- Page 1 USER MANUAL V1.00 HBP-H3 / H6 / H9 / H12 / H15 HBP HV Battery Series...
-
Page 2: Table Of Contents
CONTENT INTRODUCTION ....................3 1.1 Safety And Warnings ....................3 1.2 Label Description ......................4 1.3 Emergency Measures ....................5 Product Specification ..................6 2.1 System Performance Parameter ................6 2.2 Battery Module ......................7 2.3 Appearance ........................8 Storage and Installation ................10 3.1 Storage ........................ -
Page 3: Introduction
1. INTRODUCTION 1.1 Safety And Warnings High voltages in the battery could cause lethal electrical shocks. All persons who are responsible for mounting, installation, commissioning, maintenance, tests, and service of the battery products must be suitably trained and qualified for corresponding operations. -
Page 4: Label Description
1.2 Label Description DANGER, WARNING AND CAUTION HIGH VOLTAGE AVOID CONTACT USER MANUAL IN PACK BATTERIES CONTAIN FLAMMABLE MATERIALS, BEWARE OF FIRE DO NOT DISPOSE WITH HOUSEHOLD WASTE CE MARKS TUV MARKS RECYCLABLE AND REUSABLE HBP-H3/H6/H9/H12/H15 USER MANUAL... -
Page 5: Emergency Measures
1.3 Emergency Measures Battery Electrolyte Leakage If the battery module leaks electrolyte, avoid contact with the leaking liquid or gas. The electrolyte is corrosive. It will cause skin irritation or chemical burns to the operator. Anyone contacting the leaked substance accidentally has to do the following: •... -
Page 6: Product Specification
2. Product Specification 2.1 System Performance Parameter The battery system supports capacity expansion. A maximum of 5 battery modules can be used to extend the usable energy of the battery system. Strictly follow the expansion requirement. For details, please contact the Dealer or Manufacturer. Otherwise, under-voltage, overvoltage or voltage difference might occur to the battery system. -
Page 7: Battery Module
2.2 Battery Module Table 2-2 Product parameters Model Name HP10230 Cell Technology Li-ion(LFP) Battery Module Rated Capacity (kWh) 3.072 Battery Module Rated Voltage (Vdc) 102.4 Battery Module Rated Capacity (Ah) Battery Cell Rated Voltage (Vdc) Battery Cell Rated Capacity (Ah) Battery Module Cell Quantity in Series (pcs) Battery Module Charge Voltage (Vdc) 116.8... -
Page 8: Appearance
2.3 Appearance Battery System Model Name Battery Controller 2、3、4、5、6 Battery HP10230 Item Base Battery Controller right view Battery Controller left view Battery Controller front view Battery Controller bottom view Model Name Model Name BMS: CAN Terminal Power On Switch External Negative Grounding Point Item External Positive... - Page 9 HP10230 top view HP10230 bottom view Base Model Name Connector plug Connector socket Connector plug HBP-H3/H6/H9/H12/H15 USER MANUAL...
-
Page 10: Storage And Installation
3. Storage and Installation 3.1 Storage If the equipment is not to be installed or used immediately, please ensure that the storage environment meets the following requirements: 1. Do not unpack the outer packing box or throw the desiccant away. 2. -
Page 11: Installation Clearance Requirements
3.2.2 Temperature HBP system working temperature range: 0℃~50℃; Optimum temperature: 18℃~30℃; Caution: Out of the working temperature range will cause the battery system over / low temperature alarm or protection which may lead to the cycle life reduction. 3.2.3 Cooling System It is essential to equip a cooling system to keep the battery system in a relevant temperature range. -
Page 12: Installation Location Precautions
≥300mm ≥300mm ≥300mm ≥300mm 3.4 Installation location precautions HBP-H3/H6/H9/H12/H15 USER MANUAL... -
Page 13: Installation Angle Requirements
3.5 Installation Angle Requirements Install the equipment vertically, no tilt or upside down. 3.6 Safety Gear It is recommended to wear the following safety gear when dealing with the battery pack. 3.7 Unpacking inspection Check the following items before receiving the product. 1. - Page 14 2. Check the product model. If the product model is not what you requested, do not unpack the product and contact the supplier. 3. Check the deliverables for correct model, complete contents, and intact appearance. Contact the supplier as soon as possible if any damage is found. Item Quantity Figure...
-
Page 15: Equipment Installation
3.8 Equipment installation 3.8.1 Installation Preparation Operations such as transportation, turnover, installation, and so on must meet the requirements of the laws and regulations of the country or region where it is located. 1. Consider the weight of the equipment before moving it. Assign enough personnel to move the equipment to avoid personal injury. - Page 16 3.8.2.3 Battery Controller installation ● Put the Battery Controller above the Battery modules securely. Mark the drilling hole using a marker, then remove the Battery Controller. Drill holes using the hammer drill. Secure the brackets to prevent the Battery Controller from falling down. Battery Controller uses 2 screws to fix on the left and right sides.
- Page 17 ● Connect the PE cable first before installing the equipment. Disconnect the PE cable before dismantling the equipment. The PE terminal is equipped at the side of the Battery Controller.PE Conductor cross-section: 10mm² : Model Name Battery Controller M6 terminal lug with protective conductor M6×12 pan head screw Tighten it firmly into the housing (T25 screwdriver, torque: 2.5Nm)
- Page 18 3.8.4.4 Use a multimeter to measure the output voltage on the positive and negative ports of the Battery Controller. The output voltage should conform to the voltage range in the table “Table 2-1 the parameter of HBP system”. Otherwise, the system will be not working properly.
- Page 19 cables together. Both ends must have connectors, and the connector on the inverter side is provided by the inverter. HBP-H3/H6/H9/H12/H15 USER MANUAL...
- Page 20 ● Connect the BMS CAN communication cable to the inverter CAN port. Warning: Check all the PE cable, power cable, communication cable, and terminal resistor are connected correctly and securely. ● Switch on the inverter, to make sure all the power equipment can work normally. ●...
-
Page 21: Maintenance
4. Maintenance 4.1 Trouble Shooting Danger: The battery system is a high voltage DC system, operated by professional and authorized person only. Before check the failure, must check all the cables connection. Switches are right or not (refer to section 3.7.4), and if the battery system can be woken up normally. Problem Possible Reason Solution... -
Page 22: Replacement Of Main Component
4.2 Replacement of main component Danger: The Tower battery system is a high-voltage DC system, that only can be operated by a professional and authorized person. 4.2.1 Replacement of Battery Controller 4.2.1.1 Turn off the whole battery system. Ensure the Negative terminal and Positive terminal have no power. -
Page 23: Battery Maintenance
4.3 Battery Maintenance Danger: The maintenance of battery only can be operated by professional and authorized person. You need turn off the battery system firstly when you do some maintenance things. Maintaining Item Maintaining Period Once every 6 months Check whether the locking brackets are secured, tighten it if not. Check whether the outer enclosure is broken. -
Page 24: Transportation
5. Transportation Battery module will pre-charged to 50% SOC or according to customer requirement before shipment. The remaining capacity of battery cell is determined by the storage time and condition after shipment. ● The battery modules meet the UN38.3 certificate standard. ●... -
Page 25: Disclaimer
6. Disclaimer The battery protects this product under warranty when it is installed and used as listed in this manual. Violation of the installation procedure or use of the product in any way not described in this manual will immediately void all warranties on the product. The battery does not provide warranty coverage or assume any liability for direct or indirect damages or defects that result from the following causes: ●... - Page 26 HINA H – G T +86 512 807 12199 YPONTECH EUTSCHLAND ERMANY RANCH . 11, 69115 H UDOLF IESEL EIDELBERG INFO HYPON SERVICE HYPONTECH HYPON RAZIL FFICE ÃO AULO , 214 OSÉ OCHA OMFIM VENUE BLOC 217, C ONDRES ROOM AMPINAS ÃO...
