Summary of Contents for Dupont Cyrel 2000 ECLF
- Page 1 User’s Manual â Cyrel 2000 ECLF...
- Page 3 User's Manual Cyrel ® 2000 ECLF Edition AA, August 2017 This book has part No 10091626 (GB)
- Page 4 Always read the Safety Instruction Manual part No 21741 before installing or operating the equipment. This manual is published by: Glunz & Jensen S.r.l. Via Alessandro Volta 28 20088 – Rosate (MI) – ITALY Tel.: +39 02 900 90 180 Internet: www.degraf.glunz-jensen.com Copyright ©...
-
Page 5: Table Of Contents
Table of contents Part 1: General information ......1-1 About this manual ..........1-1 Intended use of this manual . -
Page 6: Part 1: General Information
General information About this manual Part 1: General information About this manual Intended use of this manual This manual describes the common use procedures of the equipment. It is intended for the daily user and should be kept with the equipment for reference at all times. Reservations This manual was written and illustrated using the best possible information •... -
Page 7: Unintended Use Of The Equipment
General information About this manual Unintended use of the equipment Glunz & Jensen S.r.l. does not take any responsibility for any damage or accidents caused by unintended use of the equipment: It is absolutely prohibited to make any modifications, electrical nor mechanical, of •... -
Page 8: Part 2: Daily Use
Daily use General Part 2: Daily use General This equipment is designed to expose, post-expose and light finish of flexographic printing plate before and after the washout process. The equipment is divided in the following sections: Exposure section - 38 lamps to ensure even exposure. •... - Page 9 Daily use Safety warnings " The exposure section is fitted with a safety interlock to prevent user to be exposed to UVA light radiation. " The light finisher drawer is fitted with a safety interlock to prevent user to be exposed to UVC and UVA light radiation. UVC light radiation is dangerous for human skin and particularly the eyes.
-
Page 10: Initial Operation Of The Equipment
Daily use Initial operation of the equipment Initial operation of the equipment Before switching the machine on make sure that the working area around the • machine is clean and free for easy movement. Check if there is any damage on the different hoses, check for water leak and verify •... -
Page 11: Main Screen Description
Daily use Main screen description Main screen description The main screen allows to make several functions and to display several machine parameters: Exposure section Display overview Description Display the last plate name selected. Press on this frame to access to the plate list memorised in the machine and select the plate needed to process. - Page 12 Daily use Main screen description Display overview Description Display the main exposure time memorised in the channel of the plate displayed. When the cycle is started the frame is blinking green and the remaining time is shown at the centre. The frame is changing as well from “START MAIN”...
-
Page 13: Light Finisher Section
Daily use Main screen description Light finisher section Display overview Description Display the last plate name selected. Press on this frame to access to the plate list memorised in the machine and select the plate needed to process. This frame is used in both exposure and light finishing section. -
Page 14: Alarms
Daily use Main screen description Alarms When an alarm occurs, the warning sign is then displayed in the middle of the main screen. Depending of the type of alarm, the corresponding warning sign will be displayed. Critical alarm This sign indicates the machine is not in the condition to work in normal and safe way. -
Page 15: Plate Parameters
Daily use Main screen description Plate parameters 25 channels (from 0 to 24) are available to store the plate name as well as back exposure, main exposure, UVA and UVC times. To access to the plate parameters modification screen, press on from the Exposure or Light- finisher section. -
Page 16: Part 3: Making Plates
Making plates Plate selection Part 3: Making plates Plate selection Press on from the exposure or light finisher section to access to the plate selection screen. Exposure section Light finisher section To select the plate to produce just scroll up or down until you the correct plate name is displayed. -
Page 17: Starting An Exposure Cycle
Making plates Starting an exposure cycle Starting an exposure cycle During an automatic cycle as well as in manual operation, the safety of the lid is in operation. In case of contact the lid will stop closing and will then open completely. -
Page 18: Starting A Light Finisher Cycle
Making plates Starting a light finisher cycle Starting a light finisher cycle Open the drawer and put the plate in. • Close the drawer (the background of the light finisher section switch from red • colour to green). Select plate type to produce. •...
