top of the calibrator. 2) Connect the sensor's cable to the back-end test equipment input. 3) Press the power button (ON/OFF). 4) Press the amplitude button to select suitable acceleration. -
Page 10: Accessories
6. Accessories 1) VC-01A handheld vibration calibrator: 1ea 2) 9V rechargeable battery: 3) Battery charger: 4) Certificate:...
