- Page 1 User's Guide Cyrel® 2000 ECLF IMPORTANT Please keep this manual with other equipment documentation for future reference. July 18th, 2019 Edition BA, Part No 10091626 English (en-us) Original version...
- Page 2 ( Blank ) User's Guide|Cyrel® 2000 ECLF July, 2019...
-
Page 3: About This Manual
About this manual About this manual This manual applies to the combined unit Cyrel® 2000 ECLF. Always read the separate Safety Instruction Manual part No 21741 before operating the equipment. This manual is published by: Glunz & Jensen A/S Lindholm Havnevej 29 5800 Nyborg Denmark Phone: +45 57 68 81 81... -
Page 4: Table Of Contents
Table of Contents Table of Contents About this manual Table of Contents General information Intended use of this manual Reservations Notes, Cautions and Warnings! The equipment Unintended use of the equipment Intended use of the equipment Installation Service assistance Daily use General Safety warnings Initial operation of the equipment... -
Page 5: General Information
General information General information Intended use of this manual This manual describes the common use procedures of the equipment. It is intended for the daily user and should be kept with the equipment for reference at all times. Reservations • This manual was written and illustrated using the best possible information available at the time of publication. -
Page 6: The Equipment
General information The equipment Unintended use of the equipment Glunz & Jensen does not take any responsibility for any damage or accidents caused by unintended use of the equipment. It is absolutely prohibited to make any modifications, electrical or mechanical, of the equipment. If however this prohibition is disregarded, Glunz &... -
Page 7: Daily Use
Daily use Daily use General This equipment is designed to expose post-expose/light finish of flexographic printing plates. The operator interface is made by a color touch screen which ensures a very easy control. July, 2019 User's Guide|Cyrel® 2000 ECLF... -
Page 8: Safety Warnings
Daily use Safety warnings Any maintenance, servicing or adjustments must only be carried out by suitably skilled or properly instructed/supervised personnel. Guards, other than the top covers must NOT be removed by anyone other than an authorized and trained service engineer. To use this equipment safely, it is necessary that operators and maintenance people follow the safety instructions and safety cautions and warnings specified in the manuals. - Page 9 Daily use CAUTION: Make sure that the cooler tank is filled with proper cooling liquid before turning the machine on. See Service manual for more details. NOTE: Make sure the room temperature is between 17°C (63°F) and 28°C (82°F) and relative humidity between 20 and 80.
-
Page 10: Main Screen Description
Daily use Main screen description Exposure section Display Description PLATE: It displays the selected plate name. Press to select the plate to process. The plate channel number is as well displayed in the top right corner. NOTE: Up to 25 channels (from 0 to 24) are available to store the plate parameters. NOTE: The plate name is the same in the exposure as well in the light finisher section. -
Page 11: Light Finisher Section
Daily use Display Description The button allows access to the Plate parameters modification screen. NOTE: The button is visible only if access to the Plate parameters modification is unlocked (refer to Service manual). Press the button to start/stop the vacuum pump. The level of vacuum is displayed on top of the button. - Page 12 Daily use Display Description START It displays set UVC time. When the cycle starts, the button is blinking green and the "START UVC: UVC" is changed to "STOP UVC". The remaining time is displayed in the middle. The "END" is displayed at the end of the cycle and the button remains green, indicating the end of the cycle.
-
Page 13: Plate Settings
Daily use Plate settings It is possible to store 25 plates (channels 0 - 24) with main and back exposure, or UVA and UVC times. • By pressing the button from exposure or light finisher section, corresponding plate parameters screen is displayed (this button is available on the main screen as well as on the plate selection screen). - Page 14 Daily use NOTE: The plate name of the same channel is common for both exposure and light finisher section. Modifying the plate name in one section will modify the plate name in the other section as well. User's Guide|Cyrel® 2000 ECLF July, 2019...
-
Page 15: Making Plates
Making plates Making plates Plate selection Press the "PLATE:" field of dedicated section on the main screen to access the plate selection screen. Exposure section Light finisher section • To select the plate to process, scroll up or down until required plate name is displayed. Press required plate name to highlight it. -
Page 16: Starting An Exposure Cycle
Making plates Starting an exposure cycle WARNING: For handling the plates use a safety gloves. • Put the plate on the vacuum table. • If needed, start the vacuum pump. • Verify the vacuum level. • Select plate type in the exposure section. •... -
Page 17: Starting A Light Finisher Cycle
Making plates Starting a light finisher cycle WARNING: For handling the plates use a safety gloves. • Open the light finisher drawer and put the plate in. • Close the drawer. • Select plate type in the light finisher section. •... - Page 18 User's Guide Cyrel® 2000 ECLF July, 2019...
-
Page 19: Maintenance
Maintenance Maintenance The equipment is equipped with emergency switch which allows the operator to stop the equipment in case of an emergency. These emergency switches cut off the power supply of the entire equipment, except power supply of the controls (relays, touch screen, etc.). WARNING: Make sure that the risk or the problem has been eliminated before restoring the power on the equipment. -
Page 20: Cleaning Air Filter
Maintenance Cleaning air filter The Moisture Trap (3) is a self-venting system but the air filter needs cleaning when dirt builds up. WARNING: Make sure the equipment is turned off and the main switch is locked in "OFF" position. • Unplug the compressed air supply. -
Page 21: Cleaning
Maintenance Cleaning • Clean the equipment covers from dust and dirt by using a clean damp cloth. UV output measurement • Open the exposure and place the sensor of a Kühnast meter on top of the exposure table. • Close the exposure. •... -
Page 22: Uv Lamps Replacement
Maintenance UV lamps replacement • The UV lamp is fragile, take a great care while unpacking, moving and installing the UV lamp. • Only clean UV lamps ensure uniform light emission. Before installation, ensure the UV lamps are clean. • Perspiration and sebaceous oil from the skin form white smudges which become etched on the quartz surface of the UV lamp, when the UV lamp reaches its normal operating temperature. -
Page 23: Exposure Lamps Replacement
Maintenance Exposure lamps replacement WARNING: Make sure the equipment is turned off and the main switch is locked in "OFF" position. • Open the top lid of the equipment. • Remove the UV lamps by turning them 90°. • Make sure that the socket position is correct on both sides for inserting the UV lamp. To adjust the socket correctly it is recommended to use a flat screwdriver (2). - Page 24 Maintenance • Remove the light finisher drawer. • Remove the rear panels. • Remove the locking screws of the lamps holder drawer on both sides. • Pull out the lamps holder drawer from the equipment's front. User's Guide|Cyrel® 2000 ECLF July, 2019...
- Page 25 Maintenance • Remove the UV lamps by turning them 90°. • Make sure that the socket position is correct on both sides for inserting the UV lamp. To adjust the socket correctly it is recommended to use a flat screwdriver (2). •...
- Page 26 User's Guide Cyrel® 2000 ECLF July, 2019...
