Summary of Contents for Biostar BIRPL-PAT

  • Page 1: Fcc Information And Copyright

    FCC Information and Copyright This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 2: Table Of Contents

    Table Of Contents FCC Information and Copyright ������������������������������������������������������������������������������� 1 Chapter 1: Introduction ������������������������������������������������������������������������������������������� 3 1.1 Before You Start .............................3 1.2 Specifications ............................4 1.3 Rear Panel Connectors ...........................7 1.4 Motherboard Layout ..........................8 Chapter 2: Hardware installation ��������������������������������������������������������������������������� 10 2.1 Central Processing Unit (CPU) ......................10 2.2 Fan Headers ............................10 2.3 Installing System Memory ........................10 2.4 Expansion Slots ............................12...
  • Page 3: Chapter 1: Introduction

    BIRPL-PAT User’s Manual Chapter 1: Introduction 1.1 Before You Start Thank you for choosing our product. Before you start installing the motherboard, please make sure you follow the instructions below: •  Prepare a dry and stable working environment with sufficient lighting.
  • Page 4: Specifications

    1.2 Specifications Project Name BIRPL-PAT Dimensions 148 x 102x 1.6 mm, 10 layers Intel® 13 Gen Raptor Lake-P Processors, TDP: 15W U300E, I3-1315UE, I5-1345UE. Processor Support wide range temperature CPU: I3-1315URE, I5-1345URE EDP to LVDS: CH7513A-BFI LAN controller: I226V/I226LM – (Wide range temperature: I226-IT)
  • Page 5 BIRPL-PAT User’s Manual Audio Codec: ALC897+ ALC105 (1) 1 x 2*5 2.0mm box header for Front Audio ● MIC-in Audio ● Line-out ● Line-In (2) 1 x 1*4 2.0mm box header for Speaker out (2W) 8-Bit DIO header, GPIO power support 5V/12V switch by jump. (default 5V)
  • Page 6 Contact with 4Kv, Air with 8Kv ESD/ EMI EMI class A 0ºC ~ 60ºC Humidity: 5% ~ 90% Operation Temp.. Wide range temperature: -40ºC ~ 85ºC Humidity: 5% ~ 90% Storage Temp. -40ºC ~ 85ºC Humidity: 5% ~ 90% 6 | Chapter 1: Introduction...
  • Page 7: Rear Panel Connectors

    BIRPL-PAT User’s Manual 1.3 Rear Panel Connectors Chapter 1: Introduction | 7...
  • Page 8: Motherboard Layout

    1.4 Motherboard Layout Top View »  »  represents the 1st pin. 8 | Chapter 1: Introduction...
  • Page 9 BIRPL-PAT User’s Manual Back View »  »  represents the 1st pin. Chapter 1: Introduction | 9...
  • Page 10: Chapter 2: Hardware Installation

    Chapter 2: Hardware installation 2.1 Central Processing Unit (CPU) The mainboard includes an Intel® Celeron processor, and a cooler has been installed to provide sufficient cooling. 2.2 Fan Headers These fan headers support cooling-fans built in the computer. The fan cable and connector may be different according to the fan manufacturer.
  • Page 11 BIRPL-PAT User’s Manual Memory Capacity DIMM Socket Location DDR5 Module Total Memory Size DIMMA1 8GB/16GB/32GB Max is 64GB DIMMB1 8GB/16GB/32GB Note »  » When installing more than one memory module, we recommend to use the same brand and capacity memory on  this motherboard. Chapter 2: Hardware installation | 11...
  • Page 12: Expansion Slots

    2.4 Expansion Slots M2_1: M.2 (Key M) Slot •  The M.2 slot supports M.2 Type 2242/2260/2280 module. When installing M.2 module, please place the screw and hex pillar to correct position. M.2 KEY M Pin Assignment Assignment +V3.3S +V3.3S M2_DAS +V3.3S +V3.3S +V3.3S...
  • Page 13 BIRPL-PAT User’s Manual M2_3: M.2 (Key B) Slot •  The M.2 slot supports M.2 Type 3042/3052 module. When installing M.2 module, please place the screw and hex pillar to correct position. M.2 KEY B Pin Assignment Assignment M2_B_CFG3 +V3.3A +V3.3A...
  • Page 14 M2_2: M.2 (E Key) Socket •  Support M.2 socket 2230 type module. •  Supports USB 2.0, PCIex1 and Intel CNVi. M.2 KEY E Pin Assignment Assignment +V3.3A USB2_P10_DP +V3.3A USB2_P10_DN M2_BT_PCMCLK M2_BT_PCMFRM_CRF_RST_ CNV_WR_D1_DN M2_BT_PCMFRM_CRF_RST_ CNV_WR_D1_DP M2_BT_PCMOUT_CLKREQ CNV_WR_D0_DN CNV_WR_D0_DP +V3.3A GPPC_A8_UART_WAKE_N CNV_WR_CLK_DN GPPC_F1_CNV_BRI_RSP CNV_WR_CLK_DP...
  • Page 15 BIRPL-PAT User’s Manual Install an Expansion Card You can install your expansion card by following steps: •  Read the related expansion card’s instruction document before install the expansion card into the computer. •  Remove your computer’s chassis cover, screws and slot bracket from the computer.
  • Page 16: Headers / Connectors

    2.5 Headers / Connectors CN1: SATA Power Connector Pin Assignment VCC5 VCC12 BAT1: WAFER 1X2 1.25MM Pin Assignment BAT_IN 16 | Chapter 2: Hardware installation...
  • Page 17 BIRPL-PAT User’s Manual LVDS/EDP: WAFER 2X15 1.25MM Pin Assignment LVDSB_DATA0_N PVDD2 LVDSB_DATA0_P PVDD2 LVDSB_DATA1_N LVDSB_DATA1_P LVDSA_DATA0_N LVDSA_DATA0_P (eDP_ HPD) LVDSB_DATA2_N LVDSB_DATA2_P LVDSA_DATA1_N(eDP_ TX1N) LVDSA_DATA1_P(eDP_ TX1P) LVDSB_CLK_N LVDSB_CLK_P LVDSA_DATA2_N(eDP_ TX0N) LVDSA_DATA2_P(eDP_ TX0P) LVDSB_DATA3_N LVDSB_DATA3_P LVDSA_CLK_N(eDP_ AUXN) +VCC5S LVDSA_CLK_P(eDP_ AUXP) +V3.3S LVDSA_DATA3_N...
  • Page 18 JC1: Backlight Control Header Pin Assignment VCC12S VCC12S +VCC5S BKLTEN_LVDS EDPA_BKLT_CTRL F_USB1: USB Header Pin Assignment PWR_RUSB2 PWR_RUSB2 USB2_P7_DN USB2_P8_DN USB2_P7_DP USB2_P8_DP F_AUDIO1: Front Panel Audio Header Pin Assignment FMIC1 FLINE1_LL(LINE IN) FLINE1_RR(LINE IN) FLINE2_LL(LINE OUT) FLINE2_RR(LINE OUT) 18 | Chapter 2: Hardware installation...
  • Page 19 BIRPL-PAT User’s Manual JSPK1: Chassis Speaker Header Pin Assignment SPKLP SPKLN SPKRN SPKRP JCOM1, JCOM2, JCOM3: RS232/RS422/RS485 Header Pin Assignment COM_DCD/RS422_TX-/RS485_R-T- COM_RXD/RS422_TX+/RS485_R+T+ COM_TXD/RS422_RX+ COM_DTR/RS422_RX- COM_DSR COM_RTS COM_CTS COM_PWR JCOM4: RS232 Header Pin Assignment COM_DCD COM_RXD COM_TXD COM_DTR COM_DSR COM_RTS COM_CTS...
  • Page 20 JDIO1: DIO Header Pin Assignment VDIO_POWER JF_PANEL1: Front Panel Header Pin Assignment POWER_LED+ SPKR- SPKR_CNTL SPKR- +VCC5S pull high PWRSW+ HWRST+ HDD_LED- HDD_LED+ DCIN1: DC_JACK Header PHOENIX CONN 2P Pin Assignment VCC(9V ~ 24V) 20 | Chapter 2: Hardware installation...
  • Page 21 BIRPL-PAT User’s Manual SATA1: Serial ATA 6.0 Gb/s Connectors The connector supports the thin Serial ATA cable for primary internal storage devices. Pin Assignment SSATA_TXP1 SSATA_TXN1 SSATA_RXN1 SSATA_RXP1 Detect SIM1: SIM Slot Pin Assignment UIM_PWR UIM_Reset UIM_CLK Data Chapter 2: Hardware installation | 21...
  • Page 22: Jumpers

    2.6 Jumpers Jumper Setting The illustration shows how to set up jumpers. When the jumper cap is placed on pins, the jumper is “close”, if not, that means the jumper is “open”. Pin opened Pin closed Pin 1-2 closed JCMOS: Clear CMOS Jumper Placing the jumper on pin2-3 allows user to restore the BIOS safe setting and the CMOS data.
  • Page 23 BIRPL-PAT User’s Manual JLV1: LCD panel power select Header JLV1 +V3.3S +VCC5S VCC12S JAT_ATX1: HEADER 1X3 JAT_ATX1 COMPWR 1/2/3/4 COMPWR +VCC5S VCC12S JDIO-PWR1: JDIO-POWER JDIO_PWR1 VCC12S +VCC5S (Default) Chapter 2: Hardware installation | 23...
