- Page 1 Cooking Range User manual Model No.: Y95ND, C74ND Manufactured by: Adexa Direct Limited Unit 1 Swift Point, Cosford Lane, Swift Valley Industrial Estate, Rugby, CV21 1QN, UK service@adexa.co.uk , T:+44 1788 222 410...
-
Page 2: Table Of Contents
Maintenance & Cleaning Trouble Shooting SPECIFICATION Model Oven Unit Size Burners Oven capacity 1.0kW+1.8kW+1.8kW+2.8 Y95ND 90x60x85cm 4.0kW+3.0kW 116L kW+4.0kW 1.0kW+1.8kW+1.8kW+4.0 C74ND 70x55x85cm 3.0kW+1.7kW This manual is prepared for more than one model. Your appliance may not have some of the features outlined in this manual. Please read this manual carefully and pay attention to the figures and information that relates to your model. -
Page 3: Important Safety Information
IMPORTANT SAFETY INFORMATION It is very important that this instruction book should be kept safely for the future consultation. If the appliance should be sold or given to another person, please ensure that the booklet goes together with it, so that the new owner can know functions of this appliance and also be aware of the necessary precautions. - Page 4 Where supplied you must use the adjustable feet. The cooker chassis must not sit directly on the floor, a plinth or support surface. To fit adjustable feet.- 1. Place the cooker on a piece of polystyrene packaging or similar exposing the base for fitting the feet. 2.
- Page 5 The following instructions are meant for a qualified installer, in order that the operations of installation, regulation, and service are executed according to the existing regulations. Whenever changes are made involving the disconnection of the machine it is necessary to proceed with maximum caution.
- Page 6 This electric fan must be powerful enough to ensure in a kitchen an air replacement of 3 to 5 times its volume per hour. WARNING - If the oven touches the side of other pieces of the kitchen furniture, ensure they can withstand a temperature of 75℃. ELECTRICAL CONNECTION Before you connect the gas cooker, please check that the voltage indicated on the rating plate to ensure that it corresponds to the mains power supply...
-
Page 7: Using Cooker For The First Time
1. The hose does not exceed a length of 1 meter. 2. The hose must not be very tight or twisted and must not show any sharp bends or kinks. If there is a leak don't repair but replace it. 3. - Page 8 There may be a smell. This is quite normal when the cooker is first heated as residual oil from production of parts will be burnt off quickly. There may be noises. This is also quite normal as new parts move and settle into place during the initial heating process.
- Page 9 into the dripping pan to avoid grease burning and creating unpleasant smell. Clean dripping pan regularly to ensure food, fat and grease do not build up and create a fire hazard. Before maintenance and cleaning, disconnect the appliance and allow cooling down.
-
Page 10: Using The Gas Hob Burners
The gas oven becomes hot with the movement of air. The holes on the bottom of the oven must never be obstructed. Do not cover the sides of the oven with aluminum foil, particularly the lower part of the opening at the base of the gas oven. ... - Page 11 Control knobs on the gas burners The knobs for the gas burners of the cooker are found on the control panel. The regulating knobs should be turned in anti-clockwise direction until the small flame symbol, vice-versafor the larger flame symbol. No gas supply Maximum gas supply Minimum gas supply...
-
Page 12: Using The Hotplate
USING THE HOTPLATE The hotplates are controlled by heating switch on the control panel.. By switching the control knob to any position from small and to big, with biggest number being the hottest, the hotplate can be operated. Near each hob control knob, there is a small diagram that shows which hotplate is controlled with that knob. -
Page 13: Using The Gas Oven
USING THE GAS OVEN Manual ignition of the Oven burner Open the oven door, then push and turn the oven knob in an anti-clockwise direction to the maximum position, introduce a small flame or spark lighter to the small ignition hole located in the front of the oven burner cover on the bottom of your oven. -
Page 14: Using The Electric Oven
MPOTRANT SAFETY: Apply knob protection plate when using gas grill burner. (Knob protection plate is stored at the compartment.) After a few minutes check the temperature and adjust the grill control if necessary to obtain the required level. USING THE ELECTRIC OVEN Electric Oven 4 Functions This oven functions allow the user to have flexibility in the method of cooking and provide heating alternatives to suit a wide variety of dishes. - Page 15 Tradition Cooking For tradition baking (one level ), turn the selector switch to the position and turn the thermostat knob until it coincides with the temperature required. Cooking with the Lower Heater For reheating or baking delicate food, turn the selector switch to the position and turn the thermostat knob until it coincides with the temperature required.
- Page 16 Electric Oven 5 Functions This electric oven is controlled by the switch combined with the oven thermostat. As the knob is turned clockwise, the following functions are obtained in this order: Oven light switches on; 0...250 numerical indication of the temperature which can be obtained in the oven(in this thermostat controled function, the oven is heated by two elements, one in the top and one at the bottom);...
- Page 17 Electric Oven 8 Functions This oven functions allow the user to have flexibility in the method of cooking and provide heating alternatives to suit a wide variety of dishes. The oven light stays lit in all selector positions. Oven light The oven light and general pilot light come on and will remain on as long as the oven is in use.
- Page 18 around the oven cavity for even cooking results. Ideal for baking or cooking on up to 3 levels. Grill This cooking mode is used for grilling small amounts of food such as steak, chops, sausages and fish (low energy consumption). Heat comes from the top grill element which directs radiant heat onto the food.
-
Page 19: Using The Mechanical Timer
When cooking with the electric grill, you are advised to leave the oven door half open and to fit the knob protection plate. 1) Place the oven drip pan on the runner position under the grid rack on which you want to grill. 2) Close the oven door until it touches the knob protection plate. -
Page 20: Using The Turnspit
USING TURNSPIT First, insert the forked branch into the spindle of motor. Then take out the hook according to the direction of the figure below. Next, put the turnspit in which it has a slot hang on the hook. (While removing in reverse order.) ... - Page 21 For baking cakes: Pre-heat the oven for at least 10minutes before use. Do not open the oven door when baking. The jet of cold air will block the raising block the raising process of some cakes, pastries and soufflés. ...
- Page 22 half hour. Begin cooking raw meat at a high temperature, reducing the temperature to finish cooking the inside. The cooking temperature for white meat can be mode-rate throughout. The degree of cooking can be checked by pressing the meat with a fork, if it penetrates easily then it is cooked.
-
Page 23: Maintenance & Cleaning
The "TIPS FOR OVEN COOKING" relating to cooking in the oven and by grill is provided as a guide. Experience will show possible variations to the values set out in the table. NOTE –If in doubt, always carefully follow the indications given in the in the recipes you intend to follow. - Page 24 Wash the enameled grids with water and detergent; these can also be washed in a dishwasher. Take off the burner covers and the grids and wash them carefully with warm water and detergent. Dry them well before putting them back in position.
-
Page 25: Troubleshooting
Periodically check the condition of the flexible hose of gas connection and have it replaced by skilled technicians as soon as it shows abnormalities. Annual replacement is recommended. For model with a gas cylinder compartment, do not use this space to keep a non-connected or empty cylinder.
