- Page 1 Cyrel ® 1000 ECLF...
- Page 3 Pre-installation Manual Cyrel ® 1000 ECLF T11341 Edition AA, October 2016 This book has part No 10087668...
- Page 4 This manual is published by: Glunz & Jensen S.r.l. Via Alessandro Volta 28 20088 – Rosate (MI) – ITALY Tel.: +39 02 900 90 180 Internet: www.degraf.glunz-jensen.com Copyright © 2016 by Glunz & Jensen S.r.l. Pre-installation Manual - Cyrel® 1000 ECLF 1641...
-
Page 5: Part 0: Introduction
Introduction Part 0: Introduction Reservations This manual was written and illustrated using the best possible information • available at the time of publication. Any differences between this manual and the equipment reflect improvements • introduced after the publication of the manual. Changes, technical inaccuracies and typographic errors will be corrected in •... -
Page 6: Table Of Contents
Introduction Table of contents Table of contents Part 0: Introduction ........0-3 Reservations . -
Page 7: Part 1: Transportation
Transportation When the equipment arrives Part 1: Transportation When the equipment arrives Storing the equipment before installation The crated equipment will usually be delivered some time before the arrival of the Service Technician. In which case you should prepare an appropriate place indoors to store the crated equipment. -
Page 8: Checking The Crate For Damage
Transportation The crate Checking the crate for damage Check if the crate is damaged at the time of delivery. Take note of the damage before you allow the Service Technician to unpack the equipment. Provide a detailed description or take a photograph of the damage. "... -
Page 9: Transporting The Equipment
Transportation Transporting the equipment Transporting the equipment Lifting the crate The equipment is supplied in a wooden crate. The equipment is very heavy equipment. To lift the crate a fork-lift truck is required. T32327 Available width for transport Depending on the width of the door(s) through which the equipment has to be transported to the installation site, the Service Technician may have to perform the actions described in the table below: If width of the door is…... - Page 10 Transportation Transporting the equipment Pre-installation Manual - Cyrel® 1000 ECLF 1641...
-
Page 11: Part 2: Installation Requirements
Installation requirements Installation hours Part 2: Installation requirements This equipment must be installed in restricted access locations only. " Check the delivery route to the installation location for necessary clearance and remove all obstructions. Installation hours The installation of the equipment will last 1 working day. •... -
Page 12: Space Requirements
Installation requirements Space requirements Space requirements Free space around the equipment Decide where the equipment shall be placed and make sure that the free space around the equipment makes servicing and work possible. The recommended minimum free space around the equipment is as illustrated below. T11409 Pre-installation Manual - Cyrel®... -
Page 13: Equipment Dimensions
Installation requirements Space requirements Equipment dimensions " ) 4 . 8 0 . 9 1 " " ) " ) 4 . 3 T11410 1641 Pre-installation Manual - Cyrel® 1000 ECLF... -
Page 14: Connections Location
Installation requirements Connections location Connections location All the connection points are located at the back of the equipment (see illustration below). t ø i s h f i n l i g p l y T 411 Exhaust requirements Light finisher exhaust must be connected to the appropriate location (directly to the outside or to the building exhaust installation). -
Page 15: Electrical Requirements
Installation requirements Electrical requirements Electrical requirements Electrical installation must conform to local regulations and guidelines. Main power outlet Provide a main power outlet close to the installation site. The table below indicates the applicable power supply types. Power supply cable The power supply cable (5 m) is delivered with the equipment. - Page 16 Installation requirements Electrical requirements Pre-installation Manual - Cyrel® 1000 ECLF 1641...
-
Page 17: Part 3: Pre-Installation Checklist
Pre-installation checklist Part 3: Pre-installation checklist Please ask the customer to answer the following questions in order to ensure a trouble-free installation of the equipment. Send this completed pre-installation checklist to your regional service coordinator. 1. Delivery of the crate and transport to the installation site YES NO A. - Page 18 Pre-installation checklist 3. Environmental and exhaust requirements YES NO A. Is capacity of air condition/ventilation adequate with regard to exhaust and environmental requirements specified on pages 2-1 and 2-4? B. Is there an adequate exhaust system as specified on page 2-4 available? C.
- Page 19 Pre-installation checklist 1641 Pre-installation Manual - Cyrel® 1000 ECLF...
