Summary of Contents for Biostar BIWLA-IHT

  • Page 1: Fcc Information And Copyright

    FCC Information and Copyright This equipment has been tested and found to comply with the limits of a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 2: Table Of Contents

    Table Of Contents FCC Information and Copyright ������������������������������������������������������������������������������� 1 Chapter 1: Introduction ������������������������������������������������������������������������������������������� 3 1.1 Before You Start ........................3 1.2 Package Checklist ........................ 3 1.3 Specifications ........................4 Chapter 2: Hardware installation ����������������������������������������������������������������������������� 8 2.1 Central Processing Unit (CPU) ..................... 8 2.2 Connect Cooling Fan ......................
  • Page 3: Chapter 1: Introduction

    BIWLA-IHT User’s Manual Chapter 1: Introduction 1�1 Before You Start Thank you for choosing our product. Before you start installing the motherboard, please make sure you follow the instructions below: •  Prepare a dry and stable working environment with sufficient lighting.
  • Page 4: Specifications

    1.3 Specifications Intel® Whiskey Lake-U (8th generation Core™ i7/i5/i3 ) processor Intel® Integrated HD Graphics VGA: 1x 2*8 N16(2.0) pin-header, resolution up to 1920 x 1200@60Hz, (colay DP) DP1.2: 1x DP connector, resolution up to 3480 x 2160@60Hz HDMI: 1x HDMI connector, resolution up to 4096 x 2160@30Hz 1x LVDS, support dual channel 18/24bit.
  • Page 5 BIWLA-IHT User’s Manual Expansion slots 2x 260-pin socket support DDR4 2400 SO-DIMM 2x 1*7 pin SATA connector 1x M.2 Key E connector, support PCIE+USB interface, support CNVI 1x M.2 key M connector, support 2242/2260/2280 1 x M.2 key B type 3042 with PCIE and USB interface for 3G/4G...
  • Page 6 1�4 Rear Panel Connectors Standard DC-12V ~ 28V Output Jack 6 | Chapter 1: Introduction...
  • Page 7 BIWLA-IHT User’s Manual 1.5 Motherboard Layout Note »  »  represents the 1st pin. Chapter 1: Introduction | 7...
  • Page 8: Chapter 2: Hardware Installation

    Chapter 2: Hardware installation 2.1 Central Processing Unit (CPU) The mainboard includes an onboard Intel® SOC, and a cooler has been installed to provide sufficient cooling. 2.2 Connect Cooling Fan The fan header supports cooling-fans built in the computer. The fan cable and connector may be different according to the fan manufacturer.
  • Page 9: Power Supply

    BIWLA-IHT User’s Manual Memory Capacity DIMM Socket Location DDR3 Module Total Memory Size DIMMA1 8GB/16GB/32GB Max is 64GB DIMMB1 8GB/16GB/32GB 2.4 Power Supply DC2: ATX Power Source Connector (4-pin) This connector provides or +12V input to system power circuit. Pin Assignment...
  • Page 10: Jumpers / Headers / Connectors

    2.5 Jumpers / Headers / Connectors Jumper Setting The illustration shows how to set up jumpers. When the jumper cap is placed on pins, the jumper is “close”, if not, that means the jumper is “open”. Pin opened Pin closed Pin 1-2 closed JPANEL1: Front Panel Header This 10-pin header includes Power-on, Reset, HDD LED, and Power LED connection.
  • Page 11 BIWLA-IHT User’s Manual TPM1: Trusted Platform Module Header This header allows you to store cryptographic keys that protect information. Assignment Assignment LAD0 VCC3_3 LAD1 VCC3_3 LAD2 PCLK_TPM LAD3 L_FRAME_N SER_IRQ TPM_RST CLK_RUN# +3V3_DUAL F_USB2/F_USB3: USB 2.0 Header This header allows you to connect two additional USB 2.0 ports.
  • Page 12 COM1/COM2: Serial Port Headers RS-232 (Default) RS-422* RS-485* Pin Assignment Carrier detect (DCD) 422 TXD- 485 DATA- Received data (RXD) 422 TXD+ 485 DATA+ Transmitted data (TXD) 422 RXD+ Data terminal ready (DTR) 422 RXD- Signal ground (GND) Data set ready (DSR) Request to send (RST) Clear to send (CTS) RI, 5V, 12V selected by...
  • Page 13 BIWLA-IHT User’s Manual LVDS-OUT1: LVDS Connector This connector supports 18/24 bit single-channel panels. Pin Assignment Assignment LVDSB_DATA0_N PVDD2 LVDSB_DATA0_P PVDD2 LVDSB_DATA1_N LVDSB_DATA1_P LVDSA_DATA0_N LVDSA_DATA0_P LVDSB_DATA2_N LVDSB_DATA2_P LVDSA_DATA1_N LVDSA_DATA1_P LVDSB_CLK_N LVDSB_CLK_P LVDSA_DATA2_N LVDSA_DATA2_P LVDSB_DATA3_N LVDSB_DATA3_P LVDSA_CLK_N VCC5 LVDSA_CLK_P LVDS-EDID_SCL VCC3_3 LVDSA_DATA3_N...
  • Page 14 INVERTER1 Assignment VCC5V/12V VCC5V/12V ENABKL BL_CTRL_C JLV1: LCD Panel Power Select Jumper This jumper is for selecting LCD Power. Pin 1-2 Close: 3.3V Pin 2-3 Close: 5V JLV2: LCD Backlight Inverter Power Select Jumper This jumper is for selecting LCD Backlight Inverter Power. Pin 1-2 Close: 5V Pin 2-3 Close: 12V SPK: Audio Connector...
  • Page 15 BIWLA-IHT User’s Manual JDIO1: Digital I/O Connector This connector offers 4-pair of digital I/O functions and address is set in BIOS. Pin Assignment JDIO_PWR DI01 DO01 DI02 DO02 DI03 DO03 DI04 DO04 10 -- »  » You could read the address value at dword  (32 bits/4 bytes). JVGA1: VGA Connector This header allows you to connect VGA output.
  • Page 16 2.6 Expansion Slots PCIE-M2_1/PCIE-M2_2/PCIE-M2_3: Mini PCI-E Slot (Height @ 8mm) Install an Expansion Card You can install your expansion card by following steps: •  Read the related expansion card’s instruction document before install the expansion card into the computer. •  Remove your computer’s chassis cover, screws and slot bracket from the computer. • ...
