Hypontech HBP-H3 Quick Installation Manual

HBP-H3 / HBP-H6 / HBP-H9 / HBP-H12 / HBP-H15
1. Product Overview
Parts Introduction(Battery Controller)
2
Right View
1
5 4 3
Front View
7
Parts Introduction(Battery)
8
1. BMS: CAN Terminal 2. Power On Switch
4. Grounding Point 5. External Positive Socket
7. Button Indicator 8. Rectangular Connector
Dimensions
500mm
(19.69in)
35-45mm
(1.38-1.77in)
H838-00120-04
Left View
8
6
Bottom View
Parts Introduction(Base)
8
3. External Negative Socket
6. Circuit Breaker
350mm
(13.78in)
163.4mm
(6.43in)
189.2mm
(7.45in)
189.2mm
(7.45in)
189.2mm
(7.45in)
189.2mm
(7.45in)
189.2mm
(7.45in)
60mm(2.36in)
2. Packing List
Battery
Mounting
Base Battery
Controller
Screws
N
1 1 N
N = Quantity depends on the battery system.
3.
Installing
Installation Requirements
1. Please install the battery(s) in places that can avoid
inadvertent contact.
2. Please install the battery on solid/smooth surfaces.
3. The battery(s) should not be installed near inflammable
or explosive objects.
AVOID
Direct Rain Snow
Lay up
Sunlight Exposure
3.1 Mounting
3.1.1 Loosen 2 screws to remove Batter y Controller from the Base.
3.1.2 Place the Base cling to the wall; The adjustable feet can adjust Base level.
Remove the upper and lower insulation covers of each batter y box.
3.1.3 Place the Batter y module on the base; Each module uses 2 screws to fix.
3.1.4 Install the remaining batteries according to actual batter y system type.
3.1.5 Put the Batter y Controller above the Batter y modules securely.
Mark the drilling hole using a marker, then remove the Batter y Controller.
3.1.6 Drill holes using the hammer drill.
3.1.7 Secure the brackets to prevent the Batter y Controller from falling down.
Batter y Controller uses 2 screws to fix on the left and right sides.
Step 2
Step 3
NOTICE
The battery module is 29kg.It's necessary to arrange more than 1 person to install battery module if without lifting
equipment, more than 2 person when install battery module in higher position.
Battery
Mounting
BMS
Mounting
Documents
Plugs
Accessories
Terminal
Bracket
(SUNCLIX)
1
1 1 1
≥300mm
≥300mm
≥300mm
≥300mm
HBP-H3 HBP-H6 HBP-H9 HBP-H12
Step 1
Step 4
1
HBP-H15
