- Page 1 R-T12100B/T12200B/T12300B User Manual TOPBAND Lithium Iron Phosphate Battery with Smart Monitoring SHENZHEN TOPBAND BATTERY CO.,LTD Address:Topband Industrial Park, Liyuan Industrial Zone, Shiyan, Bao'an, Shenzhen, China, 518108 Web：https://www.topbandbattery.com/...
-
Page 2: Table Of Contents
2.1 Tools and Equipment ______________________________________________________ 6 2.2 Battery placement _________________________________________________________ 6 2.3 Battery supporting materials ________________________________________________ 8 3. Introduction to TOPBAND series batteries _______________________________ 8 3.1 Main features _____________________________________________________________ 8 3.2 Product appearance. _______________________________________________________ 9 3.3 Functional characteristics _________________________________________________ 15 3.4 Heating function _________________________________________________________ 16... - Page 3 4.5.2 Networking method: _____________________________________________________________ 22 4.5.3 APP interface display ___________________________________________________________ 24 5. Charging requirements _______________________________________________ 24 5.1 AC-DC charger ___________________________________________________________ 25 5.2 Photovoltaic charging _____________________________________________________ 25 5.3 Charging with an AC generator through a DC-DC charger ____________________ 25 5.4 Recommended charging voltage ___________________________________________ 25 5.5 Passive balance function __________________________________________________ 26 6.
-
Page 4: Safety
1. Safety 1.1 Statement Please read this manual carefully before installation, operation, and maintenance, and pay attention to various warning signs and statements on the equipment. After reading this manual, please keep it pro perly for future reference. 1.2 Specification This manual contents using the following symbols should be paid special attention to during operation. -
Page 5: Battery Maintaining
During installation: • Personnel familiar with the electrical specifications of their country or region are required to in stall battery packs. For optimal safety, please follow the steps described in this manual. Battery operation: • ①Prohibit connecting batteries to different types of batteries； •... -
Page 6: Waste Disposal
1.5 Waste disposal Please handle packaging and replace components in accordance with the law s and regulations of the country or region where the battery pack is located. Do not mix batteries with daily life. Dispose of garbage together 2. Installation 2.1 Tools and Equipment Insulating gloves Safety shoes... - Page 7 ✘ ✘ Figure 1 Installation and Placement Diagram...
-
Page 8: Battery Supporting Materials
00Ah Screw M8 * 12 stainles s steel screw 3. Introduction to TOPBAND series batteries 3.1 Main features a. LiFePO4 chemistry - providing excellent safety and lifespan performance b. High reliability – with high cell consistency and balancing feature c. Maintain consistent performance over a wide temperature range d. -
Page 9: Product Appearance
h. IP67 rating 3.2 Product appearance. Figure 2 Battery Appearance Component Description Name Statement Disperse the heat insid e the battery, be careful not to touch it with your hands Pole M8 Terminal... - Page 10 Check the SOC. runnin g light to preliminarily deter Panel mine whether the battery o perates normally When the battery is not Power used for a long time, it ca Switch n be disconnected to reduc e self-consumption. Carefully read the label and use the battery correctl Label y according to the label co...
- Page 11 Component description: 1. Heat sink The heat sink is a battery cooling component, and rapid heat dissipation is beneficial for extending the battery life. At the same time, the heat sink is a hot decoration that cannot be touched by hand duri ng battery use to avoid burns.
- Page 12 SOC indicator lights: 4 green lights, representing different SOC according to different lighting methods. One LED represents 25% SOC. Status Charge Discharge 0-25% Blink2 25-50% Blink2 50-75% Blink2 75%-100% Blink2 4. Battery switch Power switch: The battery power switch is used to turn the battery on or off. When the battery is in the O N state, it indicates that the battery BMS is in a normal state and can be charged, discharged, and conne cted to Bluetooth;...
- Page 13 Reset button: to check the battery SOC or match the battery address. Usage method: ① Press for 1s, the SOC LEDs turns on for 10s. According to the number of SOC LED lights on, det ermine the SOC range; ② Long press 10s, the battery to match the networking address. During the matching process, the SO C LEDs start running.
- Page 14 A: Schematic diagram of single battery usage B: When multiple batteries are used in series or parallel, the external device communication line needs to be connected to the battery Link in; 8. Pressure relief valve The waterproof grade is IP67, because the battery is heating during charging and discharging, which leads to thermal expansion.
-
Page 15: Functional Characteristics
3.3 Functional characteristics Item 12100 12200 12300 Nominal voltage 12.8V Nominal energy 1280Wh 2560Wh 3840Wh Nominal capacity 100AH 200Ah 300Ah ≤30mΩ Internal resistance@1khz AC Allowed MAX. charge current@ 100A 200A 300A 25° C Allowed MIN. discharge current 150A 200A 300A @25°... -
Page 16: Heating Function
3.3.1 First use ① Observe that there are no signs of the battery being disassembled; ② When the battery leaves the factory, the power switch will be turned off and in the OFF stat ③ Before using the battery, it is necessary to turn the switch to the ON state, and the LED disp lay light will be on. -
Page 17: Parallel Usage
nd the expansion of battery system capacity. For example, four 12.8V200Ah batteries can be connecte d in series and parallel to form a 25.6V400Ah battery system. When multiple sets of batteries are connected in series and parallel at the same time, in addition to e xternal power lines, communication lines can be connected between the batteries, and internal commu nication between the batteries can better obtain battery information. - Page 18 arallel. Communication cable Positive power cable Negative power cable Chart 3：Wire chart For example, two 12.8V100Ah are used in parallel Do not output positive and neg ative poles on the same battery, which may damage the battery.
-
Page 19: Serial Usage
System voltage: 12.8V System capacity:100Ah + 100Ah = 200Ah 4.3 Serial usage A maximum of 4 batteries can be used in series. Before connecting the batteries in series, a multimet er needs to be used to test the voltage between the positive and negative terminals of the battery. Yo u can also check the battery voltage through the Bluetooth app to ensure that the voltage between th e batteries does not exceed 2V. -
Page 20: Simultaneous Series And Parallel
4.4 Simultaneous series and parallel T series batteries allow simultaneous use of batteries in series and parallel, with a maximum support of 4 series and 4 parallel applications. The connection method is: first in series, then in parallel, wh ich means that the batteries are connected in series to form a high voltage, and then in parallel to for m a high capacity. -
Page 21: Battery Communication
4.5 Battery communication 4.5.1 Communication terminal connection The series of T-Premium batteries have the function of communication networking between batteries. When communication with external devices is needed, the networking function can be used to enable the battery to summarize information. The battery can be used alone or used for communication netw orking, which is more prominent in some intelligent devices. -
Page 22: Networking Method
CAN bus, please contact Topband for technical support. For normal battery operation, the CAN bus function is not mandatory. The battery can automatically op erate and protect itself; it does not require any CAN bus communication or external devices (such as external controllers) or other CAN bus connected batteries to operate. - Page 23 ④ Matching address: After pressing the host battery1 reset button for 10 seconds, the SOC LED s will start running. After all the LED are steady on, it means that the internal address allocati on of the battery is completed; ! Attention: The battery must be connected to the power line in a series first and t hen in parallel mode;...
-
Page 24: App Interface Display
Please refer to the APP user manual for details. 5. Charging requirements We recommend using a charging source with specific lithium charging settings to meet the following c harging requirements to achieve the optimal performance and lifespan of TOPBAND series batteries. -
Page 25: Ac-Dc Charger
You can use a DC-DC charger without lithium charging settings to charg e TOPBAND series batteries. However, it must be set to charge no more than 58.4V (4 batteries in s eries, with a maximum charging voltage of no more than 14.6V for a single battery), and then it must be turned off after the TOPBAND series battery is fully charged. -
Page 26: Passive Balance Function
6. Battery recycling Topband ® T-Premium lithium-ion batteries are recyclable and should not be treated as household was te or landfill waste. If you need assistance in recycling batteries, please contact your dealer or Topban 7. - Page 27 Shenzhen Topband Battery Co., Ltd. shall not be responsible for any accidents caused by not following our operating instructions. Warning! • The battery must be kept away from heat sources, high voltage, and directly exposed to sunlight.
