Summary of Contents for Subaru BRZ 2022

  • Page 2 Please leave this manual in the vehicle at the time of resale. The next owner will need the information found herein. NOTE: “SUBARU dealer” means an authorized SUBARU dealer and/or repairer. SUBARU CORPORATION, TOKYO, JAPAN “SUBARU” and the six-star cluster design are registered trademarks of SUBARU CORPORATION. © Copyright 2022 SUBARU CORPORATION...
  • Page 4 This manual describes the following vehicle type. 002011...
  • Page 6: Table Of Contents

    Table of Contents Introduction......................1 Illustrated Index ....................13 Seat, Seatbelt and SRS Airbags ................27 Chapter 1 Keys and Doors ....................91 Chapter 2 Instruments and Controls .................. 117 Chapter 3 Climate Control ....................185 Chapter 4 Audio........................197 Chapter 5 Interior Equipment....................
  • Page 8: Introduction

    Introduction Warranties ...............2 Drugs and Driving............8 Driving When Tired or Sleepy......... 8 How to Use This Owner’s Manual ......2 Modification of Your Vehicle .......... 8 Using Your Owner’s Manual..........2 Car Phone/Cell Phone and Driving ........ 8 Safety Warnings ...............3 Driving Vehicles Equipped with Navigation/ Safety Symbol..............3 Audio System..............
  • Page 9: Warranties

    Chapter 8: Driving Tips tion before driving. This chapter informs you how to drive your Illustrated Index SUBARU in various conditions and This chapter informs you about the vehicle explains some safety tips on driving. layout with illustrations. Chapter 9: In case of Emergency...
  • Page 10: Safety Warnings

    How to Use This Owner’s Manual This chapter informs you when you need Safety Warnings Safety Symbol to take your SUBARU to the dealer for You will find a number of WARNINGs, scheduled maintenance and informs you CAUTIONs and NOTEs in this manual.
  • Page 11: Abbreviation List

    P25. Abbreviation Meaning Supplemental restraint sys- Anti-lock brake system Mark Name Air conditioner SRVD Subaru rear vehicle detection WARNING Automatic locking retractor Thin Film Transistor Automatic locking retractor/ Tire identification number ALR/ELR Emergency locking retractor Tire pressure monitoring sys- CAUTION...
  • Page 12: Safety Precautions When Driving

    Safety Precautions When Driving Safety Precautions When Child Safety The SRS airbags deploy with Driving considerable speed and force. Occupants who are out of the WARNING proper position when the SRS Seatbelt and SRS Airbag Never hold a child on your lap or airbag deploys could suffer very in your arms while the vehicle is serious injuries.
  • Page 13 Safety Precautions When Driving Put children aged 12 and under or WARNING 1.5 m (4 feet 11 inches) tall or less NEVER use a rearward facing REAR seat properly child restraint on a seat protected restrained at all times in a child by an ACTIVE AIRBAG in front of restraint system or in a seatbelt.
  • Page 14: Engine Exhaust Gas (Carbon Monoxide)

    Safety Precautions When Driving For instructions and precautions, carefully Drinking and Driving Avoid remaining in a parked read the following sections. vehicle for a long time while the For the seatbelt system, refer to "Seat- engine is running. If that is WARNING belts"...
  • Page 15: Drugs And Driving

    Never drive if you are under the influence and park in a safe place before SUBARU navigation and/or audio of any illicit mind-altering drugs. For your using your phone. In some coun- system. Doing so could cause the...
  • Page 16: Driving Vehicles Equipped With Navigation/Audio System

    For detailed your SUBARU dealer for details the vehicle off the road and stop it information, refer to "Tires and Wheels" on the proper location.
  • Page 17: General Information

    (e.g., overtaking or driv- Data usage ing on an uphill slope). access information stored in your SUBARU may use the data recorded in vehicle. The use of unauthorized this computer to diagnose malfunctions, devices may also cause unex- This indicator supports the driver to drive...
  • Page 18: Eu Battery Directive 2006/66/Ec

    EU Battery Directive 2006/66/EC EU Battery Directive 2006/66/ The following devices utilize batteries that do not have the symbol: Followings are the symbol of EU Battery Directive 2006/66/EC. This directive applies to the collection of batteries, recycling of disposed batteries and accumulators, and batteries not disposed of in landfills because they could be hazardous to the environment.
  • Page 20: Illustrated Index

    Illustrated Index Exterior ..............14 Type A................21 Type B................22 Interior..............16 Combination Meter..........23 Instrument Panel ...........19 Normal mode..............23 Steering Wheel ............20 TRACK mode..............24 Light Control and Wiper Control Levers/ Warning and Indicator Lights ......25 Switches ..............21...
  • Page 21 Exterior Exterior 1) Engine hood (page 336) 2) Turn signal lights (page 176, 366) 3) Lights (page 168, 366) 4) Wipers (page 178) 5) Outside mirrors (page 182) 6) Door locks (page 108) 7) Tire pressure (page 353) 8) Flat tires (page 292) 9) Tire chains (page 284) 10) Tie-down hooks (page 309) 11) Towing hook (page 309)
  • Page 22 Exterior 1) Rear window defogger (page 181) 2) Fuel filler lid and cap (page 212) 3) Tie-down holes (page 309) 4) Lights (page 168, 366) 5) Turn signal lights (page 176, 366) 6) Towing hook (page 309) 7) Trunk lid (page 113) 002013...
  • Page 23 Interior Interior 1) Lower anchorages for child restraint system (page 45) 2) Seatbelts (page 37) 3) Front seats (page 28) 4) Rear seats (page 35) 002014...
  • Page 24 Interior 1) Cup holder and console tray (AT models) (page 202) 2) Parking brake lever (page 243) 3) Shift lever (MT models)/Select lever (AT models) (page220, 223) 4) Center information display (page153)/ Audio /Audio and navigation system 5) Climate control (page 186) 6) Glove box (page 202) 7) Accessory power outlet (page 203) 8) Center console (page 202)
  • Page 25 Interior 1) Map light switches (page 200) 2) Door interlock switch (page 200) 3) SOS button for eCall system (if equipped) 4) Warning labels for child restraint system (page 48) A) AIRBAG *: NEVER use a rearward facing child restraint on a seat protected by an ACTIVE AIRBAG in front of it, DEATH or SERIOUS INJURY to the CHILD can occur.
  • Page 26 Instrument Panel Instrument Panel 1) Power window switches (page 110) 2) Remote control mirror switch (page 1 2 3 4 182) 3) Illumination brightness control dial (page 124) 4) Trunk lid opener button (page 115) 5) Combination meter (page 121) 6) Tilt/Telescopic steering (page 183) 7) Hazard warning flasher switch (page 121)
  • Page 27 Steering Wheel Steering Wheel 1) Audio control switches 2) Control switches for combination meter display (color TFT) (page 145) 3) Shift paddles (AT models) (page 226) 4) Following distance setting switch 5) Talk switch voice command system 6) Cruise control switch (page 247) 7) SRS airbag (page 64) 8) Horn (page 184) 9) Hands-free phone switches...
  • Page 28 Light Control and Wiper Control Levers/Switches Light Control and Wiper Control Levers/Switches Type A 1) Windshield wiper (page 177) 2) Mist (page 179) 3) Windshield washer (page 180) 4) Wiper intermittent time control switch (page 179) 5) Wiper control lever (page 178) 6) Light control switch (page 168) 7) Rear fog light switch (page 175) 8) Headlight ON/OFF/AUTO (page 168)
  • Page 29 Light Control and Wiper Control Levers/Switches Type B 1) Turn signal lever (page 176) 2) Headlight flasher High/Low beam change (page 170) 3) Headlight ON/OFF/AUTO (page 168) 4) Rear fog light switch (page 175) 5) Light control switch (page 168) 6) Wiper control lever (page 178) 7) Wiper intermittent time control switch (page 179)
  • Page 30 Combination Meter Combination Meter Normal mode 1) Combination meter display (color TFT) (page 145) 2) Tachometer (page 121) 3) Speedometer (page 121) 4) Outside temperature (page 123) 5) Clock (page 166) 6) Engine coolant temperature gauge (page 123) 7) Fuel gauge (page 123) 8) Select lever/gear position indicator (page 141) 9) Trip meter and odometer (page 122)
  • Page 31 Combination Meter TRACK mode 1) Combination meter display (color TFT) (page 145) 2) Tachometer (page 121) 3) Speedometer (page 121) 4) Outside temperature (page 123) 5) Clock (page 166) 6) Engine coolant temperature gauge (page 123) 7) Fuel gauge (page 123) 8) Select lever/gear position indicator (page 141) 9) Trip meter and odometer (page 122)
  • Page 32 Warning and Indicator Lights Warning and Indicator Lights Mark Name Page Mark Name Page Vacuum pressure sys- Automatic headlight tem warning light (yel- beam leveler warning Mark Name Page low) light Seatbelt warning light LED headlight warning Door open indicator light Front passenger’s seatbelt warning light...
  • Page 33 Warning and Indicator Lights Mark Name Page Subaru Rear Vehicle Detection warning indi- cator (if equipped) Subaru Rear Vehicle Detection OFF indica- tor (if equipped) Snow mode indicator light (if equipped) Sport mode indicator light (if equipped) TRACK mode indica-...
  • Page 34: Seat, Seatbelt And Srs Airbags

    Seat, Seatbelt and SRS Airbags 1-1. Front Seats ............28 1-6. Child Restraint Systems........45 Manual Seat..............31 Applications for Australia models ....... 45 Head Restraint Adjustment ...........32 Safety Precautions ............45 1-2. Seat Heater (If Equipped) ........33 Safety Tips for Installing child Restraint Systems ..46 Where to Place a Child Restraint System....
  • Page 35: 1-1. Front Seats

    Front Seats 1-1. Front Seats Seatbelts provide maximum restraint when the occupant sits back and upright in the seat. To WARNING reduce the risk of sliding under Never adjust the seat while the seatbelt in a collision, the driving, as personal injury or loss front seatbacks should always be of vehicle control may occur.
  • Page 36 Front Seats According to accident statistics, WARNING WARNING children are safer when properly Put children aged 12 and under or To prevent the passenger from slid- restrained in the rear seating posi- 1.5 m (4 feet 11 inches) tall or less in ing under the seatbelt in the event tions than in the front seating posi- the REAR seat properly restrained...
  • Page 37 Front Seats WARNING WARNING WARNING Do not let rear passengers rest their Do not press your feet onto the Seatbelts provide maximum feet between the front seatback and instrument panel. Doing so may restraint when the occupant sits seat cushion. Doing so may inter- prevent the occupant detection...
  • Page 38: Manual Seat

    Front Seats Manual Seat Reclining the seatback Seat cushion height adjustment (driver’s seat) Forward and backward adjustment 102663 102664 102662 1. Pull up the reclining lever, adjust the 1) Push the lever down to lower the seat. seatback to the desired position, and then 1.
  • Page 39: Head Restraint Adjustment

    Front Seats Before getting in or out of the Head Restraint Adjustment rear seats WARNING Release the seatbelt from the seatbelt guide. Never drive the vehicle with the head restraints removed because Getting in the rear seats they are designed to reduce the risk of serious neck injury in the Lift the reclining lever or seatback fold lever.
  • Page 40: Seat Heater (If Equipped)

    Seat Heater (If Equipped) 1-2. Seat Heater (If Equipped) Head restraint height adjustment The seat heater operates when the igni- tion switch is in the “ON” position. CAUTION Do not put hard or heavy objects or ones with protrusions on the seat, and do not stab the seat with sharp objects, such as pins or needles.
  • Page 41: Front Seat Heater

    Seat Heater (If Equipped) When using for a long period of To turn on the seat heater, push the Front Seat Heater time, we recommend setting the heater “LOW” or “HIGH” position on the switch, to the LOW position. Use the HIGH as desired, depending on the tempera- position for only quick heating at the ture.
  • Page 42: 1-3. Rear Seats

    Rear Seats 1-3. Rear Seats Folding Down the Rear Seat- back WARNING When folding down the seatback, check that there are no passen- gers or objects on the rear seat. Not doing so creates a risk of injury or property damage. Never allow passengers to ride on the folded rear seatback or in 102666...
  • Page 43 Rear Seats Push the lock release button. Folding down the rear seatback WARNING Pull the lock release strap. When you return the seatback to its Return the rear seatback original position, check that the unlocking marker is not visible. Also, push the rear seatback and then check that it is securely locked in position by lightly pushing it back and forth.
  • Page 44: 1-4. Seatbelts

    Seatbelts 1-4. Seatbelts Replace all seatbelt assemblies including retractors Seatbelt Safety Tips attaching hardware worn occupants of a vehicle that has WARNING been in a serious accident. Also, sure replace seatbelt All persons in the vehicle should assemblies that show signs of fasten their seatbelts BEFORE severe fraying or having been the vehicle starts to move.
  • Page 45 Seatbelts If the shoulder portion of the belt crosses Put children aged 12 and under or According to accident statistics, the face or neck, move the child closer to 1.5 m (4 feet 11 inches) tall or less children are safer when properly the belt buckle to help provide a good REAR seat...
  • Page 46: Emergency Locking Retractor (Elr)

    Seatbelts slightly, the retractor locks the seatbelt in Emergency Locking Fastening the Seatbelt that position and the seatbelt cannot be Retractor (ELR) extended. As the belt is rewinding, clicks WARNING All seatbelts in the vehicle have an Emer- will be heard which indicate the retractor gency Locking Retractor (ELR).
  • Page 47 Seatbelts Front seatbelts Do not put cushions or any other CAUTION materials between occupants and 1. Adjust the seat position: seatbacks or seat cushions. If Metallic parts of the seatbelt can Driver’s seat: Adjust the seatback to the become very hot in a vehicle that you do so, the risk of sliding upright position.
  • Page 48 Seatbelts strong pull on it, then pull it out slowly Unfastening the seatbelt again. 100102 4. Insert the tongue plate into the buckle 102492 100102 until you hear a click. 1) Button 3. Insert the tongue plate into the buckle 1.
  • Page 49: Seatbelt Maintenance

    Seatbelt Pretensioners 1-5. Seatbelt Pretensioners 5. Place the lap belt as low as possible Seatbelt Maintenance on the hips, not on the waist. To clean the seatbelts, use a mild soap The following seatbelts have a seatbelt and lukewarm water. Never bleach or dye Unfastening the seatbelt pretensioner.
  • Page 50: Front Seatbelt With Shoulder Belt Pretensioner

    Seat- your SUBARU dealer as soon as belt pretensioners have no user- possible. serviceable parts. For required If the seatbelt retractor assembly or servicing of seatbelt retractors...
  • Page 51: System Monitors

    We recommend that you consult your tion. The seatbelt pretensioners share the systems. For required servicing SUBARU dealer if you want to install any control module with the SRS airbag of the seatbelt pretensioner, we accessory parts to your vehicle.
  • Page 52: 1-6. Child Restraint Systems

    Applications for Australia plow, skid/sump plate, etc.) to the fully follow the manufacturer’s instruc- front end other than genuine models tions. SUBARU accessory parts Refer to the Owner’s Manual supplement According to accident statistics, children parts that match the quality of...
  • Page 53: Safety Tips For Installing Child Restraint Systems

    Child Restraint Systems WARNING WARNING WARNING Before installing a child restraint Children should properly Never let a passenger hold a child system, check that the unlocking restrained at all times. Never on his or her lap or in his or her marker on the seatback lock allow a child to stand up, or to arms while the vehicle is moving.
  • Page 54: Where To Place A Child Restraint System

    Restraint System Unsecured child restraint The following descriptions are SUBARU’s systems can be thrown around recommendations on where to place a inside of the vehicle in a sudden child restraint system in your vehicle. stop, turn or accident; they can...
  • Page 55 Child Restraint Systems Some types of child restraint systems NEVER INSTALL CHILD might not be able to be secured firmly due RESTRAINT SYSTEM IN THE to projection of the seat cushion. FRONT PASSENGER'S SEAT. In this seating position, you should use DOING RISKS SERIOUS...
  • Page 56: Choosing A Child Restraint System

    Child Restraint Systems by looking for the approval label on the A) AIRBAG NEVER use a rearward facing child restraint system or the manufac- child restraint on a seat protected Choosing a Child Restraint turer’s statement of compliance on the by an ACTIVE AIRBAG in front of System box and the system.
  • Page 57 Child Restraint Systems Child Restraint System Child restraint system suitability for each seating position Left-hand drive Right-hand drive mod- models Seat position number Front passenger With occupant detection Without 2nd row 2nd row 2nd row 2nd row Seat position system occupant left right...
  • Page 58 Not appli- i-Size cable cable cable cable cable Belted Not appli- Not appli- Not appli- Childseat SUBARU Kidfix 2 R Applicable Applicable Applicable Applicable cable cable cable Recom- mend child Childseat SUBARU Baby Safe Not appli- Not appli- restraint i-Size with Childseat SUBARU...
  • Page 59 Suitable for forward facing universal category child restraint systems that are installed using the seatbelt. Child seats permitted to install in your SUBARU (refer to applicable vehicle models list attached the child seat products). Suitable for ISOFIX child restraint 102762 102763 systems.
  • Page 60 Child Restraint Systems Recommend Child Restraint System suitability for mass group Mass Group Child Restraint System up to 10 kg Childseat SUBARU Baby Safe i-Size up to 13 kg 9 to 18 kg Not applicable 15 to 25 kg Childseat SUBARU Kidfix 2 R 22 to 36 kg –...
  • Page 61 *: For SUBARU recommended child restraint systems, we recommend that you contact your SUBARU dealer. For other child restraint systems, refer to the applicable vehicle model list for the child restraint system or the child restraint system manufacturer’s web site for details.
  • Page 62: Installing Child Restraint Systems With Seatbelt

    Child Restraint Systems gency Locking Retractor (ALR/ELR) (if Installing Child Restraint Equipped)" P39. Systems with Seatbelt Preparation for installing child Installing a rearward facing child restraint system restraint system First check if the Automatic Locking WARNING Retractor (ALR) is equipped for the seatbelts of the vehicle according to the NEVER INSTALL...
  • Page 63 Child Restraint Systems 1. Place the child restraint system in the pushing it down into the seat cushion and rear seating position. then tightening the seatbelt. 6. To remove the child restraint system, press the release button on the seatbelt buckle.
  • Page 64 Child Restraint Systems 7. If your child restraint system is not equipped with a lock-off (a seatbelt locking feature), secure the child restraint system using a locking clip. 101753 101754 1) Lock-off lever 1) Lock-off lever 4. Release the child restraint system 6.
  • Page 65 Child Restraint Systems Models with ALR NOTE If using ALR mode is not recom- mended by the manufacturer’s instruc- tions supplied with the child restraint system, use the lock-off lever or the locking clip instead of using ALR mode. 1. Place the child restraint system in the rear seating position.
  • Page 66: Installing A Booster Seat Or Booster Cushion

    Child Restraint Systems buckle and allow the belt to retract completely. The belt will return to the ELR mode. NOTE When the child restraint system is no longer in use, remove it and restore the ELR function of the retractor. That function is restored by allowing the seatbelt to retract fully.
  • Page 67: Installation Of Child Restraint Systems Using Isofix Anchor Bars

    Child Restraint Systems Place the lap belt as low as possible on the child’s hips. A high-positioned belt will increase the risk of sliding under the lap belt and of the lap belt sliding up over the abdomen, and both can result in serious internal injury or death.
  • Page 68 Child Restraint Systems Your vehicle is equipped with ISOFIX manufacturer, connect the connectors of anchor bars that allow an approved the child restraint system to the anchor ISOFIX child restraint system to be bars. When the connectors are fastened, installed on the rear seat without use of a make sure that the adjacent seatbelts are seatbelt.
  • Page 69: Top Tether Anchorages

    Child Restraint Systems CAUTION When you install a child restraint system, follow the manufacturer’s instructions supplied with it. After installing the child restraint system, check to ensure that it is held securely in position. If it is not held tight and secure, the danger of your child suffering personal injury in the event of an accident may be increased.
  • Page 70 To hook the top tether anchorage. Anchorage location 3. Tighten the top tether securely. We recommend that contact your SUBARU Anchorages are installed as shown in the dealer have questions following illustration. regarding the installation of a child restraint system.
  • Page 71: Srs Airbag (Supplemental Restraint System Airbag)

    SRS Airbag (Supplemental Restraint System Airbag) 1-7. SRS Airbag (Supple- General Precautions The SRS side airbag and SRS mental Restraint System regarding SRS Airbag curtain airbag are designed only to be a supplement to the primary Airbag) System protection provided seatbelt.
  • Page 72 SRS Airbag (Supplemental Restraint System Airbag) Do not sit or lean unnecessarily WARNING WARNING close to the SRS airbag. Because Do not sit or lean unnecessarily The SRS airbags deploy with con- the SRS airbag deploys with close to either door. The SRS side siderable speed and force.
  • Page 73 SRS Airbag (Supplemental Restraint System Airbag) – These objects could be entan- gled with the steering wheel, preventing the SRS frontal airbag, etc. from operating properly. – If the SRS frontal airbag deploys, these objects could propelled inside vehicle, causing injury. Do not put any objects under the driver’s side of the instrument panel.
  • Page 74 SRS Airbag (Supplemental Restraint System Airbag) Never hang or place coat hangers WARNING WARNING or other hard or pointed objects Do not attach accessories to the Do not attach accessories to the near the side windows. If such door trim or near either SRS side windshield, or fit an extra-wide mir- items are present when the SRS airbags and do not place objects...
  • Page 75 P45. tion available to the front seat’s occupant. 100082 Do not install a seat cover unless it is a genuine SUBARU seat WARNING cover exclusively designed for use with the SRS airbag. Even Put children in the REAR seat prop-...
  • Page 76 SRS Airbag (Supplemental Restraint System Airbag) WARNING NEVER INSTALL A CHILD SEAT IN FRONT SEAT. DOING SO RISKS SERIOUS INJURY OR DEATH TO THE CHILD BY PLACING THE CHILD’S HEAD TOO CLOSE TO THE SRS AIRBAG. 100125 100166 WARNING Never hold a child on your lap or in your arms.
  • Page 77 SRS Airbag (Supplemental Restraint System Airbag) – Wrap his/her arms around the CAUTION front seat seatback. When the SRS airbag deploys, – Put his/her head, arms or some smoke will be released. other parts of the body out of This smoke could cause...
  • Page 78: Components

    SRS Airbag (Supplemental Restraint System Airbag) Components The SRS airbags are stowed in the following locations. Driver’s SRS frontal airbag: in the center portion of the steering wheel An “SRS AIRBAG” mark is located on the pad of the airbag. Front passenger’s SRS frontal airbag: near the top of the right side of dashboard An “SRS AIRBAG”...
  • Page 79 SRS Airbag (Supplemental Restraint System Airbag) 1) Front impact sensor (left-hand side) 2) Front impact sensor (right-hand side) 10 11 3) SRS airbag system warning light 4) Frontal airbag module (driver’s side) 5) Airbag control module (including impact sensors) 6) Front passenger’s frontal airbag ON and OFF indicator (if equipped) 7) Frontal airbag...
  • Page 80 SRS Airbag (Supplemental Restraint System Airbag) 1) Side impact sensor (rear wheel house left-hand side) 2) Airbag wiring 3) Side impact sensor (center pillar left- hand side) 4) Seatbelt pretensioner and adaptive force limiter equipped) (front passenger’s side) 5) Side airbag module (front passenger’s side) 6) Side impact sensor (door left-hand side) 7) Curtain airbag module (left-hand side)
  • Page 81: Srs Airbag

    In a moderate to severe frontal collision, senger occupant detection system. the following components deploy. In this case, contact your SUBARU SRS frontal airbag for driver dealer immediately. SRS frontal airbag for front passenger...
  • Page 82 Check (such as an audio amplifier) other "Reclining the seatback" P31. that the indicators work properly. than a genuine SUBARU acces- sory or an equivalent under the When the OFF indicator turns off and the front passenger’s seat. indicator...
  • Page 83 FRONT PASSENGER’S SRS FRON- The front passenger’s SRS frontal airbag by your SUBARU dealer immediately if TAL AIRBAG IS DEACTIVATED. Be will not be activated when any of the the SRS airbag system warning light illu-...
  • Page 84 The front passenger’s SRS frontal airbag described above, we recommend that you will be activated for deployment upon immediately contact your SUBARU dealer impact when any of the following condi- for an inspection. tions regarding front Even if the system has passed the dealer passenger’s seat.
  • Page 85: System Operation

    We recommend that you immediately 2. Ask the front passenger to set the contact your SUBARU dealer for an seatback to the upright position, sit up inspection. straight in the center of the seat cushion,...
  • Page 86 SRS Airbag (Supplemental Restraint System Airbag) SRS frontal airbag operation A) Driver’s side B) Passenger’s side 1) SRS AIRBAGs deploy as soon as a collision occurs. 2) After deployment, SRS AIRBAGs start to deflate immediately so that the driver’s vision is not obstructed. Knee airbag If the front impact sensors located on both the right and left sides at the front of the...
  • Page 87 SRS Airbag (Supplemental Restraint System Airbag) If the vehicle is equipped with the occu- When will the SRS frontal airbag At what other times might the pant detection system for the front most likely deploy? SRS frontal airbag deploy? passenger’s seat, the SRS system detects whether the front passenger’s seat is occupied by a passenger or not.
  • Page 88 SRS Airbag (Supplemental Restraint System Airbag) impacted or knocked hard against an obstacle on the road such as a curb). – CONTINUED –...
  • Page 89 SRS Airbag (Supplemental Restraint System Airbag) When is the SRS frontal airbag unlikely to deploy? 1) The vehicle strikes an object, such as a telephone pole or sign pole. 2) The vehicle slides under the load bed of a truck. 3) The vehicle sustains an oblique offset frontal impact.
  • Page 90 SRS Airbag (Supplemental Restraint System Airbag) When will the SRS frontal airbag SRS side airbag and SRS curtain not deploy? airbag operation 101395 1) First impact 2) Second impact 100281 The driver’s and front passenger’s SRS In an accident where the vehicle is side airbags and SRS curtain airbags impacted more than once, the SRS frontal deploy independently of each other since...
  • Page 91 SRS Airbag (Supplemental Restraint System Airbag) After the deployment, the SRS side airbag When will the SRS side airbag immediately starts to deflate. The time and SRS curtain airbag most required from detection of an impact to likely deploy? deflation of an SRS side airbag after deployment is shorter than the blink of an eye.
  • Page 92 SRS Airbag (Supplemental Restraint System Airbag) When are the SRS side airbags unlikely to deploy? 1) The vehicle is involved in an oblique side-on impact. 2) The vehicle is involved in a side-on impact in an area outside the vicinity of the passenger compartment.
  • Page 93 SRS Airbag (Supplemental Restraint System Airbag) When is the SRS curtain airbag unlikely to deploy? 1) The vehicle is involved in an oblique side-on impact. 2) The vehicle is involved in a side-on impact in an area outside the vicinity of the passenger compartment.
  • Page 94: Srs Airbag System Monitor

    SRS Airbag (Supplemental Restraint System Airbag) the first impact, they will not be activated 3) The vehicle pitches end over end. When will the SRS side airbag on the second. and SRS curtain airbag not In the event of accidents like those illus- deploy? trated, the SRS side airbag and SRS SRS airbag system monitor...
  • Page 95: Srs Airbag System Servicing

    - Front passenger’s side place, and we recommend that you the SRS airbag, we recommend Knee airbag module (driver’s side) consult a SUBARU dealer. Unless a that you consult your nearest Side impact sensor technician checks and repairs the SUBARU dealer. Tampering with...
  • Page 96: Precautions Against Vehicle Modification

    SUBARU parts at an authorized SUBARU inoperative, which may result in Modifications on or inside the dealer. serious injury, no modifications front door panels for the purpose should be made to any components...
  • Page 97 Attachment of any equipment (side steps or side sill protectors, etc.) other than genuine SUBARU accessory parts to the side body. We recommend that you always consult your SUBARU dealer if you want to install any accessory parts on your vehicle.
  • Page 98: Keys And Doors

    Keys and Doors 2-1. Keyless Access with Push-Button Start 2-3. Remote Keyless Entry System ......106 System ..............92 Locking the Doors ............107 Unlocking the Doors............ 107 Safety Precautions ............92 Automatic Locking ............107 Locking and Unlocking with “Keyless Access” Opening the Trunk Lid ..........107 Entry Function ..............95 Opening/Closing the All Windows Unlock Using PIN Code Access ........98...
  • Page 99: Keyless Access With Push-Button Start System

    Keyless Access with Push-Button Start System 2-1. Keyless Access with NOTE Push-Button Start System The remote keyless entry system can be used to control the following functions. The following access key fobs are Locking/unlocking doors, provided with the vehicle. trunk lid and fuel filler lid Opening/closing the windows (except Australia models) For detailed information, refer to...
  • Page 100 Keyless Access with Push-Button Start System The keyless access with push- The radio waves from the transmit- button start system uses radio ting antennas on the vehicle could waves of the following frequency* adversely affect the operation of in addition to the radio waves implanted pacemakers used for the remote keyless entry...
  • Page 101 Do not leave the access key replaced at an authorized access function is switched to the non- fob near a battery charger or SUBARU dealer to avoid the operational mode, refer to "Access Key any electrical accessories. risk of damage.
  • Page 102: Locking And Unlocking With “Keyless Access” Entry Function

    Inside the glove box radio waves are used, such as an SUBARU dealer. Inside the door trim pocket access key fob or a remote trans- For a spare access key fob, we On the rear seat mitter key of another vehicle.
  • Page 103 Keyless Access with Push-Button Start System When the access key fob is within either of keyless access function when the Operating ranges the operating ranges of the doors, the access key fob is inside the vehicle. LED indicator on the access key fob However, depending on the status of flashes.
  • Page 104 NOTE your SUBARU dealer. We recommend door lock sensor twice more to that you contact your SUBARU dealer It is not possible to lock the doors attempt the lock operation without first for details. The setting of the hazard...
  • Page 105: Unlock Using Pin Code Access

    (PIN code) is registered. Under the following conditions, the trunk can be opened without the key fob. The trunk lock/unlock setting is on. All doors are unlocked. The trunk lock/unlock setting can be changed by a SUBARU dealer. We rec-...
  • Page 106 Keyless Access with Push-Button Start System Registration for a PIN code Steps Operation Time from the previous step Turn off the ignition switch. Close all doors (including trunk). Press and hold the “ ” button on the access key fob, then press and hold the trunk opener button until a chirp sounds intermittently.
  • Page 107: Power Saving Function

    Keyless Access with Push-Button Start System NOTE The PIN code cannot be deleted Power Saving Function while the keyless access function is Press the trunk opener button ten To protect the access key fob battery and disabled by operating the access key times to enter “0”.
  • Page 108: Power Saving Function Of Access Key Fob

    Keyless Access with Push-Button Start System Open a door and then close it and push-button start system will not be dure described in "Starting Engine" available. P315. Turn the push-button ignition switch to To cancel the power save mode, press the “ON”...
  • Page 109 Keyless Access with Push-Button Start System By operating the driver’s door 204163 3. Press and hold the “ ” button and 204132 “ ” button on the access key fob simul- To disable the keyless access function by taneously for more than 5 seconds. operating the driver’s door, perform the A chirp sound will be heard, and the func- following procedures.
  • Page 110 Keyless Access with Push-Button Start System Enabling functions Steps Operation Time Status When the procedure to disable the func- Sit in the driver’s seat, and close the door. Close tions is performed again, a chirp sound Push “ ” on the power door locking will be heard, and the functions are Close switch.
  • Page 111: Selecting Hazard Warning Flasher Operation

    Access key fobs can be replaced at mation display. For details, refer to "Car SUBARU dealers. For more details, we settings" P159. The setting can also be recommend that you contact a SUBARU changed by a SUBARU dealer.
  • Page 112: 2-2. Immobilizer

    Do not leave spare keys or any SUBARU dealer. starting the engine. Only keys registered record of your key number in the Technical Information of the with your vehicle’s immobilizer system vehicle.
  • Page 113: Remote Keyless Entry System

    SUBARU dealer. We recommend that waves are sent and may affect the Opening the trunk lid you consult your SUBARU dealer for operation of the airplane. When details. Operate all windows (except Australia you carry the remote transmitter...
  • Page 114: Locking The Doors

    With the engine turned off, you can open purchase additional transmitters (up to can be changed by a SUBARU dealer. We and close the all windows by using the four can be programmed), you should re-...
  • Page 115: 2-4. Door Locks

    Door Locks 2-4. Door Locks How to lock the vehicle without Locking and Unlocking from using the key the Inside Locking and Unlocking from To lock the door from outside without the How to use the lock lever the Outside key, the following methods are available.
  • Page 116: Key Lock-In Prevention Function

    Door Locks you contact your SUBARU dealer for WARNING details. Keep all doors locked when you Non-operation of key lock-in drive, especially when small chil- prevention function dren are in your vehicle. When the system is set so that it does not...
  • Page 117: 2-5. Windows

    “operational”. The opera- When operating power The closing window slides down tional/non-operational setting of this windows, be extremely careful to slightly and stops. function can be changed by a SUBARU prevent anyone’s fingers, arms, opening window stops dealer. recommend that neck, head or other objects from sliding down.
  • Page 118: Power Window Operation

    Windows Passenger’s side power window Power Window Operation Operating the window switches: Power window switches Driver’s side power window switches: 202972 204165 With one-touch auto up and down Passenger’s window can be controlled by feature 204137 the power window switch located on the 1) Automatically close* door.
  • Page 119 Windows to be opened or closed. If the windows Anti-entrapment function Off delay function cannot be opened or closed, check the While closing the window automatically, if The windows can be operated for approx- fuses and replace them as necessary. the window senses a substantial enough imately 40 seconds even after the ignition Refer to "Fuses"...
  • Page 120: Initialization Of Power Window

    Trunk Lid 2-6. Trunk Lid Initialization of Power Before opening and closing the Window trunk, carefully check your surroundings to make sure it will WARNING If the one-touch auto up and down func- not strike any people or objects. tion or off delay function does not operate To prevent dangerous exhaust When loading and unloading properly, operate each window according...
  • Page 121: To Open And Close The Trunk Lid From Outside

    The trunk lid is equipped with All doors are unlocked. damper stays that hold the trunk The trunk lock/unlock setting can be lid in place. Observe the following changed by a SUBARU dealer. We rec- precautions. ommend that contact your Failure to do so may cause SUBARU dealer to change the setting.
  • Page 122: To Open The Trunk Lid From Inside

    Trunk Lid To Open the Trunk Lid from Inside 204140 Press and hold the trunk lid opener button for more than 1 second.
  • Page 124: Instruments And Controls

    Instruments and Controls 3-1. Push-Button Ignition Switch ......119 Brake System Warning Light (Red)......134 Vacuum Pressure System Warning Light Safety Precautions ............119 (Yellow)............... 134 Operating Range for Push-Button Start System ..119 Low Fuel Warning Light ..........134 Switching Power Status..........119 Door Open Indicator ............
  • Page 125 Meter Information Screen..........145 3-14.Turn Signal Lever..........176 Drive Information ............146 One-Touch Lane Changer ...........177 Exclusive Content for SUBARU BRZ ......148 3-15.Wiper and Washer..........177 Navigation System-Linked Display ......149 Windshield Wiper and Washer Switches ....178 Audio System-Linked Display........150 3-16.Headlight Washer..........
  • Page 126: Push-Button Ignition Switch

    Push-Button Ignition Switch 3-1. Push-Button Ignition close to the glass, it may be possible to Switching Power Status switch the power or to start the engine. Switch Do not leave the access key fob in the following places. It may become Safety Precautions impossible to operate the push-button Refer to "Safety Precautions"...
  • Page 127: When Access Key Fob Does Not Operate Properly

    We recommend automatically switched “OFF” used: “ACCESSORY” that you contact a SUBARU prevent the battery from going dead. (In audio and dealer immediately. AT models, this function is activated when accessory power outlet. the select lever is in the “P” position.)
  • Page 128: 3-2. Hazard Warning Flasher

    Hazard Warning Flasher 3-2. Hazard Warning Flasher 3-3. Meters and Gauges 2) Vehicle speed This screen displays the current vehicle NOTE speed. Liquid crystal displays are used in Tachometer some of the meters and gauges in the combination meter. You will find their The tachometer shows the engine speed indications hard to see if you wear in thousands of revolutions per minute.
  • Page 129: Odometer And Double Trip Meter

    Meters and Gauges Odometer and Double Trip Double trip meter Meter The trip meter shows the distance that the vehicle has been driven since you last set it to zero. CAUTION To ensure safety, do not attempt to change the function of the indicator during driving, as an accident could result.
  • Page 130: Fuel Gauge

    Meters and Gauges The fuel gauge shows the approximate The temperature gauge shows engine Fuel Gauge amount of fuel remaining in the tank. coolant temperature when the ignition switch is in the “ON” position. When the ignition switch is in the “OFF” or Except Europe Models “ACC”...
  • Page 131: Combination Meter Settings

    REV indicator light and buzzer 3-4. REV indicator light and 3-5. Illumination Brightness NOTE buzzer Control The outside temperature indicator shows the temperature around the sensor. However, the temperature may not be indicated correctly or the update may be delayed in the follow- ing conditions.
  • Page 132: Auto Dimmer Cancel Function

    SUBARU dealer. We recommend that you corresponding system. fastens the seatbelt.) contact your SUBARU dealer for details. We recommend that you consult your :SRS airbag system warning light authorized SUBARU dealer for repair.
  • Page 133: Seatbelt Warning Light And Chime

    If the est SUBARU dealer. seatbelt is fastened at this time, the warning light will turn off and the chime will Seatbelt warning for driver’s seat...
  • Page 134: Rear Seatbelt Indicator Light And Chime

    Warning and Indicator Lights Rear Seatbelt Indi- Do not remove or disassemble WARNING the front passenger’s seat. cator Light and Chime The driver must check that the all Do not place any objects passengers have fastened their (shoes, umbrella, etc.) under seatbelts properly since...
  • Page 135: Srs Airbag System Warning Light

    Do not apply any strong place, and we recommend that you impact to the rear seat. consult a SUBARU dealer. Unless a Do not fold the seatback technician checks and repairs the forward when objects are on system as needed, the seatbelt the seat.
  • Page 136: Malfunction Indicator Light (Check Engine Light)

    With the ignition switch turned to the “ON” vehicle checked/repaired by your possible. position, if both the ON and OFF indica- SUBARU dealer as soon as possi- tors remain illuminated or off simultane- ble. Continued vehicle operation The malfunction indicator light may stop...
  • Page 137: Coolant Temperature Low Indicator Light/Coolant Temperature High Warning Light

    We recommend engine is close to overheating measure listed below. that you contact your SUBARU dealer for Illumination in RED indicates over- an inspection. heating condition of the engine For the system check, this indicator light/...
  • Page 138: Charge Warning Light

    SUBARU dealer immediately. proper tire inflation pressure for those Charge Warning Light tires.) AT OIL TEMP Warning...
  • Page 139 TPMS Monitoring System checked at a four road wheels. We recommend malfunctions may occur for a variety of SUBARU dealer as soon as possi- that you contact your SUBARU reasons, including the installation of ble.
  • Page 140: Abs Warning Light

    The warning light illuminates right available opportunity by your pressure(s), the tire pressure moni- after the engine is started but turns off SUBARU dealer. toring system will not re-check tire immediately, remaining off. The warning light does not inflation pressures until the vehicle...
  • Page 141: Brake System Warning Light (Red)

    (with the parking WARNING case, drive the vehicle carefully and have brake fully released and with the ignition the system inspected by a SUBARU Driving with the brake system switch positioned in “ON”), it could be an dealer.
  • Page 142: Power Steering Warning Light

    The steering wheel is operated at a SUBARU dealer as soon as frequently and turned sharply while the possible. vehicle is maneuvered at extremely low speeds, such as while frequently...
  • Page 143: Vehicle Stability Control (Vsc) Off Indicator Light

    The warning light illuminates right SUBARU dealer as soon as possible. after the engine is started but turns off The light does not turn off even after immediately and remains off.
  • Page 144: Warning Chimes And Warning Indicator Of The Keyless Access With Push-Button Start System

    Warning and Indicator Lights you consult your SUBARU dealer for engine start provided Warning Chimes and details. depending on the status of the access Warning Indicator of the key fob and the environmental condi- Keyless Access with Push- WARNING tions.
  • Page 145 Warning and Indicator Lights Inside warning Outside warning Status Action chime chime Switch the push-button ignition switch to “OFF”, or The driver’s door is opened while the push-button close the driver’s door. ignition switch is “ACC”. (in AT models, when the When exiting the vehicle, be sure to switch the Ding, ding ...
  • Page 146 Warning and Indicator Lights Inside warning Outside warning Status Action chime chime Access key warning for engine start: Carry the access key fob, and press the push-but- Ding The push-button ignition switch is pressed while ton ignition switch. the access key fob is not inside the vehicle. Access key takeout warning: The driver exits the vehicle with the access key fob Beep, beep, beep...
  • Page 147 Warning and Indicator Lights Inside warning Outside warning Status Action chime chime System malfunction warning: We recommend that you contact a SUBARU dealer Ding A malfunction is detected in the power system or immediately and have the vehicle inspected. steering lock.
  • Page 148: Immobilizer Indicator Light

    If the indicator light does not blink in the above conditions, it may indicate that immobilizer system may be malfunc- 702774 tioning. Contact your nearest SUBARU 1) Upshift indicator dealer immediately. 2) Downshift indicator (AT models only) In the event that an unauthorized key (for...
  • Page 149: Cruise Control Warning Light (Yellow)

    Warning and Indicator Lights you contact your SUBARU dealer for an your vehicle inspected by your SUBARU Gear shift indicator (MT models) inspection. dealer as soon as possible. When shifting up is recommended for good fuel economy, the upshift indicator...
  • Page 150: Led Headlight Warning Light

    This light illuminates if the LED headlights malfunction. We recommend that you Rear Fog Light Indi- This indicator appears on the combination have your vehicle inspected at a SUBARU meter display (color TFT) when “SRVD” is cator Light (If dealer as soon as possible.
  • Page 151: Rab Warning Indicator (If Equipped)

    When the gasoline particulate filter Equipped)" P263. warning light flashes, we recommend that Master Warning Light you consult the nearest SUBARU dealer RAB OFF Indicator (If for an immediate inspection. Equipped) A buzzer sounds and the warning light comes on and flashes to indicate that the...
  • Page 152: Combination Meter Display (Color Tft)

    Drive information Also, a warning message will appear on the display if a malfunction is detected. In Exclusive content for addition, several settings for the displayed SUBARU BRZ content can be performed. 149 and refer to the separate Navigation system-linked...
  • Page 153: Drive Information

    Combination Meter Display (Color TFT) Drive Information Drive information (page 2) Icons Page Audio system-linked dis- Drive information (page 1) play Refer to Owner’s Manual EyeSight screen (if supple- equipped) ment for the Eye- Sight sys- tem. Driving support system set- tings display 306877 Settings display...
  • Page 154 Combination Meter Display (Color TFT) When only a small amount of fuel is NOTE 3) Driving distance added to the tank, the display may not be tire pressure values This screen displays the average vehicle updated. When refueling, turn the push- displayed several minutes...
  • Page 155: Exclusive Content For Subaru Brz

    Press and hold to change the range of Exclusive Content for the actual condition of the vehicle. the acceleration G-force display between SUBARU BRZ 1.0 G and 0.5 G. Press and hold to reset the record of G-force maximum G-forces.
  • Page 156: Navigation System-Linked Display

    Combination Meter Display (Color TFT) 5) Past lap times Stopwatch Navigation System-Linked 6) Meter control switch operation guide Display When the timer is reset, “ ’ ” ” will be displayed. A maximum of 50 lap times can be recorded. Changing between stopwatch...
  • Page 157: Audio System-Linked Display

    Combination Meter Display (Color TFT) Audio System-Linked Driving Support System Display Settings Display The setting adjustments to the following systems can be changed to meet your personal requirements. *1*2 LDW (Lane Departure Warning) *1*2 PCB (Pre-Collision Braking) SRVD (Reverse Automatic Braking system) 306813...
  • Page 158 Combination Meter Display (Color TFT) Page reference for Item Settings the vehicle system operation Acquisition Sound ON/OFF Start Alert ON/OFF EyeSight Accel Lv. Lv.1 (Eco)/Lv.2 (Comfort)/Lv.3 (Standard)/Lv.4 (Dynamic) Select Drive Lane Right Lane/Left Lane Max/Mid/Min 263 and *2 Warning Volume Startup Scrn ON/OFF GSI (MT models)
  • Page 159: Warning Message Display

    Vacuum pressure sys- tem warning light (yel- low) 306794 306959 Subaru Rear Vehicle Example of warning 1) Telltale screen Detection warning indi- If there is a warning message or a mainte- cator (if equipped) When the corresponding situation occurs,...
  • Page 160: Center Information Display (Cid)

    Center Information Display (CID) 3-8. Center Information Mark Name Page Items Page Display (CID) Cruise control indica- Refer to tor light (white/green)/ the sepa- Cruise control warning rate navi- WARNING light (yellow) (models Navigation system (if equipped) gation/ without the EyeSight audio Always pay attention to safe driving system)
  • Page 161: Touch Screen Operations

    Center Information Display (CID) combination meter display (color TFT) Quickly move the screen by swiping with Drag can be changed. For details, refer to your finger. "Car settings" P159. NOTE images displayed this Owner’s Manual are sample images. Swipe operations may not be per- The actual image may vary depending formed smoothly in high altitudes.
  • Page 162 Center Information Display (CID) General settings Set the time and display general items. 306805 1. Press (HOME). (Settings) “General” 4. Select the preferred menu. – CONTINUED –...
  • Page 163 Center Information Display (CID) The setting adjustments to the following items can be manually changed to meet your personal requirements. Item Page reference Page reference for the vehicle Available settings for the setting system opera- 1st menu 2nd menu 3rd menu procedure tion Auto/Manual...
  • Page 164 Center Information Display (CID) Item Page reference Page reference for the vehicle Available settings for the setting system opera- 1st menu 2nd menu 3rd menu procedure tion Maintenance ON/OFF Reminder Screen Birthday ON/OFF Anniversary ON/OFF Startup Screen ON/OFF Gear Shift Indicator (MT mod- ON/OFF els) Meter Screen...
  • Page 165 Center Information Display (CID) Item Page reference Page reference for the vehicle Available settings for the setting system opera- 1st menu 2nd menu 3rd menu procedure tion Update Check if a new software update Automatically Check for ON/OFF Software Update Updates Automatically Download ON/OFF...
  • Page 166 Center Information Display (CID) Car settings Perform the EyeSight system setting and vehicle setting. 306806 1. Press (HOME). (Settings) “Car” 4. Select the preferred menu. – CONTINUED –...
  • Page 167 Keyless entry system 30 seconds/60 seconds/120 Security Relocking seconds/OFF Demister 15 minutes/Continuous 7.5 seconds/15 seconds/30 Interior Light seconds One-Touch Lane Changer ON/OFF SUBARU Rear Vehicle Detec- ON/OFF tion Steering Responsive Head- ON/OFF lights (SRH) Min/Mid/Max 260, 272 and *2 Warning Volume...
  • Page 168 Center Information Display (CID) *1: If equipped *2: For details about EyeSight system, refer to the Owner’s Manual supplement for the EyeSight system. NOTE Touch to display the explanation of the items. – CONTINUED –...
  • Page 169 Center Information Display (CID) Car settings icon Touch to display the items that are changeable while driving. 307003...
  • Page 170 ON/OFF Headlights (SRH) Pre-Collision Braking Setting ON/Setting OFF Lane Departure Driving Assistance ON/OFF Warning SUBARU Rear Vehi- ON/OFF cle Detection Others Warning Volume Min/Mid/Max 255, 263 and *2 *1: If equipped *2: For details about EyeSight system, refer to the Owner’s Manual supplement for the EyeSight system.
  • Page 171 Center Information Display (CID) “Brightness/Contrast” How to select items on the screen Selecting ON/OFF setting 306873 306872 6. Drag to adjust the brightness and Example 306871 contrast. Touch the preferred item. Example Touch “Default” to revert to the factory setting. Touch the changing menu and select ON How to set items on the screen or OFF...
  • Page 172 Center Information Display (CID) Maintenance XXXX 306999 307001 “Add” 8. Enter the date. 306164 “OK” Maintenance reminders can be set. Engine oil setting: NOTE 1. Touch (Maintenance). A maximum of 5 birthdays can be stored. (Engine Oil) 3. Select “Notification Date” or “Notifica- Anniversary List tion Distance”...
  • Page 173: 3-9. Clock

    Clock 3-9. Clock Maintenance Schedule setting: The setting procedure is the same as For models with a genuine SUBARU navi- “Engine Oil” setting, but touch the “Mainte- gation and/or audio system, the clock can nance Schedule” item in step 2.
  • Page 174: Setting The Clock Automatically

    Clock NOTE Setting the Clock Automati- cally For models without navigation sys- tem: Depending on the model of 1. Turn the ignition switch to the “ON” smartphone, the settings of the con- position. nected smartphone may need to be changed. (ex: For iOS or other models, notification settings may need to be activated.) For details, check the instructions...
  • Page 175: 3-10.Light Control Switch

    Light Control Switch 3-10. Light Control Switch conditions, a chirp sound will inform “AUTO” position: auto on/off head- the driver that the lights are illumi- lights nated. When the ignition switch is in the “ON” CAUTION position, the instrument panel illumination, Headlights Use of any lights for a long period headlights, front position lights, tail lights...
  • Page 176 The ignition switch is turned to the “ON” mately 1 minute after the wiper stops. position. The ON/OFF setting of this function can The doors are locked. be changed by a SUBARU dealer. We The light control switch is turned to a recommend that consult your position other than “AUTO”.
  • Page 177: High/Low Beam Change (Dimmer)

    If this happens, we recom- lights 304881 mend that you have your vehicle inspected by your SUBARU dealer as While the light control switch is in the “ ” soon as possible. or “AUTO” position in a dark place, the The light sensor may not operate headlights will turn on.
  • Page 178: Headlight Flasher

    For more details, we recommend that beam. Do not hold the lever in the flashing you contact a SUBARU dealer for an position for more than just a few When the vehicle speed increases to or inspection.
  • Page 179 Light Control Switch At this time, the high beam assist function disturb the oncoming vehicle or vehicle will turn off, the high beam assist indicator ahead. Also, the low beam mode may will turn off and the high beam indicator continue although there are no oncoming light will turn on.
  • Page 180: Daytime Running Light System

    Light Control Switch - When the rear part of the vehicle by a street light, traffic signal, illumination Daytime Running Light ahead, such as a container, reflects of an advertisement board, or a reflective System light strongly. object such as a road sign and signboard. - When the headlights of your vehicle The timing of the change of headlight WARNING...
  • Page 181: 3-11.Steering Responsive Headlight (Srh)

    (color TFT) illuminates SRH is not activated indicates that SRH has been deactivated. when SRH is turned off. Contact a SUBARU dealer for an inspec- SRH is a function that automatically tion. moves the headlight beam to the left or...
  • Page 182: 3-12.Headlight Beam Leveler

    ” posi- light alignment checked tion with the low beam mode selected. SUBARU dealer. The headlight switch is in the “AUTO” position and the low beam headlights turn on automatically. To turn off the rear fog light: Turn the fog light switch back down to the “OFF”...
  • Page 183: 3-14.Turn Signal Lever

    Turn Signal Lever 3-14. Turn Signal Lever headlight switch is set to the “ ” position or the ignition switch is turned to the “ON” position again. So, if you want to reilluminate the rear fog light, turn the fog light switch to the “...
  • Page 184: One-Touch Lane Changer

    10 seconds, obstruction on the window, this be changed by a SUBARU dealer. We or when the washer fluid tank is might cause the wiper motor to recommend that you contact the near- empty.
  • Page 185: Windshield Wiper And Washer Switches

    In these cases, we recommend that paint thinner or benzine. This will cloth with a neutral detergent or mild- you contact your SUBARU dealer. cause deterioration of the wiper abrasive cleaner. Do not, however, use blades.
  • Page 186 Wiper and Washer Windshield wipers /INT : Intermittent : Low speed : High speed To turn the wipers on, push the wiper control lever down. To turn the wipers off, return the lever to the “ /OFF” position. For a single wipe of the wipers, push the lever up.
  • Page 187: 3-16.Headlight Washer

    Headlight Washer 3-16. Headlight Washer Windshield washer CAUTION Do not operate the washer if the washer fluid tank is empty. This may cause overheating of the washer motor. Check washer fluid level fre- quently, such as at fuel stops. NOTE When the area around the nozzle cover of the headlight washer is frozen, remove the ice before using.
  • Page 188: 3-17.Defogger

    Defogger 3-17. Defogger It is possible to set the defogger system for the continuous operation mode by operating the center information display. For details, refer to "Car settings" P159. CAUTION To prevent the battery from being discharged, do not operate the defogger system continuously for any longer than necessary.
  • Page 189: 3-18.Mirrors

    Mirrors 3-18. Mirrors NOTE Outside Mirrors The mirrors can also be adjusted man- Remote control mirror switch Always check that the inside and outside ually. mirrors are properly adjusted before you start driving. Power folding mirror switch Inside Mirror 306821 : Select side to adjust : Direction control 306822...
  • Page 190: 3-19.Tilt/Telescopic Steering Wheel

    Tilt/Telescopic Steering Wheel 3-19. Tilt/Telescopic Steering depending on the status of the power When the temperature is low, the folding mirror switch. outside mirrors may stop during oper- Wheel If the outside mirrors have been ation. Push the switch again. When the manually folded slightly forward of the outside mirrors do not work by oper- WARNING...
  • Page 191: 3-20.Horn

    Horn 3-20. Horn 2) Telescopic adjustment 3) Tilt/telescopic lock lever 1. Adjust the seat position. Refer to "Front Seats" P28. 2. Pull the tilt/telescopic lock lever down. 3. Move the steering wheel to the desired level. 4. Pull the lever up to lock the steering wheel in place.
  • Page 192: Climate Control

    Climate Control 4-1. Ventilator Control..........186 4-6. Operating Tips for Heater and Air Conditioner ..........192 Center Ventilators............186 Side Ventilators ............186 Cleaning Ventilator Grille..........192 4-2. Climate Control Panel.........186 Efficient Cooling after Parking in Direct Sunlight ..192 4-3. Automatic Climate Control Operation....188 Lubrication Oil Circulation in the Refrigerant Circuit .................
  • Page 193: Ventilator Control

    Ventilator Control 4-1. Ventilator Control 4-2. Climate Control Panel Side Ventilators Center Ventilators WARNING The cooling function operates only when the engine is running. Do not leave children or adults who would normally require the support of others alone in your vehicle.
  • Page 194 Climate Control Panel 1) Set temperature indicator (left-hand side) 2) Temperature control dial (left-hand side) (Refer to "Temperature Control" P190.) 3) Climate control mode indicator 4) Fan speed control dial (Refer to "Fan Speed Control" P190.) 5) Temperature control dial (right-hand side) (Refer to "Temperature Control"...
  • Page 195: Automatic Climate Control Operation

    Automatic Climate Control Operation 4-3. Automatic Climate The controllable temperature range Sensors may vary depending on the regional Control Operation specifications of the vehicle. If you operate any of the buttons on When this mode is selected, the fan the control panel other than the ON/ speed, airflow mode, air inlet selection, OFF button, rear window defogger and air conditioner operation are automat-...
  • Page 196: 4-4. Manual Climate Control

    Manual Climate Control 4-4. Manual Climate Control and become damaged, the system may not be able to control the interior tempera- ture correctly. To avoid damaging the Airflow Mode Selection sensors, observe the following precau- Select the airflow mode using the airflow tions: mode selection button.
  • Page 197: Temperature Control

    Manual Climate Control Heat-def: Windshield defroster outlets, SYNC mode foot outlets and both side outlets of the When the SYNC mode is turned on, both instrument panel the driver’s and front passenger’s side temperatures are synchronized using the Temperature Control driver’s side temperature control dial.
  • Page 198: Air Inlet Selection

    Defrosting 4-5. Defrosting To turn off the air conditioner, press the button to the OFF position in the following button again. The indicator light will turn cases. off. - When the road is no longer dusty - When the interior has cooled to a NOTE comfortable temperature For efficient defogging or dehumidify-...
  • Page 199: Operating Tips For Heater And Air Conditioner

    We recommend clean because cooling performance is that have the air conditioning system impaired by any accumulation of insects checked by your SUBARU dealer. and leaves on the condenser.
  • Page 200: Cooling And Dehumidifying In High Humidity And Low Temperature Weather Condition

    We recommend that you consult your from the air outlets may be noticed. This SUBARU dealer for service. condition is normal and does not indicate Repairs needed as a result of using the...
  • Page 201: 4-7. Air Filtration System

    We recommend that you contact (3) Push both sides of the glove box Left-hand drive models your SUBARU dealer if the follow- inward to unlock the stoppers and then 1) Link pocket ing occurs, even if it is not yet time pull down the glove box as far as it will go.
  • Page 202 Air Filtration System prevent dust on the air cleaner from falling to the inside of its housing. (1) Pinch both tabs and remove the filter cover. (2) Gently tilt down the end of the filter and slowly pull it out 1 cm (0.4 in). (3) Slowly pull out the rest of the filter.
  • Page 204: Audio

    Audio 5-1. Antenna..............198 5-2. Audio Set .............198 Roof Antenna ..............198...
  • Page 205 501618 engine is not running. The roof antenna is installed on the roof. If your vehicle is equipped with a genuine SUBARU navigation system (if equipped) or audio system, refer to the separate navigation system/audio Owner’s Manual for details.
  • Page 206: Interior Equipment

    Interior Equipment 6-1. Interior Light ............200 6-4. Bottle Holders............203 6-5. Accessory Power Outlets........203 Map Lights..............200 OFF Delay Timer ............200 6-6. USB Power Supply..........204 6-2. Sun Visors ............201 How to Use the USB Power Supply ......205 Vanity Mirror with Light ..........201 6-7.
  • Page 207: 6-1. Interior Light

    NOTE The setting for the period of time in which the lights remain on (OFF delay 602245 timer) can be changed by a SUBARU 1) Door interlock switch dealer. We recommend that you con- tact your SUBARU dealer for details.
  • Page 208: 6-2. Sun Visors

    Sun Visors 6-2. Sun Visors 6-3. Storage Compartment CAUTION Keep the storage compartment closed when it is not being used. If left open, in the event of sudden braking, etc., stowed items may fly out, possibly leading to an accident. Do not store the following items storage compartment.
  • Page 209: Glove Box

    Storage Compartment To open the center console, push on the Glove Box button lightly and it will automatically open. Cup Holder and Console Tray CAUTION Take care to avoid spills. Bever- ages, if hot, might burn you and/ your passengers. Spilled beverages may also damage...
  • Page 210: 6-4. Bottle Holders

    Bottle Holders 6-4. Bottle Holders 6-5. Accessory Power CAUTION Outlets Do not attempt to use a cigarette CAUTION lighter in the accessory power Do not pick up a bottle from the outlet. bottle holder or put a bottle in the Do not place any foreign objects, holder while you are driving, as especially metal ones such as...
  • Page 211: 6-6. Usb Power Supply

    USB Power Supply 6-6. USB Power Supply If the plug on your electric appli- If a device is connected for a long ance is either too loose or too time when the engine is not tight for the accessory power running, doing so may cause the CAUTION outlet, this can result in a poor...
  • Page 212: How To Use The Usb Power Supply

    Ashtray (Dealer Option) 6-7. Ashtray (Dealer Option) cable is used. In this case, be sure to When the ignition switch is in the “ACC” or connect the device using the special “ON” position, the power can be supplied cable. to the electronic device. Up to 5 V/2.1 A CAUTION When a device that communicates can be supplied from each terminal (total...
  • Page 213: 6-8. Floor Mat

    SUBARU floor mat designed with grommets in the correct loca- tions. Make sure that the driver’s floor mat is placed back in its proper location and is correctly secured on its retaining pins.
  • Page 214: Under-Floor Storage Compartment (Models With The Flat Tire Repair Kit)

    Under-Floor Storage Compartment (models with the flat tire repair kit) 6-9. Under-Floor Storage 2. Turn the upper knob of each retaining hook (clip) to secure the floor mats in CAUTION Compartment (models with place. the flat tire repair kit) Always keep the lid of the A: Always align the “...
  • Page 216: Starting And Operating

    Starting and Operating 7-1. Fuel...............211 Disc Brake Pad Wear Warning Indicators ....232 7-10.ABS (Anti-Lock Brake System)......232 Fuel Requirements ............211 Fuel Filler Lid and Cap ..........212 ABS Self-Check............233 7-2. Preparing to Drive..........215 ABS Warning Light ............233 7-11.Electronic Brake Force Distribution (EBD) 7-3.
  • Page 217 Canceling the Reverse Automatic Braking (RAB) Viewing Range on the Screen........252 System Operation ............272 Help Lines ..............253 Reverse Automatic Braking (RAB) System 7-19.Subaru Rear Vehicle Detection (SRVD) ON/OFF Setting ............272 (If Equipped) ............255 RAB Warning Indicator ..........273 System Features ............256...
  • Page 218: 7-1. Fuel

    7-1. Fuel Use of ethanol blended petrol Bioethanol fuel sold under names such as “E50” or “E85” and fuel SUBARU allows the use of ethanol Fuel Requirements containing a large amount of blended petrol if the ethanol content is up ethanol should not be used.
  • Page 219: Fuel Filler Lid And Cap

    In areas where the impurity content in the fuel is high 702054 When you find these types of fuel labels at Add a bottle of genuine SUBARU fuel 702786 the petrol station, use only the fuel with additive to the fuel every 15,000 km one of the above labels.
  • Page 220 Fuel Press the unlock side of the power When opening the cap, grasp it door locking switch. firmly and turn it slowly to the left. 3. The fuel filler lid opens automatically. Do not remove the cap quickly. Open it further by hand. Fuel may be under pressure and spray out of the fuel filler neck, WARNING...
  • Page 221 SUBARU Limited Warranty. these operations are performed when create a fire hazard. Always use a genuine SUBARU the fuel filler lid is open, the fuel filler fuel filler cap. If you use the lid will not lock when it is subsequently 6.
  • Page 222: 7-2. Preparing To Drive

    Preparing to Drive 7-2. Preparing to Drive If the fuel filler lid cannot be opened If the fuel filler lid cannot be opened due to You should perform the following checks a malfunction or a dead battery, it can be and adjustments every day before you opened from the trunk.
  • Page 223: Starting And Stopping Engine

    Starting and Stopping Engine 7-3. Starting and Stopping Do not start the engine near dry CAUTION Engine foliage, paper, or other flammable Small animals trapped in the cool- substances. The exhaust pipe ing fan and belt of the engine may exhaust emissions Safety Precautions...
  • Page 224: Starting Engine

    We recommend that you contact switch. Instead, press the push- brand of fuel. your SUBARU dealer immedi- button ignition switch without rare occasions, transient ately.
  • Page 225 Starting and Stopping Engine (MT models) or the brake pedal (AT NOTE models) to switch the power to “OFF”. In case the engine does not start by If the light had illuminated, try to the normal engine start procedure, start the engine again. move the shift lever to the neutral If the light had been off, press the position, and switch the power to...
  • Page 226: Stopping Engine

    Not Operate Properly The engine will stop, and the power will be safe place, and we recommend Refer to "Access Key Fob – If Access Key switched off. that you contact a SUBARU Fob Does Not Operate Properly" P314. dealer immediately. WARNING...
  • Page 227: 7-4. Manual Transmission

    When the display of warning released messages There may be a malfunction in the steering lock function. Immediately we recommend that you contact your nearest SUBARU dealer. 702834 702836 This manual transmission is a completely 1) Push-button ignition switch synchromesh, 6-forward-speed and 1- reverse-speed transmission.
  • Page 228: Shifting Speeds

    Manual Transmission Do not engage the clutch (i.e., Shift up km/h (mph) release clutch pedal) 4th to 5th 42 (26) to 69 (43) suddenly when starting 5th to 6th 55 (34) to 83 (52) vehicle. By doing so the vehicle might unexpectedly accelerate or Gear shift indicator the transmission could malfunc-...
  • Page 229: Driving Tips

    Automatic Transmission 7-5. Automatic Transmission When it is necessary to reduce vehicle Driving Tips speed due to slow traffic, turning corners, or driving up steep hills, downshift to a The automatic transmission is electroni- lower gear before the engine starts to cally controlled and provides 6 forward WARNING speeds and 1 reverse speed.
  • Page 230: Select Lever

    Automatic Transmission shift to the normal timing after the Select Lever Do not race the engine for more engine has warmed up. than 5 seconds in any position Immediately after transmission fluid except the “N” or “P” position is replaced, you may feel that the trans- when the brake is applied or when mission operation...
  • Page 231: Adaptive Control

    Automatic Transmission position using the shift paddles. For P (Park) WARNING details about the manual mode, refer to This position is for parking the vehicle and "Selection of Manual Mode" P226. Do not drive the vehicle with the starting the engine. In this position, the Once the vehicle speed stabilizes, the select lever in the “N”...
  • Page 232: Shift Lock Function

    Automatic Transmission When driving uphill, prevents unneces- Depress the brake pedal first, and then sary upshifting and downshifting. operate the select lever. When driving downhill, downshifting is Only the “P” position allows you to turn performed at engine speeds higher than the push-button ignition switch to the usual.
  • Page 233: Selection Of Manual Mode

    We paddle is operated, except in the following recommend that you contact a SUBARU situations. dealer for an inspection as soon as When...
  • Page 234: Driving Tips

    Automatic Transmission If the temperature of the transmis- The selected gear, from “M1” to “M6”, will gravel covered road), you can start off sion fluid becomes too high, the “AT be displayed on the combination meter. from a standstill safely and easily by first OIL TEMP”...
  • Page 235: Driving Mode Select Switch (If Equipped)

    Driving Mode Select Switch (If Equipped) 7-6. Driving Mode Select If the mode is changed to Sport mode Use Snow mode for accelerating and while driving with the select lever in the “D” driving on slippery road surfaces such as Switch (If Equipped) position, the selected gear, from “D1”...
  • Page 236: 7-7. Active Sound Control

    The operational/non-operational set- Sport mode. ting of the Active Sound Control can If a malfunction occurs in the engine be changed by a SUBARU dealer. We or automatic transmission electrical recommend that you contact your control system while Sport mode or SUBARU dealer for details.
  • Page 237: 7-9. Braking

    Drive carefully to function of the power steering control Never rest your foot on the brake the nearest SUBARU dealer and we system. pedal while driving. This can cause recommend that you have the vehi-...
  • Page 238: Brake System

    Braking harder than normal and the braking Braking when a tire is punctured CAUTION distance will increase. Do not depress the brake pedal suddenly When you need to brake suddenly, when a tire is punctured. This could cause Supplemental booster function continue depressing brake...
  • Page 239: Disc Brake Pad Wear Warning Indicators

    The operational/non-operational setting of WARNING reduces the possibility of a collision. the Emergency Stop Signal can be changed by a SUBARU dealer. For Always use the utmost care in driv- CAUTION details, we recommend that you contact ing – overconfidence because you your SUBARU dealer.
  • Page 240: Abs Self-Check

    Electronic Brake Force Distribution (EBD) System 7-11. Electronic Brake Force ABS Self-Check When tire chains are installed, Distribution (EBD) System stopping distances You may feel a slight shock in the brake longer for a vehicle with the ABS pedal and hear the operating noise of the than one without.
  • Page 241: Ebd System Malfunctions

    In the event of wheelspin and/or skidding mend that you have the brakes on a slippery road surface and/or during inspected by a SUBARU dealer cornering and/or an evasive maneuver, immediately. the Vehicle Stability Control (VSC) system adjusts the engine’s output and the...
  • Page 242: Trc System

    Vehicle Stability Control the Vehicle Stability Control (VSC) opera- authorized SUBARU dealer. (VSC) system and TRC system, tion indicator light. The TRC system is winter tires should be used when...
  • Page 243: Vehicle Stability Control (Vsc) System Monitor

    Vehicle Stability Control (VSC)/TRC System vehicle steering wheel Disabling the TRC System All four wheels should be shakes to a small degree. fitted with tires of the same If the vehicle gets stuck in mud, dirt or An operating noise from the engine size, type, and brand.
  • Page 244 Vehicle Stability Control (VSC)/TRC System (VSC) system and TRC system except the brake control system is activated, under above-mentioned situations. the Vehicle Stability Control (VSC) operation indicator light flashes. NOTE When the switch has been pressed to deactivate the Vehicle Stability Control (VSC) system and TRC system, the Vehicle Stability Control (VSC) system and TRC system automatically...
  • Page 245: 7-13.Track Mode

    TRACK Mode 7-13. TRACK Mode The TRACK indicator and Vehicle Stability Control (VSC) OFF indicator come on when in TRACK mode. TRACK Mode To change back to normal mode while in Your vehicle is equipped with two types of TRACK mode, press Vehicle Stability control modes to accommodate various Control (VSC) OFF switch or the TRACK driving preferences.
  • Page 246: Selecting Trc Mode And Vehicle Stability Control (Vsc) Mode

    Tire Pressure Monitoring System (TPMS) (If Equipped) 7-14. Tire Pressure Moni- Selecting TRC Mode and Vehicle Stability Control (VSC) Mode toring System (TPMS) (If Modes can be selected to suit your driving conditions as follows: Equipped) Vehicle Sta- Driving con- bility Con- Brake LSD TRC modes...
  • Page 247: 7-14.Tire Pressure Monitoring System (Tpms)

    Refer to "Tires and Wheels" to monitor all four road wheels. occur. P351. The tire pressure moni- Contact your SUBARU dealer as (1) Keep driving straight ahead toring system does not function soon as possible for tire and while gradually reducing speed.
  • Page 248: (If Equipped)

    2. Adjust the tire inflation pressure to the imately one minute, promptly specified cold tire inflation pressure level. contact a SUBARU dealer to have Refer to "Tires" P377. the system inspected. Make sure to adjust the tire pressure to...
  • Page 249: If You Press The Tire Pressure Monitoring Reset Switch Accidentally

    ID codes can be registered inflation pressure to the specified level the vehicle checked at your SUBARU at your SUBARU dealer or repairer, or and initialize the tire pressure monitoring dealer. another duly qualified and equipped system again.
  • Page 250: 7-15.Parking Your Vehicle

    Parking Your Vehicle 7-15. Parking Your Vehicle 2. Press the TPMS set switch 3 times within 3 seconds. 3. The low tire pressure warning light will WARNING illuminate for 3 seconds and then blink 3 Never leave unattended children times. or pets in the vehicle.
  • Page 251: Parking Tips

    Hill Start Assist System 7-16. Hill Start Assist System When parking on a hill, always turn the The braking power of the parking steering wheel. When the vehicle is brake may not be sufficient when headed up the hill, the front wheels should stronger braking power is needed WARNING be turned away from the curb.
  • Page 252 Hill Start Assist System In both these cases, the Hill start assist system operates under the following conditions. The clutch pedal is depressed while the brake pedal is also depressed (MT models). The vehicle has stopped with the brake pedal depressed (AT models). Braking power is maintained temporarily (for approximately 2 seconds) by the Hill start assist system after the brake pedal is...
  • Page 253: To Activate/Deactivate The Hill Start Assist System

    Hill Start Assist System While the Hill start assist indicator light NOTE To Activate/Deactivate the is illuminated. Refer to "Hill Start Assist Hill Start Assist System If you make an error when performing Indicator Light" P143. any steps in the following procedure, When using the Hill start assist system, a place the ignition switch in the “OFF”...
  • Page 254: Hill Start Assist Indicator Light

    Cruise Control (Models without the EyeSight system) 7-17. Cruise Control (Models 4. Confirm the following items. 8. Turn the ignition switch to the “OFF” position. Hill start assist is deactivated. (1) The ABS warning light turns off. without the EyeSight system) (2) The brake system warning light illu- NOTE minates.
  • Page 255: To Set Cruise Control

    Cruise Control (Models without the EyeSight system) To Set Cruise Control When using the cruise control, always set the speed appropri- ately according to the speed limit, traffic flow, road conditions, and other conditions. NOTE Make sure the cruise control system is turned off when the cruise control is not in use to avoid unintentionally setting of the cruise control.
  • Page 256: To Temporarily Cancel The Cruise Control

    Cruise Control (Models without the EyeSight system) NOTE accelerator pedal to accelerate the vehicle. When the accelerator pedal is When setting a cruise speed for the released, the vehicle will return to and first time during a drive, both “-SET” maintain the previous cruising speed.
  • Page 257: To Change The Cruising Speed

    Cruise Control (Models without the EyeSight system) The set speed can be decreased 1 km/h To Change the Cruising To increase the speed (by acceler- (0.6 mph) each time by pushing the cruise ator pedal) Speed control switch to the “-SET” side. 1.
  • Page 258: 7-18.Rear View Camera

    Use of a fuse with a A rear view camera is attached to the SUBARU dealer for an inspection. different rating may result in a trunk lid. When the ignition switch is in the Continued use may result in acci- malfunction.
  • Page 259: How To Use The Rear View Camera

    Rear View Camera When waxing the vehicle, be careful vehicle. When the lever is set to other To turn the function on and off, refer to not to apply the wax to the camera. If it positions, the image before setting to “R” "General settings"...
  • Page 260: Help Lines

    Rear View Camera Range of view 601498 601103 601105 Range of view Image from camera The area from the rear end of the bumper Image from camera can be viewed. Areas at both ends of the The area above the camera cannot be bumper and areas just under the bumper viewed.
  • Page 261 Rear View Camera switch before shifting to the “R” When there is an upward slope CAUTION range. Then, the warning message will at the back be displayed. When moving backward, always check the back with your eyes without relying on the help lines. Otherwise, it may cause an acci- dent or injury.
  • Page 262: 7-19.Subaru Rear Vehicle Detection (Srvd)

    Subaru Rear Vehicle Detection (SRVD) (If Equipped) 7-19. Subaru Rear Vehicle When there is a downward slope Feature of distance marker at the back Detection (SRVD) (If Equipped) The Subaru Rear Vehicle Detection (SRVD) consists of rear corner radars with Blind Spot Detection, Lane Change Assist and Rear Cross Traffic Alert.
  • Page 263: System Features

    Subaru Rear Vehicle Detection (SRVD) (If Equipped) The system uses radar sensors for the approach indicator light is illuminating, the The system is designed to assist following features. system warns the driver of dangers by the driver in changing lanes or...
  • Page 264 Subaru Rear Vehicle Detection (SRVD) (If Equipped) system warns the driver of dangers by An icon appears on the center informa- WARNING flashing the SRVD approach indicator tion display. light. An approaching vehicle (A) may not Limitations of the detectability...
  • Page 265: System Operation

    Subaru Rear Vehicle Detection (SRVD) (If Equipped) In the following cases, the SRVD will However, if the SRVD OFF indicator System Operation temporarily stop operating (or may appears for a prolonged period of Operating conditions stop operating) and the SRVD OFF time, we recommend that you have the indicator will appear.
  • Page 266: Srvd Approach Indicator Light/Warning Buzzer

    Subaru Rear Vehicle Detection (SRVD) (If Equipped) trailer with no cargo and sports The SRVD approach indicator light While the indicator light is illuminating, cars) (when there are vehicles in the neigh- if the turn signal lever is operated toward...
  • Page 267 Subaru Rear Vehicle Detection (SRVD) (If Equipped) - When there is a difference in height SRVD approach warning buzzer between your lane and the neighboring (only when reversing) lane A warning buzzer sounds along with - Immediately after the SRVD is acti- flashing of the SRVD approach indicator vated by touching “SRVD”...
  • Page 268: Srvd Off Indicator

    Subaru Rear Vehicle Detection (SRVD) (If Equipped) - When the vehicle driving two lanes have the system inspected at a SUBARU SRVD Warning Indicator away drives on the near side of its lane dealer. System malfunction from your vehicle System temporary stops due to...
  • Page 269: To Turn On/Off The Srvd

    Subaru Rear Vehicle Detection (SRVD) (If Equipped) When using a chassis dynamom- To Turn On/Off the SRVD eter or free roller device, etc. When running the engine and making the wheels rotate while lifting up the vehicle If the ignition switch is turned to the “OFF”...
  • Page 270: 7-20.Reverse Automatic Braking (Rab) System

    If a wall or an we recommend that you contact Make sure to set the Automatic obstacle is detected in the reversing direc- your SUBARU dealer for inspec- Braking function to OFF when the tion, the system will notify the driver with a tion.
  • Page 271: Reverse Automatic Braking (Rab) System Overview

    Automatic Braking function SUBARU and third parties contracted by SUBARU may acquire and use the The Automatic Braking function detects recorded data for the purpose of vehi- objects rearward and if there is a high risk research development.
  • Page 272: Operating Conditions

    Reverse Automatic Braking (RAB) System (If Equipped) WARNING If your vehicle is trapped on a rail- road crossing and you are trying to escape by reversing through the crossing gate, the system may rec- ognize the crossing gate as an obstacle and brake may activate.
  • Page 273 On a steep hill, the system’s auto- not operate. Promptly we recommend matic braking ability will be reduced. that you contact a SUBARU dealer to The system is designed to avoid have the system inspected. collisions by automatic hard braking The EyeSight warning indicator when the vehicle’s reversing speed is...
  • Page 274 Reverse Automatic Braking (RAB) System (If Equipped) emitted from the sonar sensor such Engine sound from other vehi- Vehicle conditions: as a chain link fence. cles. Ice, snow or mud is adhered to Objects the system is not designed Sound of an air brake. the sonar sensors or the rear to detect and apply brake.
  • Page 275: Sonar Audible Alarm Function

    Reverse Automatic Braking (RAB) System (If Equipped) There is an obstacle that is next to an object. Going back along a wall. The area where the road starts touching dirt and snow When reversing on an uneven road. circumstances such following, it may not be possible to avoid a collision even when the system operates normally.
  • Page 276 Reverse Automatic Braking (RAB) System (If Equipped) NOTE Guideline of detecting range It may take time to display the wall and Alert level Distance indicator Alarm pattern sound warning beeps after the object Range of detected object was recognized by the Sonar Audible Long proximity 90 cm (35 in) or more Green...
  • Page 277: Automatic Braking Function Operation

    Reverse Automatic Braking (RAB) System (If Equipped) When an object is detected in the Obstacle detected and alert level reversing direction, the range of detected object will be shown on the center infor- mation display. warning alarm will sound and, depending on the speed, either torque control to generate engine braking or automatic braking will be applied.
  • Page 278 Reverse Automatic Braking (RAB) System (If Equipped) either strong automatic braking or torque NOTE After the brake pedal is depressed, the control will be applied to prevent collision. RAB OFF indicator will illuminate and the The Sonar Audible Alarm function and system will temporarily stop operating.
  • Page 279: Canceling The Reverse Automatic Braking (Rab) System Operation

    Reverse Automatic Braking (RAB) System (If Equipped) When the TRC mode and Vehicle Touch the ON setting key to turn the Reverse Automatic Braking Stability Control (VSC) mode are setting OFF. (RAB) System ON/OFF turned off When the OFF setting is shown, the corre- Setting When in TRACK mode and the sponding setting is OFF.
  • Page 280: Rab Warning Indicator

    Reverse Automatic Braking (RAB) System (If Equipped) Warning volume a SUBARU dealer to have the system inspected. Sonar Audible Alarm Do not disassemble the sonar sensors. Automatic Braking For details, refer to "Car settings" P159. NOTE If the sonar sensors require repair or...
  • Page 282: Driving Tips

    Driving Tips 8-1. New Vehicle Break-In Driving – the First 8-7. Driving in Foreign Countries......280 1,600 km (1,000 miles) ........276 8-8. Driving Tips ............280 8-2. Fuel Economy Hints ...........276 8-9. Winter Driving............281 8-3. Engine Exhaust Gas (Carbon Monoxide) ..276 Operation during Cold Weather ......... 281 Driving on Snowy and Icy Roads .......
  • Page 283: New Vehicle Break-In Driving – The First 1,600 Km (1,000 Miles)

    New Vehicle Break-In Driving – the First 1,600 km (1,000 miles) 8-1. New Vehicle Break-In 8-2. Fuel Economy Hints 8-3. Engine Exhaust Gas Driving – the First 1,600 km (Carbon Monoxide) The following suggestions will help to (1,000 miles) save your fuel. WARNING Select the proper gear position for the The performance and long life of your...
  • Page 284: 8-4. Catalytic Converter

    SUBARU dealer. crackling sound coming from the Do not apply undercoating or rust exhaust system for a short time after prevention treatment to the heat shield of the engine has been shut off.
  • Page 285: Gasoline Particulate Filter (If Equipped)

    Gasoline Particulate Filter (If Equipped) 8-5. Gasoline Particulate The indicator light will turn off after approximately 30 minutes. Filter (If Equipped) If the indicator light does not turn off, we recommend that you contact a SUBARU dealer. WARNING When gasoline particulate...
  • Page 286: When Gasoline Particulate Filter Warning Light Flashes

    Cruise control cannot be used when warning light flashes, we recommend that nate less frequently by driving in the the gasoline particulate filter warning you consult the nearest SUBARU dealer suburbs and by releasing acceleration light is flashing. for an immediate inspection.
  • Page 287: 8-6. Periodic Inspections

    Periodic Inspections 8-6. Periodic Inspections 8-7. Driving in Foreign Coun- 8-8. Driving Tips tries To keep your vehicle in the best condition WARNING at all times, always have the recom- When planning to use your vehicle in mended maintenance services listed in Always maintain a safe driving another country: the maintenance schedule performed at...
  • Page 288: 8-9. Winter Driving

    Use a windshield washer fluid that unavoidable. Such actions are tact a SUBARU dealer for an contains an antifreeze solution. Do not dangerous as you may lose inspection as soon as possible. use engine antifreeze or other substitutes...
  • Page 289 Winter Driving If you fill the windshield washer tank with Clear away ice and snow that has accu- When the vehicle has been left a fluid with a different concentration from mulated under the fenders to avoid parked after use on roads the one used previously, purge the old making steering difficult.
  • Page 290: Driving On Snowy And Icy Roads

    Snow stuck on the wiper arm prevents the If your SUBARU is not going to be used for To supplement the foot brake, use the wiper from working effectively. If snow is...
  • Page 291: Corrosion Protection

    We recom- sure label is located on the ment of snow tires affects the mend that you consult your SUBARU driver’s center pillar. operation of the tire pressure dealer for information about the chains warning valves and transmitters.
  • Page 292: Rocking The Vehicle

    Loading Your Vehicle 8-10. Loading Your Vehicle Regulations regarding the use of tire you are driving with tire chains could chains vary according to location and type easily lead to a serious accident. of road. Always check local regulations WARNING Rocking the Vehicle before installing chains.
  • Page 293: Vehicle Capacity Weight

    Loading Your Vehicle Vehicle Capacity Weight Stow cargo and luggage in the Do not place cargo or luggage in trunk whenever possible. or on the following locations as the item may get under the clutch, To prevent cargo and luggage brake, or accelerator pedal and from sliding...
  • Page 294: 8-11.Trailer Towing

    Therefore, never tow a trailer with your vehicle. SUBARU assumes no responsibility for injuries or vehicle damage that may result from trailer towing, from any trailer towing equipment or from any errors or omissions in the instructions accompanying such equipment.
  • Page 296: In Case Of Emergency

    In Case of Emergency 9-1. If You Park Your Vehicle in an Emergency..290 If No Steam Is Coming from the Engine Compartment ............. 308 9-2. Maintenance Tools..........290 9-6. Towing..............309 Models with Flat Tire Repair Kit ........291 Towing Hook and Tie-Down Hooks/Holes....309 Models with spare tire..........291 Using a Flat-Bed Truck..........
  • Page 297: If You Park Your Vehicle In An Emergency

    If You Park Your Vehicle in an Emergency 9-1. If You Park Your Vehicle 9-2. Maintenance Tools NOTE in an Emergency When the hazard warning flasher is on, Your vehicle is equipped with the following the turn signals do not work. maintenance tools.
  • Page 298: Models With Flat Tire Repair Kit

    Maintenance Tools Models with Flat Tire Repair Models with spare tire 901280 Example of jack label 901216 1) Jack label 1) Spare tire A) CAUTION 2) Jack handle B) WORKING LOAD LIMIT 3) Wheel nut wrench NOTE 4) Jack 5) Towing hook (eye bolt) For how to use the jack, refer to "Flat 6) Screwdriver Tires"...
  • Page 299: 9-3. Flat Tires

    CAUTION recommend that contact jacking point or sink into the SUBARU dealer when jacking up the ground and this can result in Do not hit and bend the disc rotor vehicle using a garage jack. serious injury or death. backing plate when removing and installing the tire.
  • Page 300 Flat Tires or the select lever to the “P” (Park) posi- tion (AT models). 3. Turn on the hazard warning flasher and unload all occupants and luggage from the vehicle. 900635 901295 6. Models with spare tire: Take out the 8.
  • Page 301 "Tires" P377. Never use your foot on ately contact your SUBARU dealer. the wheel nut wrench or a pipe extension on the wrench because you may exceed 12. Put on the spare tire. Replace the the specified torque.
  • Page 302: Sealing A Flat Tire (Models With The Flat Tire Repair Kit)

    Sealing a Flat Tire (Models the sealed tire changed by your nearest 901296 with the Flat Tire Repair Kit) SUBARU dealer. You may reuse the 1) Support holder wheel if the attached sealant is wiped off, WARNING but the valve of the wheel must be 15.
  • Page 303 2) Sealing is not possible flasher while sealing the flat tire. recommend that you contact your Do not attempt to remove foreign SUBARU dealer. WARNING objects like nails or screws that Drive with caution and avoid have penetrated the tire. Leave...
  • Page 304 We recommend that of a power supply or a battery you consult your SUBARU dealer other than DC 12 V. or tire dealer for advice. If a temporary puncture repair is...
  • Page 305 Flat Tires Contents of the flat tire repair kit 900881 900858 Air compressor (front side) Sealant bottle 900880 1) Air gauge 1) Hose 1) Sealant bottle 2) Power plug 2) Valve 2) Quick reference guide 3) Air compressor WARNING 4) Speed limit label Do not drink the sealant.
  • Page 306 Flat Tires or 5 km (3 miles) so that the sealant can If a person who is allergic to seal the damaged area. natural rubber comes in contact Stop the vehicle again, check and, if the sealant, allergy symptoms necessary, adjust the pressure of the may occur.
  • Page 307 Flat Tires outlet. Apply the parking brake and turn on the ignition switch to the “ACC” position. 900885 900886 Connect the hose from the bottle to the tire 3. Turn the bottle upside down and tilt the valve stem tightly. bottle cap into the bottle holder of the air 900888 compressor.
  • Page 308 100kPa If tire pressure doesn’t reach the green zone for 10 minutes, this kit will be unable to seal the tire. Please contact your SUBARU dealer for help. 900889 NOTE 5. While filling the tire with air, attach the 6.
  • Page 309 We recommend that you consult Connect the hose of the bottle to the valve 7. Stow the kit back in the vehicle and with your SUBARU dealer or road of the bottle in a circular fashion to avoid drive your vehicle immediately for 10 service provider.
  • Page 310: Tire Pressure Monitoring System (Tpms) (If Equipped)

    (for example, a blow-out caused by running Before the tire is removed from the rim, over a sharp object). inform your SUBARU dealer or other tire dealer that the tire contains sealant. – CONTINUED –...
  • Page 311: Tpms Screen (If Equipped)

    If a liquid sealant is nates while driving after adjusting used, we recommend that you con- the tire pressure, a tire may have tact your nearest SUBARU dealer or significant damage and a fast leak other qualified service shop as 702813 that causes the tire to lose air rap- soon as possible.
  • Page 312: 9-4. Jump Starting

    Jump Starting 9-4. Jump Starting Battery fluid contains sulfuric Keep children away: Battery Precautions acid: Batteries must be handled only by Since battery fluid contains sulfuric persons who are aware of the WARNING acid, be sure to wear eye protection potential hazards.
  • Page 313: Precautions When Jump Starting

    Jump Starting Precautions when jump To prevent electrical sparks, all CAUTION starting rings, wristwatches, other The battery used for boosting must metal accessories must be taken off be 12 V. Do not jump start unless before work is carried out on or WARNING you are sure that the booster bat- near the battery.
  • Page 314 Jump Starting A) Booster battery B) Strut mounting nut 1) Connect one jumper cable to the posi- tive (+) terminal on the discharged battery. 2) Connect the other end of the jumper cable to the positive (+) terminal of the booster battery.
  • Page 315: 9-5. Engine Overheating

    "Engine Coolant" P342. We recommend that you contact an 5. If there is no coolant in the reserve authorized SUBARU dealer. tank, add coolant to the reserve tank. Then remove the radiator cap and fill the radiator with coolant.
  • Page 316: 9-6. Towing

    1) Upper cover 901277 2) Lower cover If towing is necessary, SUBARU recom- mends it be done by your SUBARU dealer 2. Insert a screwdriver, with its tip or a commercial towing service. covered with tape or a cloth to prevent...
  • Page 317 Towing cover. Then, pull the lower cover to sepa- After towing, remove the towing hook from rate it. the vehicle and stow it in the under-floor storage compartment. Fit the towing hook cover on the bumper. WARNING Do not use the towing hook except when towing your vehicle.
  • Page 318 Towing Rear towing hook: 2. Pry off the cover on the rear bumper using a screwdriver, and you will find a 1. Take out the screwdriver, towing hook, threaded hole for attaching the towing wheel nut wrench from the under-floor hook.
  • Page 319 Towing After towing, remove the towing hook from Front tie-down hooks: Rear tie-down holes: the vehicle and stow it in the under-floor storage compartment. Fit the towing hook cover on the bumper. WARNING Do not use the towing hook except when towing your vehicle. Be sure to remove the towing hook after towing.
  • Page 320: Using A Flat-Bed Truck

    Using a Flat-Bed Truck effort to operate the brake pedal light alignment checked and steering wheel. SUBARU dealer after transporting the vehicle by flat-bed truck. CAUTION Towing with All Wheels on If transmission failure occurs, the Ground transport your vehicle on a flat- bed truck.
  • Page 321: Access Key Fob – If Access Key Fob Does Not Operate Properly

    Access Key Fob – If Access Key Fob Does Not Operate Properly 9-7. Access Key Fob – If Locking and Unlocking Use a flat-bed truck if there are Access Key Fob Does Not long distance downgrades or steep slopes. However, do not Operate Properly apply the brake pedal for a long time because the engine braking...
  • Page 322: Switching Power Status

    If the engine does not start even button ignition switch changes to either of though the above procedure was fol- the following. lowed precisely, we recommend that you contact your SUBARU dealer.
  • Page 323: Malfunctions Of The Center Information Display

    Malfunctions of the Center Information Display 9-8. Malfunctions of the Center Information Display If the following screens are displayed, temporary errors or malfunctions may occur in the center information display. If they are only temporary errors, the following procedure may help to eliminate them.
  • Page 324: If Your Vehicle Is Involved In An Accident

    When the vehicle sustains an recovered by restarting it, we recommend impact in an accident, etc., the fuel pump that you contact your SUBARU dealer. shut off system stops supplying the fuel in order to minimize fuel leakage. However, depending on the impact condi- tions at the time of collision, the fuel pump shut-off system may not operate.
  • Page 326: Appearance Care

    Appearance Care 10-1.Exterior Care ............320 To Help Prevent Corrosion ......... 322 10-3.Cleaning the Interior ..........323 Washing.................320 Waxing and Polishing ..........321 Seat Fabric Material............. 323 Cleaning Alloy Wheels ..........321 Leather Seat Materials..........323 Alloy Wheels (Vehicles with Matte Painted Synthetic Leather Upholstery........324 Wheels) ...............322 Instrument Panel, Console Panel, Switches, 10-2.Corrosion Protection .........322...
  • Page 327: 10-1.Exterior Care

    Exterior Care 10-1. Exterior Care with plenty of lukewarm water. Wipe the Do not use any organic solvents remaining water off with a chamois or soft when washing the surface of the Washing cloth. Wear rubber gloves and use a hand bulb assembly cover.
  • Page 328: Waxing And Polishing

    We recom- with water. Do not clean the wheels with a mend that you always contact your Waxing and Polishing stiff brush or expose them to a high-speed SUBARU dealer auto paint washing device. Always wash and dry the vehicle before specialist.
  • Page 329: Alloy Wheels (Vehicles With Matte Painted Wheels)

    We especially when temperatures range just recommend that contact your above freezing. SUBARU dealer to perform this kind of maintenance and treatment if you need Dampness in certain parts of the assistance. vehicle remains for a long time, even...
  • Page 330: 10-3.Cleaning The Interior

    Occasionally check under the mats to Leather Seat Materials organic solvents.) make sure the area is dry. The leather used by SUBARU is a high Keep your garage dry. Do not park your quality natural product which will retain its Seat Fabric Material...
  • Page 331: Synthetic Leather Upholstery

    Cleaning the Interior If your SUBARU is to be parked for a long Instrument Panel, Console CAUTION time in bright sunlight, it is recommended Panel, Switches, Combina- that the seats and headrests be covered, Do not spray neutral detergent tion Meter, and Other Plastic or the windows shaded, to prevent fading directly onto the monitor.
  • Page 332: Maintenance And Service

    Maintenance and Service 11-1.Maintenance Schedule ........327 11-14.Brake Fluid ............347 11-2.Maintenance Precautions........332 Checking the Fluid Level ..........347 Recommended Brake Fluid ........347 Before Checking or Servicing in the Engine 11-15.Clutch Fluid (MT models) ........348 Compartment ..............333 When Checking or Servicing in the Engine Checking the Fluid Level ..........
  • Page 333 Maintenance and Service 11-27.Installation of Accessories......366 Other Bulbs ..............367 11-29.Replacing Battery..........368 11-28.Replacing Bulbs ..........366 Safety precautions ............368 Headlights..............366 Replacing Battery of Access Key Fob......369 Rear Fog Light (if equipped)/Backup Light ....366 The safe disposal of button batteries......370 Trunk Light ..............
  • Page 334: 11-1.Maintenance Schedule

    These conditions may differ from one country to another. Therefore there may be special requirements in your country. We recommend that you ask your authorized SUBARU dealer for the actual maintenance schedule applied to your vehicle. You can set a reminder to be displayed when a scheduled maintenance item is almost due. For details, refer to "General settings"...
  • Page 335 Drive belt Cooling system, hoses and con- nections 1st replacement: 132 months (11 years)/220,000 km (137,500 miles) Replace engine coolant (SUBARU From the 2nd replacement: 72 months (6 years)/120,000 km (75,000 SUPERCOOLANT or equivalent) miles) Fuel system, lines and connections...
  • Page 336 Maintenance Schedule MAINTENANCE INTERVAL (Number of months or km (miles), whichever occurs first) Months MAINTENANCE ITEM REMARKS × 1,000 km × 1,000 miles Replacement intervals 48 months / 30,000 km (18,500 miles) which- For Europe ever comes first. Inspection intervals 12 months / 15,000 km (9,000 miles) whichever For South Africa, comes first.
  • Page 337 Replace every 12 months or 12,000 km (7,500 miles) whichever eral occurs first SUBARU GENUINE FUEL ADDI- TIVE (In areas where the impurity Add a bottle to the fuel tank every 15,000 km (9,000 miles) content in the fuel is high)
  • Page 338 Maintenance Schedule NOTE 1) When the vehicle is used under severe driving conditions mentioned in the following examples*, the engine oil and oil filter should be changed more frequently. 2) When the vehicle is used under severe driving conditions mentioned in the following examples*, inspection should be performed at every 15,000 km (9,000 miles) or 12 months whichever occurs first.
  • Page 339: 11-2.Maintenance Precautions

    WARNING This will cause a fire. NOTE Always select a safe area when Because the fuel system is under SUBARU does not endorse the use of performing maintenance on your pressure, we recommend that non-SUBARU approved flushing sys- vehicle. you have your SUBARU dealer...
  • Page 340: Before Checking Or Servicing In The Engine Compartment

    Maintenance Precautions Before Checking or When Checking or Servicing When the ignition switch is in the Servicing in the Engine “ON” position, the cooling fan in the Engine Compartment may operate suddenly even when Compartment the engine is stopped. If your body clothes come...
  • Page 341: When Checking Or Servicing In The Engine Compartment While The Engine Is Running

    Maintenance Tips 11-3. Maintenance Tips When Checking or Servicing in the Engine Compartment Some clips and fender linings must be While the Engine Is Running removed before replacing the air cleaner element or specific bulbs. WARNING Removing and Reinstalling A running engine can be danger- Clips ous.
  • Page 342 Maintenance Tips Type B clips Type C clips Reinstalling clips B00924 B00798 B01024 Type A clips 1. Pull out the center portion of the clip 1. Turn the clip counterclockwise using a using a flat-head screwdriver as shown in Phillips screwdriver until the center portion the illustration.
  • Page 343: 11-4.Engine Hood

    2. Pull the hood release knob under the injuries from slamming. instrument panel. Do not install accessories other than genuine SUBARU parts to the engine hood. If the engine hood becomes too heavy, the stay may not be able to support holding it open.
  • Page 344 Engine Hood WARNING Always check that the hood is prop- erly locked before you start driving. If it is not, it might fly open while the vehicle is moving and block your view, which may cause an accident and serious bodily injury. B02095 4.
  • Page 345: 11-5.Engine Compartment Overview

    Engine Compartment Overview 11-5. Engine Compartment Overview 1) Battery (page "Battery" P363) 2) Clutch fluid reservoir (MT models) (page"Clutch Fluid models)" P348) 3) Brake fluid reservoir (page "Brake Fluid" P347) 4) Windshield washer tank (page "Wind- shield Washer Fluid" P359) 5) Engine oil filler cap (page "Engine Oil"...
  • Page 346: 11-6.Engine Oil

    1,413 miles), we recommend that you type, driving style, terrain and tempera- contact your SUBARU dealer who may ture. Under the following conditions, oil perform a test under controlled conditions. consumption can be increased and thus...
  • Page 347: Changing The Oil And Oil Filter

    We recommend that you con- smell, smoke, and/or a fire. If tact your SUBARU dealer for changing engine oil gets on the exhaust the engine oil and oil filter. Fully pipe, be sure to wipe it off.
  • Page 348: Recommended Grade And Viscosity

    36°C ( 33°F). You should use synthetic engine oil that Make sure to always use genuine meets the same requirements given for SUBARU SUPER COOLANT or an conventional engine oil. When using equivalent (non-amine type synthetic oil, you must use oil of the same coolant).
  • Page 349: Cooling Fan, Hose And Connections

    SUBARU 2. If the level is close to or lower than the a specific temperature.
  • Page 350: 11-8.Air Cleaner Element

    We recommend that you have the coolant genuine SUBARU air cleaner ele- changed by your SUBARU dealer if ment. If it is not used, there is the necessary. possibility of causing a negative The coolant should be changed according effect to the engine.
  • Page 351: Replacing The Air Cleaner Element

    If the inside of the air cleaner case is extremely soiled (for example, by sand), we recommend that you con- tact a SUBARU dealer and have the B02102 air cleaner case cleaned. 1) Clip 1. Unsnap the two clips holding the air 3.
  • Page 352: 11-9.Spark Plugs

    “Mainte- according to the maintenance schedule. nance schedule”. We recommend that Refer to "Maintenance Schedule" P327. you consult your SUBARU dealer for replacement. Recommended Spark Plugs If the belt is loose, cracked or worn, we Refer to "Electrical System"...
  • Page 353: 11-11.Automatic Transmission Fluid

    Schedule" P327. We recom- nance Schedule" P327. We recom- Each oil manufacturer has its own base mend that you consult your SUBARU mend that you consult your SUBARU oils and additives. Never use different dealer for details. dealer for details.
  • Page 354: 11-14.Brake Fluid

    If the vehicle requires frequent refilling, there may be a leak. If suspect a problem, we recommend that you have the vehicle checked at your SUBARU dealer. CAUTION B02107 When adding brake fluid, be 1) “MAX” level line careful not to allow any dirt into 2) “MIN”...
  • Page 355: 11-15.Clutch Fluid (Mt Models)

    Clutch Fluid (MT models) 11-15. Clutch Fluid (MT 11-16. Brake Booster the reservoir. It cannot be checked at the outboard side of the reservoir. models) The brake booster utilizes the vacuum Recommended Clutch Fluid produced by the vacuum pump to reduce Checking the Fluid Level the force required to depress the brake Refer to "Fluids"...
  • Page 356: 11-17.Brake Pedal

    It is recommended that you disconnect the vehicle battery before replacing the brake pad. However, it is dangerous to disconnect the vehicle battery. We recommend that you have your SUBARU dealer replace the brake pad and lining. 700040 – CONTINUED –...
  • Page 357: Breaking-In Of New Brake Pads And Linings

    SUBARU dealer as soon adjusting nut located on the parking brake as possible. lever.
  • Page 358: 11-21.Tires And Wheels

    Tires and Wheels 11-21. Tires and Wheels All season tires are identified by “ALL Be sure to use proper tire inflation SEASON” and/or “M+S” (Mud & Snow) on pressure. If tires are under-inflated, the tire sidewall. they may be damaged more severely. Types of Tires Avoid pot holes, uneven pavement, You should be familiar with type of tires...
  • Page 359 In this event, system. As with wheel replacement, spond to various outside temperatures we recommend that you go to a SUBARU therefore, we recommend that you have when the temperature in the garage is dealer to have the system inspected as the work performed by a SUBARU dealer.
  • Page 360: Tire Inspection

    Tires and Wheels We recommend that you contact your A tire goes flat repeatedly or If this light still illuminates while SUBARU dealer immediately if you find cannot be properly repaired due to driving after adjusting the tire pres- any problem.
  • Page 361 Tires and Wheels the tire inflation pressure label. The tire Correctly inflated tires (tread worn inflation pressure label is located on the evenly) center pillar on the driver’s side. Driving even a short distance warms up the tires and increases the tire pressures. Also, the tire pressures are affected by the outside temperature.
  • Page 362: Wheel Balance

    Rolling resistance is high, so fuel Ride comfort is poor. Also, the tire magni- and adjusted by your SUBARU dealer. consumption is also higher. fies the effects of road surface bumps and Also have them adjusted after tire repairs dips, possibly resulting in vehicle damage.
  • Page 363: Wear Indicators

    Tires and Wheels Example of rotational direction marked Wear Indicators WARNING on the sidewall 1) Front When a tire’s tread wear indicator If the tires have specific rotational direc- becomes visible, the tire is worn tion, refer to the arrow marked on the side beyond the acceptable limit and wall.
  • Page 364: Tire Replacement

    You are advised to replace the tires with new ones that are identical to those fitted as standard equip- ment. B02033 For safe vehicle operation, SUBARU Models without tire pressure monitoring recommends replacing all four tires at the system same time.
  • Page 365: Wheel Replacement

    (a) Size ment. Replacement wheels are available It also may be dangerous and from SUBARU dealers. lead to loss of vehicle control, (b) Speed symbol and it can lead to an accident. WARNING (c) Load index Use only radial tires.
  • Page 366: 11-22.Alloy Wheels

    SUBARU parts designed for alloy wheels. outside temperature. If the level falls below the second hole concentration is inappropriate, from the bottom (the “LOW”...
  • Page 367: 11-24.Replacement Of Wiper Blades

    Replacement of Wiper Blades 11-24. Replacement of Wiper Be careful foreign matter does When you wish to raise the Blades not contaminate the washer fluid passenger-side wiper arm, first when filling the tank. Contamina- raise the driver-side wiper arm. tion could cause malfunctions, Grease, wax, insects, or other material on Otherwise, the passenger-side the windshield or the wiper blade results in...
  • Page 368: Windshield Wiper Blade Assembly

    Replacement of Wiper Blades If you cannot eliminate the streaking even CAUTION after following this method, replace the wiper blades using the following proce- Hold the wiper arm when replacing dures. the wiper blade. Holding the wiper blade, may result in blade deforma- Windshield Wiper Blade tion.
  • Page 369: Windshield Wiper Blade Rubber

    Replacement of Wiper Blades After installing the wiper blade assembly, 3. Align the claws of the support with the close the lock cover and check that the grooves in the rubber and slide the blade connection part is locked completely. rubber assembly into the support until it locks.
  • Page 370: 11-25.Battery

    Battery 11-25. Battery Battery fluid contains sulfuric Keep children away: Battery Precautions acid: Batteries must be handled only by Since battery fluid contains sulfuric persons who are aware of the WARNING acid, be sure to wear eye protection potential hazards. Take particular and protective gloves when inspect- care to keep children away from Read these instructions care-...
  • Page 371: 11-26.Fuses

    Fuses 11-26. Fuses It is unnecessary to periodically check the To prevent electrical sparks, all battery fluid level or periodically refill with rings, wristwatches, other distilled water. metal accessories must be taken off CAUTION However, if the battery fluid level is below before work is carried out on or the lower level, remove the cap.
  • Page 372 1. Turn the ignition switch to the “OFF” SUBARU dealer for repairs. position and turn off all electrical accesso- ries. 2. Remove the fuse box cover. 3. Determine which fuse may be blown. Look at the back side of each fuse box...
  • Page 373: 11-27.Installation Of Accessories

    As the We recommend that you have your bulbs are near the exhaust pipes, vehicle inspected at a SUBARU dealer as there is a risk of being burned. soon as possible. Replace any bulb only with a new Rear Fog Light (if equipped)/ bulb of the specified wattage.
  • Page 374: Trunk Light

    Replacing Bulbs Other Bulbs It may be difficult to replace the bulbs. We recommend that you have the bulbs replaced by your SUBARU dealer if necessary. B02120 B02122 3. Turn the bulb socket counterclockwise 1. Remove the clips. and remove it.
  • Page 375: 11-29.Replacing Battery

    It is recommended that the battery Do not ingest the battery/Chemical ance. should be replaced by a SUBARU Burn Hazard dealer. (The remote control supplied with) Do not let dust, oil or water get on Use a new battery.
  • Page 376: Replacing Battery Of Access Key Fob

    Replacing Battery Replacing Battery of Access Key Fob CAUTION The battery is hazardous and is to be kept away from children (whether the battery is new or used). The battery can cause severe or fatal injuries in 2 hours or less if it 202500 B01546 is swallowed or placed inside any...
  • Page 377: The Safe Disposal Of Button Batteries

    Replacing Battery B01542 5. Attach the cover to the access key fob by fitting the projections and recesses together. The safe disposal of button batteries Please, safely dispose of button batteries immediately. As soon as you have finished using a button battery put sticky tape around both sides of the battery.
  • Page 378: Specifications

    Specifications 12-1.Specifications.............372 Brake Disc ..............377 12-2.Bulb Chart............378 Dimensions ..............372 Engine................373 Safety Precautions ............378 Fuel ................373 Bulb Chart ..............379 12-3.Vehicle Identification .........381 Engine Oil..............373 Manual Transmission and Differential Gear Oil..375 12-4.Function Settings..........382 Fluids ................375 Function Settings and Adjustments on the Engine Coolant .............376 Center Information Display........
  • Page 379: 12-1.Specifications

    Specifications 12-1. Specifications These specifications are subject to change without notice. Dimensions mm (in) Item Dimensions Drive system Transmission type Overall length 4,265 (167.9) Overall width 1,775 (69.9) Overall height 1,310 (51.6) Wheelbase 2,575 (101.4) Front 1,520 (59.8) Tread Rear 1,550 (61.0) 130 (5.1) Ground clearance*...
  • Page 380: Engine

    SUBARU dealer. Approved engine oil Always use the SUBARU approved engine oil. For further details, we recommend that you contact your SUBARU dealer. If the approved engine oil is unavailable, use the alternative engine oil described on the next page.
  • Page 381 Specifications Alternative engine oil If the SUBARU approved oil is unavailable, the following alternative oil can be used. NOTE Each quantity indicated is only a guideline. The necessary quantity for replacement may differ slightly depending on the temperature and other factors.
  • Page 382: Manual Transmission And Differential Gear Oil

    Specifications Manual Transmission and Differential Gear Oil Manual transmission oil Differential gear oil Manual Transmission Gear Oil LV 75W* Differential Gear Oil LX* Oil grade Other gear oil that meets API GL-5 SAE 75W-85 or GL-5 SAE 75W- API GL-4 SAE 75W 90 specifications* 2.2 liter (2.3 US qt, 1.9 Imp qt) 1.15 liter (1.22 US qt, 1.01 Imp qt)
  • Page 383: Engine Coolant

    Coolant type AT models 7.7 liter (8.1 US qt, 6.8 Imp qt) SUBARU SUPER COOLANT MT models 7.4 liter (7.8 US qt, 6.5 Imp qt) The indicated coolant quantity is only a guideline. The necessary quantity for replacement may differ slightly depending on the temper- ature and other factors.
  • Page 384: Electrical System

    For the wheel nut tightening procedure, refer to "Changing a Flat Tire" P292. Brake Disc If you need information on the usage limit value of brake discs and the method for measuring them, we recommend that you consult your SUBARU dealer.
  • Page 385: 12-2.Bulb Chart

    Bulb Chart 12-2. Bulb Chart Safety Precautions WARNING Bulbs may become very hot while illuminated. Before replacing bulbs, turn off the lights and wait until the bulbs cool down. Otherwise, there is a risk of sustaining a burn injury. CAUTION Replace any bulb only with a new bulb of the specified wattage.
  • Page 386: Bulb Chart

    Bulb Chart Bulb Chart C00474 NOTE Lights indicated by letters are the LED (Light Emitting Diode) type. We recommend that you consult your SUBARU dealer for replacement. – CONTINUED –...
  • Page 387 Bulb Chart Wattage Bulb No. Map lights 12 V-8 W Rear fog light (if equipped) 12 V-21 W W21W Trunk light 12 V-3.8 W SAE #194 Backup lights 12 V-16 W W16W Door step lights 12 V-5 W Vanity mirror lights 12 V-2 W Front turn signal lights Low and high beam headlights...
  • Page 388: 12-3.Vehicle Identification

    Vehicle Identification 12-3. Vehicle Identification 1) Vehicle identification number under the floor carpet of the right-hand front seat 2) Tire inflation pressure label (vehicle placard) (driver's side) 3) Year of manufacture label (Middle East models) 4) Model number label (if equipped) 3,4,5 5) Built date label (if equipped) 6) Fuel label...
  • Page 389: 12-4.Function Settings

    Function Settings 12-4. Function Settings Function Settings and Adjustments on the Center Information Display Setting adjustments can be manually changed within the center information display to meet your personal requirements. Refer to "Center Information Display (CID)" P153. Function Settings and Adjustments Performed by a Dealer Factory default Item Function...
  • Page 390 Function Settings Factory default Item Function Available settings setting Operation when the doors are unlocked Operation/Non-operation Operation Operation after the engine switch is turned off Operation/Non-operation Operation Illumination Interior light illumination upon approach Operation/Non-operation Operation Interior light illumination Operation/Non-operation Operation Active sound control Active sound control Operation/Non-operation...
  • Page 392: Supplement

    Access Key Fob ............395 Immobilizer..............398 13-2.Built date information (If Equipped)....386 TPMS Transmitter ............400 Definition ...............386 Subaru Rear Vehicle Detection (SRVD) ..... 403 Location.................386 TPMS Receiver............. 407 13-3.Information for Middle East models....386 LF Oscillator..............410 Year of Manufacture and Country of Origin....386 13-7.Technical information........413...
  • Page 393: 13-1.Id Label (If Equipped)

    ID Label (If Equipped) 13-1. ID Label (If Equipped) 13-2. Built date information 13-3. Information for Middle (If Equipped) East models Definition Year of Manufacture and Country of Origin The “BUILT DATE” is the calendar month and the year in which the body shell and powertrain sub-assemblies are conjoined and the vehicle is driven or moved from the production line.
  • Page 394: Speed Limit, Maximum Torque And Maximum Power At Rpm

    Information for Middle East models Speed limit, maximum torque and maximum power at rpm Fuel economy tips Observe the following in order to improve 2.4 L models your vehicle’s fuel economy and reduce Model emissions. Drive the vehicle appropriately. Speed limit km/h Have your vehicle maintained periodi- Maximum torque 250 (25.5) /3,700...
  • Page 395: 13-4.Declaration Of Conformity In Accordance With Emc Directive 2014/30/Ec

    Declaration of Conformity in Accordance with EMC Directive 2014/30/EC 13-4. Declaration of Conformity in Accordance with EMC Directive 2014/30/EC Compressor D00509...
  • Page 396: 13-5.Declaration Of Conformity In Accordance With The Machinery Directive 2006/42/Ec

    Declaration of conformity in accordance with the Machinery Directive 2006/42/EC 13-5. Declaration of conformity in accordance with the Machinery Directive 2006/42/EC Jack D01096...
  • Page 397: With The Radio Equipment Directive

    Declaration of Conformity in Accordance with the Radio Equipment Directive (2014/53/EU) 13-6. Declaration of Conformity in Accordance with the Radio Equipment Directive (2014/53/EU) Replacing a Coin/Button Cell Battery Precautions (Access Key) D00843 D00842...
  • Page 398 Declaration of Conformity in Accordance with the Radio Equipment Directive (2014/53/EU) D00844 D00845 D00846 – CONTINUED –...
  • Page 399 Declaration of Conformity in Accordance with the Radio Equipment Directive (2014/53/EU) D00847 D00848 D00849...
  • Page 400 Declaration of Conformity in Accordance with the Radio Equipment Directive (2014/53/EU) D00850 D00851 D00852 – CONTINUED –...
  • Page 401 Declaration of Conformity in Accordance with the Radio Equipment Directive (2014/53/EU) D00853 D00854 D00855...
  • Page 402: Access Key Fob

    Declaration of Conformity in Accordance with the Radio Equipment Directive (2014/53/EU) Access Key Fob Transmitter: Model: 14AHK Operation frequency: 433.92 MHz Maximum output power (ERP): 0.03 mW Manufacturer: DENSO CORPORATION Address: 1-1, Showa-cho, Kariya-shi, Aichi-ken, 448-8661, Japan D00894 D00856 D00908 –...
  • Page 403 Declaration of Conformity in Accordance with the Radio Equipment Directive (2014/53/EU) D00920 D00921 D00922...
  • Page 404 Declaration of Conformity in Accordance with the Radio Equipment Directive (2014/53/EU) D00923 D00924 D01178 – CONTINUED –...
  • Page 405: Immobilizer

    Declaration of Conformity in Accordance with the Radio Equipment Directive (2014/53/EU) Immobilizer D00926 D01153 D01152...
  • Page 406 Declaration of Conformity in Accordance with the Radio Equipment Directive (2014/53/EU) D01154 D01155 D01156 – CONTINUED –...
  • Page 407: Tpms Transmitter

    Declaration of Conformity in Accordance with the Radio Equipment Directive (2014/53/EU) TPMS Transmitter D01158 D01142 D01157...
  • Page 408 Declaration of Conformity in Accordance with the Radio Equipment Directive (2014/53/EU) D01143 D01144 D01145 – CONTINUED –...
  • Page 409 Declaration of Conformity in Accordance with the Radio Equipment Directive (2014/53/EU) D01146 D01147...
  • Page 410: Subaru Rear Vehicle Detection (Srvd)

    Declaration of Conformity in Accordance with the Radio Equipment Directive (2014/53/EU) Subaru Rear Vehicle Detection (SRVD) D01162 – CONTINUED –...
  • Page 411 Declaration of Conformity in Accordance with the Radio Equipment Directive (2014/53/EU) D01163...
  • Page 412 Declaration of Conformity in Accordance with the Radio Equipment Directive (2014/53/EU) D01164 – CONTINUED –...
  • Page 413 Declaration of Conformity in Accordance with the Radio Equipment Directive (2014/53/EU) D01165...
  • Page 414: Tpms Receiver

    Declaration of Conformity in Accordance with the Radio Equipment Directive (2014/53/EU) TPMS Receiver D01132 D01166 – CONTINUED –...
  • Page 415 Declaration of Conformity in Accordance with the Radio Equipment Directive (2014/53/EU) D01133 D01134 D01135...
  • Page 416 Declaration of Conformity in Accordance with the Radio Equipment Directive (2014/53/EU) D01136 D01137 D01138 – CONTINUED –...
  • Page 417: Lf Oscillator

    Declaration of Conformity in Accordance with the Radio Equipment Directive (2014/53/EU) LF Oscillator Model: SU19S-3 Operation frequency: 134.2 kHz Maximum output power (ERP): 6.195 mW Manufacturer: SUBARU CORPORATION Address: 1-1, Subaru-cho, Ota-shi, Gunma-ken, 373-8555, Japan D01141...
  • Page 418 Declaration of Conformity in Accordance with the Radio Equipment Directive (2014/53/EU) D01074 D01075 D01076 – CONTINUED –...
  • Page 419 Declaration of Conformity in Accordance with the Radio Equipment Directive (2014/53/EU) D01077 D01078 D01079...
  • Page 420: 13-7.Technical Information

    Technical information 13-7. Technical information Subaru Rear Vehicle Detection (SRVD) Singapore models Access key fob Complies with IMDA Standards DA103352 Complies with IMDA Standards DA103352 D01080 14AHK D00580 Indonesia models D00574 Subaru Rear Vehicle Detection Immobilizer (SRVD) D01097 D01102 – CONTINUED –...
  • Page 421: Vietnam Models

    Technical information Vietnam models Keyless access with push-button Philippine models start system Subaru Rear Vehicle Detection Subaru Rear Vehicle Detection (SRVD) (SRVD) No.:ESD-1409920C D00535 D01098 D00730 Immobilizer Access key fob D00534 D00535...
  • Page 422: Taiwan Models

    Technical information Taiwan models Immobilizer Tire pressure monitoring system Access key fob D01150 Keyless access with push-button start system 500631 500631 D01151 – CONTINUED –...
  • Page 423: Republic Of South Africa Models

    Technical information Active sound control Subaru Rear Vehicle Detection Subaru Rear Vehicle Detection (SRVD) (SRVD) 2014/2260 D01118 D00805 Republic of South Africa Bahrain models models Subaru Rear Vehicle Detection (SRVD) Access key fob The Equipment Identified hereon is approved for use under the following rules.
  • Page 424: Australia/New Zealand Models

    Technical information Australia/New Zealand Israel models models Subaru Rear Vehicle Detection (SRVD) Subaru Rear Vehicle Detection (SRVD) D01199 D00804 – CONTINUED –...
  • Page 425: Uae Models

    Technical information Tire pressure monitoring system Access key fob Immobilizer Transmitter D01202 D01232 D01201 Keyless access with push-button UAE models start system Tire pressure monitoring system Receiver D01203 D01100 D01200...
  • Page 426: Thailand Models

    Technical information Thailand Models Subaru Rear Vehicle Detection (SRVD) – CONTINUED –...
  • Page 427: Importer Information

    Technical information Importer Information...
  • Page 428 Technical information – CONTINUED –...
  • Page 429 Technical information...
  • Page 430 Technical information – CONTINUED –...
  • Page 431 Technical information...
  • Page 432: Index

    Index...
  • Page 433 Index Audio system-linked display ..........P150 Auto dimmer cancel function ..........P125 Abbreviation ................P4 Auto on/off headlights............P168 ABS (Anti-lock Brake System) ..........P232 Sensor ................P170 Warning light..............P133 Automatic Access key Transmission ..............P222 Warning indicator.............P137 Automatic climate control operation ........P188 Access key fob Automatic headlight beam leveler ........
  • Page 434 Index Disc ................. P377 Oil and oil filter ..............P340 Fluid ..............P347, P375 Charge warning light............P131 Pad.................. P349 Checking Parking..............P243, P350 Brake pedal free play ............P349 Pedal................P349 Brake pedal reserve distance.......... P349 System ................P231 Clutch function ..............P349 Brake pedal Clutch pedal free play .............
  • Page 435 Drive information ..............P146 Drive information .............P146 Driving Driving support system setting display ......P150 Car phone/cell phone............P8 Exclusive content for SUBARU BRZ .......P148 Drinking................P7 Navigation system-linked display ........P149 Drugs .................. P8 Settings display ...............P150 Foreign countries ............P280 Warning message display ..........P152...
  • Page 436 Start & stopping .............. P216 Average fuel consumption..........P146 Engine oil temperature gauge ..........P146 Current fuel consumption ..........P146 Exclusive content for SUBARU BRZ ........P148 Fuses ................... P364 Exterior care ................ P320 Gasoline................P211 Flat tire ................P292 Gasoline particulate filter .............
  • Page 437 High beam indicator light............P142 Select lever/Gear position..........P141 High/low beam change (dimmer) .........P170 Steering Responsive Headlight OFF ......P143 Hill start assist ..............P244 Subaru Rear Vehicle Detection OFF ......P143 Indicator light ..............P143 TRC OFF ................ P135 To activate/deactivate............P246 Turn signal ..............P142 Hook Vehicle Stability Control (VSC) OFF.......
  • Page 438 Index Opening trunk ..............P97 Manual Warning chimes and warning indicator ....P104, P137 Climate control ..............P189 When access key fob does not operate properly.... P314 mode (automatic transmission) ........P226 Seat................... P31 Transmission..............P220 Transmission oil ............P346, P375 Lane Change Assist (LCA) ..........P256 Map light ................
  • Page 439 Index Folding down ..............P35 Rear view camera ............... P251 Parking Rear window Brake ................P243 Brake stroke ..............P350 Defogger ................. P181 Tips..................P243 Recommended Periodic inspections .............P280 Brake fluid............... P375 Petrol fuel ................P211 Clutch fluid ..............P375 Differential gear oil ............P375 PIN code Access..............P98 Engine oil ................
  • Page 440 Safety tips ................. P37 Stopwatch ................P149 Warning light and chime ........P126, P127 Storage compartment ............P201 Security Subaru Rear Vehicle Detection (SRVD) ......P255 Immobilizer..............P105 OFF indicator ..............P261 Select lever OFF switch ..............P262 Position indicator............. P141 SRVD approach indicator light/warning buzzer....
  • Page 441 Index Sun visors ................P201 Towing................. P309 Supplemental Restraint System airbag (SRS) .......P64 All wheels on the ground ..........P313 Flat-bed truck ..............P313 Curtain airbag ..............P83 Hooks................P309 Side airbag ................P83 Tie-down hooks .............. P309 Synthetic leather upholstery..........P324 TPMS screen............... P241 TRACK mode ..............
  • Page 442 Vehicle Stability Control (VSC)/TRC SRS airbag system ............P128 System ................P234 Steering Responsive Headlight........P143 Ventilator ................P186 Subaru Rear Vehicle Detection (SRVD) ......P143 Voltmeter ................P146 Vacuum pressure system..........P134 Vehicle speed..............P144 Vehicle Stability Control (VSC) ........P135 Warning and indicator lights ..........
  • Page 443 Index Winter Driving ................P281 Tires..............P284, P351 Wiper and washer ..............P177...
  • Page 449 GAS STATION REFERENCE GAS STATION REFERENCE Fuel Fuel tank capacity 50 liters (13.2 US gal, 11.0 Imp gal) For Australia Fuel type: Unleaded petrol only Engine oil Research Octane Number (RON): 98 or higher is recom- Use only the following oils. mended.

Table of Contents

Save PDF
