  • Page 1 2014 Quick Reference Guide...

  • Page 2: Driver's Area

    DRIVER’S AREA Tilt/telescopic steering wheel Hold the steering wheel and push the lever down. Adjust to the ideal position by moving the steering wheel horizontally and vertically. After adjustment, pull the lever up to secure the steering wheel. Hazard warning flasher Press the switch.
  • Page 3 Push-button ignition switch (if equipped) Performing the following operations when carrying the access key on your person starts the engine or changes push-button ignition switch modes. Changing push-button ignition switch mode Modes can be changed by push-button ignition switch with the brake pedal (vehicles with an automatic transmission) or clutch pedal (vehicles with a manual transmission) released.
  • Page 4 Headlights/turn signal Headlights To turn on, rotate knob to: : The side marker, parking, tail, license plate, daytime running lights and instrument panel lights. : The headlights and all the lights listed above (except daytime running lights). AUTO: The headlights, parking, daytime running lights and so on turn on and off automatically.
  • Page 5 Instrument panel light control dial The brightness of the instrument panel lights can be adjusted. Brighter Darker Manual headlight leveling dial The level of the headlights can be adjusted according to the number of passengers and the loading condition of the vehicle.
  • Page 6 Automatic transmission (if equipped) P = Parking R = Reversing N = Neutral D = Drive For normal driving/temporary manual mode driving. M = Manual mode While the engine switch is in the ON position, or the push-button ignition switch is in ON mode, move the select lever with the brake pedal depressed.
  • Page 7 Driving pattern selector switch (if equipped) Selecting a driving mode By pressing the driving pattern selector switch, the following modes can be selected to suit driving and usage conditions: Normal mode Sport mode The SPORT indicator comes on. Use Sport mode for sporty driving or when driving in mountainous regions with lots of curves.

  • Page 8: Gauges And Meters

    METERS/INDICATORS Gauges and meters Digital speedometer Analog speedometer Tachometer Displays the vehicle speed. Displays the engine speed in revolutions Displays the vehicle speed. per minute. Odometer, tripmeter and Engine coolant Fuel gauge multi-information display temperature gauge Displays the quantity of Displays the engine Press the DISP switch, ODO/TRIP switch or km/h MPH switch to display a variety of...
  • Page 9 MAIN WARNING AND INDICATOR LIGHTS Refer to the Owner’s Manual for countermeasures when each warning light comes on. If necessary, consult your authorized Subaru dealer. Malfunction indicator SRS warning Indicates a malfunction in: Indicates a malfunction in: • The electronic engine control system •...
  • Page 10 SEAT, SEATBELT Front seat Seat position adjustment Seatback angle adjustment Vertical height adjustment (driver’s seat only) Seatback fold strap Getting in the rear seats: Getting out the rear seats: Lift the seatback angle adjustment Pull the seatback fold strap. lever. The seat can be slid forward and backward (front passenger seat only).
  • Page 11 Front seatbelt guide To enable the seatbelt to be easily extended, pass the seatbelt through the guide. When getting in or out of the rear seats, release the seatbelt from the guide. Seat heaters (if equipped) Press the switch to warm the seats. Rapid heating Normal heating Folding down rear seatback...
  • Page 12 DOOR LOCKS AND WINDOWS Remote keyless entry (if equipped) Locks both side doors Unlocks both side doors Unlocks the trunk lid (press and hold) Sounds the alarm (press and hold) Remote transmitter key Access key Keyless access function (if equipped) To unlock doors To lock all doors Carry the access key, and grip the driver’s door...
  • Page 13 Fuel filler lid opener Pull up the opener to open the fuel filler lid. Engine hood lock release lever Pull the engine hood release lever. The engine hood will pop up slightly. Power windows Opening window One-touch opening* Closing window One-touch closing* *Pushing the switch in the opposite direction will stop window travel partway.

  • Page 14: Climate Control

    CLIMATE CONTROL Automatic air conditioning system (if equipped) Changes the air outlet used To select the air outlets, set the air outlet selection button to the desired position. Fan speed control dial Turn dial to turn on and to select fan speeds. To adjust the fan speed, turn the fan speed control dial clockwise (increase) or counterclockwise (decrease).

  • Page 15: Manual Air Conditioning System

    Manual air conditioning system (if equipped) Air outlet selection dial To select the air outlets, set the air outlet selection dial to the desired position. Fan speed control dial Turn dial to turn on and to select fan speeds. To adjust the fan speed, turn the fan speed control dial clockwise (increase) or counterclockwise (decrease).
  • Page 16 Colours shown may vary due to reproduction variations in the printing process, and some vehicle parts cannot be shown in certain photographs. Subaru Canada, Inc. reserves the right to discontinue or make changes at any time, without notice or incurring obligations, to colours, materials, equipment, accessories, features, specifications and models, or to change their prices.
